| Поз. | Номер | Описание | Применение | Номенклатура | Кол-во |
| 001 |
20988124 |
PANEL, BODY SI UPR TR (INCLS 2) (EBONY) |
ST1 (53) (27I) |
2007-2012 |
01 |
| 001 |
20988125 |
PANEL, BODY SI UPR TR (INCLS 2) (EBONY) |
ST1 (53) (27I) |
2007-2012 |
01 |
| 002 |
11588650 |
CLIP, 12X14X16.6, GM4345M (PART OF 1) |
|
2004-2012 |
02 |
| 003 |
11561654 |
RETAINER, R/END TR FIN PNL (PART OF 4) (PLAIN) (BIRDS BEAK SINGLE) (FITS 8.5 DIA HOLE) (12.800) |
ST1 (53) |
2011-2012 |
06 |
| 004 |
15805185 |
PANEL, R/END TR FIN (INCLS 3, 8) (EBONY) |
ST1 (53) (AJ2, 27I) |
2007-2012 |
01 |
| 004 |
22798085 |
PANEL, R/END TR FIN (INCLS 3, 8) (EBONY) |
ST1 (03-53) (AM6, 27I) (EXC AJ2) |
2011-2012 |
01 |
| 004 |
15805184 |
PANEL, R/END TR FIN (INCLS 3, 8) (EBONY) |
ST1 (03-53) (AR9, 27I) (EXC AJ2) |
2011-2012 |
01 |
| 005 |
15862307 |
RETAINER, R/CMPT R/END TR FIN PNL (EBONY) |
ST1 (03-53) (27I) |
2007-2012 |
04 |
| 006 |
15986623 |
GUIDE, R/SEAT SHLDR BELT INTER (PART OF 7) (GRAPHITE) (CHILD COMFORT GUIDE) |
ST1 (43-53) (27I) |
2007-2012 |
02 |
| 007 |
15805179 |
PANEL, BODY SI RR LWR TR (INCLS 6, 13) (EBONY) |
ST1 (53) (AJ2, 27I) |
2007-2012 |
01 |
| 007 |
15805180 |
PANEL, BODY SI RR LWR TR (INCLS 6, 13) (EBONY) |
ST1 (53) (AJ2, 27I) |
2007-2012 |
01 |
| 008 |
19256941 |
COVER, CHILD ST TOP STRP BRKT ACC OPG (PART OF 4) (EBONY) |
ST1 (03-53) (27I) |
2007-2012 |
01 |
| 009 |
15252457 |
TRIM, BODY H/PLR (INCLS 10) (EBONY) |
ST1 (27I) |
2007-2012 |
01 |
| 009 |
15252458 |
TRIM, BODY H/PLR (INCLS 10) (EBONY) |
ST1 (27I) |
2007-2012 |
01 |
| 010 |
11517729 |
RETAINER, GARNISH MOLDING TYPE, 12.0X16.0X2.5, FITS HOLE 5.75X6.25MM, SPR STL, ZC (PART OF 9) (8.950) |
|
2004-2012 |
02 |
| 011 |
97022017 |
CLIP, FRT S/D SILL TR PLT (PART OF 12) (16.7MM HIGH) (TYPE D) (16.165) |
ST1 (53) |
2004-2012 |
12 |
| 012 |
15876445 |
PLATE, FRT S/D SILL TR (INCLS 11) (EBONY) |
ST1 (53) (27I) |
2010-2012 |
01 |
| 012 |
15876446 |
PLATE, FRT S/D SILL TR (INCLS 11) (EBONY) |
ST1 (53) (27I) |
2010-2012 |
01 |
| 013 |
11609864 |
RETAINER, R/WDO G/MLDG (PART OF 7) (8.00MM DIA HOLE) (PLASTIC TREE) (11.120) |
ST1 (53) (AJ2) |
2004-2012 |
02 |
| 014 |
15805189 |
MOLDING, W/S SI GARN (INCLS 15, 17) (EBONY) |
ST1 (ASF, 27I) |
2007-2012 |
01 |
| 014 |
15910385 |
MOLDING, W/S SI GARN (INCLS 15, 17) (EBONY) |
ST1 (ASF, 27I) |
2007-2012 |
01 |
| 015 |
|
COVER, MOLDING (PART OF 14) |
|
2004-2012 |
|
| 016 |
11517342 |
BOLT, HEX HD, W/FL WA, M6X1X20, 9.53 THD, 17 O.D., P-PT, 9.8, 6280M (W/S SI G/MLDG) |
(ASF) |
2004-2012 |
02 |
| 017 |
11588650 |
CLIP, 12X14X16.6, GM4345M (PART OF 14, 18) |
|
2004-2012 |
06 |
| 018 |
15805186 |
MOLDING, W/S SI GARN (INCLS 17) (EBONY) |
ST1 (27I) (EXC ASF) |
2007-2012 |
01 |
| 018 |
15805187 |
MOLDING, W/S SI GARN (INCLS 17) (EBONY) |
ST1 (27I) (EXC ASF) |
2007-2012 |
01 |
| 019 |
11588650 |
CLIP, 12X14X16.6, GM4345M (PART OF 20) |
|
2004-2012 |
02 |
| 020 |
25955398 |
PANEL, BODY SI RR LWR TR (INCLS 19) (EBONY) |
ST1 (53) (27I) (EXC AJ2) |
2009-2012 |
01 |
| 020 |
25955399 |
PANEL, BODY SI RR LWR TR (INCLS 19) (EBONY) |
ST1 (53) (27I) (EXC AJ2) |
2009-2012 |
01 |
