| Поз. | Номер | Описание | Применение | Номенклатура | Кол-во |
| 001 |
97022017 |
CLIP, FRT S/D TR RET (PART OF 2, 13) (16.7MM HIGH) (TYPE D) |
ST1 (53) |
2012-2012 |
04 |
| 002 |
15136543 |
PANEL, FRT S/D UPR FRT TR (INCLS 1) (EBONY) |
ST1 (27I) |
2007-2012 |
01 |
| 002 |
15136544 |
PANEL, FRT S/D UPR FRT TR (INCLS 1) (EBONY) |
ST1 (27I) |
2007-2012 |
01 |
| 003 |
15127374 |
DEFLECTOR, FRT S/D WAT |
ST1 (A31) |
2004-2012 |
01 |
| 003 |
15127375 |
DEFLECTOR, FRT S/D WAT |
ST1 (A31) |
2004-2012 |
01 |
| 004 |
15170062 |
WEATHERSTRIP, FRT S/D WDO (PART OF 13) (INNER) |
ST1 |
2004-2012 |
01 |
| 004 |
15170063 |
WEATHERSTRIP, FRT S/D WDO (PART OF 13) (INNER) |
ST1 |
2004-2012 |
01 |
| 005 |
11508765 |
SCREW, TORX, W/ RD WA, M4.2X1.41X16, 11.1 O.D., STL, NIOR (FRT S/D T/PNL) |
|
2004-2012 |
04 |
| 006 |
19131156 |
PLATE, FRT S/D ACSRY SW MT (INCLS 7) |
ST1 (03-53) (A31) |
2007-2012 |
01 |
| 007 |
|
CLIP, SW PLT TO DR TR PNL (PART OF 6, 16) |
|
2004-2012 |
|
| 008 |
15205243 |
SWITCH, O/S RR VIEW MIR R/CON |
ST1 (A31) |
2004-2012 |
01 |
| 009 |
15119572 |
BOLT, FRT S/D A/RST SW MT PLT (16.165) |
ST1 |
2004-2012 |
03 |
| 010 |
25779766 |
SWITCH, DR LK SI WDO |
ST1 (03-53) (A31) |
2007-2012 |
01 |
| 011 |
11509231 |
SCREW, RD HD C/R TAP, M4.2X1.41X13.0, GM6010M STL, GM813M NICKEL ORGANIC (PART OF 13) |
|
2004-2012 |
03 |
| 012 |
15187058 |
SPEAKER, RDO FRT S/D (1LH, 1RH) (PART OF 13) (LITTLE ONE ON UPPER PART OF DOOR) (ACDelco #15187058) |
ST1 (YC3) |
2004-2012 |
02 |
| 013 |
22759849 |
PANEL, FRT S/D TR (INCLS 1, 4, 11, 12, 15) (CASHMERE) |
ST1 (A31, YC3, 31J, 313) |
2007-2012 |
01 |
| 013 |
22759852 |
PANEL, FRT S/D TR (INCLS 1, 4, 11, 12, 15) (CASHMERE) |
ST1 (A31, YC3, 31J, 313) |
2007-2012 |
01 |
| 013 |
22759853 |
PANEL, FRT S/D TR (INCLS 1, 4, 11, 12, 15) (EBONY) |
ST1 (A31, YC3, 19J, 193, 92W) |
2009-2012 |
01 |
| 013 |
22759850 |
PANEL, FRT S/D TR (INCLS 1, 4, 11, 12, 15) (EBONY) |
ST1 (A31, YC3, 19J, 193, 92W) |
2008-2012 |
01 |
| 014 |
15186382 |
BEZEL, FRT S/D I/S HDL (EBONY) |
ST1 (27I) |
2009-2012 |
01 |
| 014 |
15186383 |
BEZEL, FRT S/D I/S HDL (EBONY) |
ST1 (27I) |
2009-2012 |
01 |
| 015 |
|
DEFLECTOR, AUX FRT S/D WAT (PART OF 13) |
|
2004-2012 |
|
| 016 |
19180793 |
PLATE, DR LK SW MT (INCLS 7) (INCLS CLIP) (LESS SWITCH) |
ST1 (A31) |
2004-2012 |
01 |
| 017 |
15205244 |
SWITCH, DR LK SI WDO |
ST1 (A31) |
2010-2012 |
01 |
| 018 |
19177870 |
DOOR, FRT SI (10.351) |
ST1 (43-53) (ZQ8, Z71, Z85) |
2004-2012 |
01 |
| 018 |
89025478 |
DOOR, FRT SI (W/O HINGES) |
ST1 (43-53) (ZQ8, Z71, Z85) |
2004-2012 |
01 |
| 019 |
11570654 |
NUT, FRT S/D TR PNL (4.2 X 1.41) (PUSH-IN NUT) (FITS 8.75 SQ HOLE) (9.665) |
ST1 |
2004-2012 |
04 |
| 020 |
15900025 |
HANDLE, FRT S/D I/S (CHROME) |
ST1 (27I) |
2007-2012 |
01 |
| 020 |
15900026 |
HANDLE, FRT S/D I/S (CHROME) |
ST1 (27I) |
2007-2012 |
01 |
| 021 |
11570654 |
NUT, FRT S/D I/S HDL (4.2 X 1.41) (PUSH-IN NUT) (FITS 8.75 SQ HOLE) (9.665) |
ST1 |
2010-2012 |
02 |
| 022 |
11508765 |
SCREW, TORX, W/ RD WA, M4.2X1.41X16, 11.1 O.D., STL, NIOR (FRT S/D I/S HDL BZL) |
|
2004-2012 |
02 |
