| Поз. | Номер | Описание | Применение | Номенклатура | Кол-во |
| 001 |
19133210 |
SEAL, INPUT SHF (ACDelco #19133210) |
T1 (MA5) |
2004-2012 |
01 |
| 002 |
89048233 |
CASE, TRANS FRT (INCLS 7, 63, 64, 70-72, 295, 296) |
T1 (MA5) |
2004-2012 |
01 |
| 007 |
|
CASE, TRANS INTER (PART OF 2) |
|
2004-2012 |
|
| 010 |
89048301 |
EXTENSION, TRANS (INCLS 65, 297, 523) |
T1 (MA5) |
2004-2012 |
01 |
| 021 |
89048307 |
SEAL, MAIN SHF RR |
T1 (MA5) |
2004-2012 |
01 |
| 023 |
89048311 |
STUD, TRANS EXTN |
T1 (MA5) |
2004-2012 |
02 |
| 024 |
89048312 |
BOLT, TRANS EXTN |
T1 (MA5) |
2004-2012 |
08 |
| 025 |
89048248 |
PLUG, TRANS OIL DRN |
T1 (MA5) |
2004-2012 |
01 |
| 026 |
89048245 |
GASKET, TRANS OIL DRN PLUG (ACDelco #89048245) |
T1 (MA5) |
2004-2012 |
01 |
| 027 |
89048248 |
PLUG, TRANS OIL FIL |
T1 (MA5) |
2004-2012 |
01 |
| 028 |
89048245 |
GASKET, TRANS OIL FILL PLUG (ACDelco #89048245) |
T1 (MA5) |
2004-2012 |
01 |
| 030 |
89048231 |
RETAINER, INPUT SHF BRG (4.105) |
T1 (MA5) |
2004-2012 |
01 |
| 031 |
89048246 |
BOLT, INPUT SHF BRG RET |
T1 (MA5) |
2004-2012 |
08 |
| 031 |
89048246 |
BOLT, INPUT SHF BRG RET (4.422) |
T1 (MA5) |
2004-2012 |
08 |
| 035 |
89048241 |
RETAINER, MAIN SHF RR BRG |
T1 (MA5) |
2004-2012 |
01 |
| 036 |
19132870 |
BOLT, FRT MAIN SHF RR BRG RET |
T1 (MA5) |
2004-2012 |
04 |
| 040 |
89048291 |
BOLT, M/TRNS FLUID BFL (M6X1.0X16) |
ST1 (MA5) |
2004-2012 |
02 |
| 041 |
89048559 |
BOLT, M/TRNS FLUID BFL (M8X1.25X20) |
ST1 (MA5) |
2004-2012 |
02 |
| 042 |
89048276 |
BAFFLE, M/TRNS FLUID |
T1 (MA5) |
2004-2012 |
01 |
| 043 |
89048310 |
NOZZLE, M/TRNS OIL (4.105) |
T1 (MA5) |
2004-2012 |
01 |
| 050 |
89048229 |
HOUSING, CLU |
T1 (MA5) |
2007-2012 |
01 |
| 051 |
89048249 |
BOLT, CLU HSG (M10X1.25X45) (W/O SEALER) |
ST1 (MA5) |
2004-2012 |
07 |
| 052 |
89048247 |
BOLT, CLU HSG (M10X1.25X45) (W/SEALER) |
ST1 (MA5) |
2004-2012 |
02 |
| 063 |
89048238 |
PLUG, SHFT SHF HOLE (LARGE) (PART OF 2) (AT FRT CASE) |
ST1 (MA5) |
2004-2012 |
01 |
| 064 |
89048239 |
PLUG, SHFT SHF HOLE (SMALL) (PART OF 2) (AT FRT CASE) |
ST1 (MA5) |
2004-2012 |
03 |
| 065 |
89048308 |
PLUG, SHFT SHF HOLE (PART OF 10) (AT EXTENSION HSG) (ACDelco #89048308) |
T1 (MA5) |
2004-2012 |
01 |
| 070 |
89048237 |
PIN, TRANS INTER CASE LOC (FRT/RR) (PART OF 2) |
T1 (MA5) |
2004-2012 |
04 |
| 071 |
89048237 |
PIN, TRANS INTER CASE LOC (FRT/RR) (PART OF 2) |
T1 (MA5) |
2004-2012 |
04 |
| 072 |
89048236 |
PIN, TRANS CASE LOC (PART OF 2) |
T1 (MA5) |
2004-2012 |
02 |
| 080 |
89048242 |
MAGNET, TRANS CHIP COLLECTOR |
T1 (MA5) |
2004-2012 |
01 |
| 091 |
89048252 |
RESTRICTOR, M/TRNS CONT LVR |
T1 (MA5) |
2004-2012 |
01 |
| 092 |
89048272 |
PIN, M/TRNS CONT LVR RSTR RET |
T1 (MA5) |
2004-2012 |
01 |
| 093 |
89048273 |
PLUG, M/TRNS CONT LVR RSTR RET PIN HOLE (4.311) |
T1 (MA5) |
2004-2012 |
01 |
| 295 |
|
BUSHING, SHFT SHF (PART OF 2) |
|
2004-2012 |
|
| 296 |
|
BUSHING, SHFT SHF (PART OF 2) |
|
2004-2012 |
|
| 297 |
|
BUSHING, TRANS EXTN (PART OF 10) |
|
2004-2012 |
|
| 310 |
89048415 |
SWITCH, PARK/NEU POSN B/U LP (INCLS 311) (4.054) (ACDelco #D2260C) |
T1 (MA5) |
2004-2012 |
01 |
| 310 |
89048415 |
SWITCH, PARK/NEU POSN B/U LP (INCLS 311) (ACDelco #D2260C) |
T1 (MA5) |
2004-2012 |
01 |
| 311 |
|
GASKET, M/TRNS NEU POSN SW (PART OF 310) |
|
2004-2012 |
|
| 312 |
89048419 |
BOLT, TRANS WRG HARN BRKT (M10X1.25X16) |
T1 (MA5, JJA) |
2004-2012 |
01 |
| 313 |
89048416 |
CLAMP, M/TRNS WRG HARN |
T1 (MA5) |
2004-2012 |
01 |
| 315 |
89048417 |
CLAMP, M/TRNS CONT SHF ADAP (LOWER) |
ST1 (MA5) |
2004-2012 |
02 |
| 316 |
89048418 |
CLAMP, M/TRNS CONT SHF ADAP (UPPER) |
ST1 (MA5) |
2004-2012 |
01 |
| 520 |
25890709 |
LEVER, M/TRNS CONT |
T1 (MA5) (EXC D06) |
2004-2012 |
01 |
| 520 |
15112814 |
LEVER, M/TRNS CONT |
T1 (MA5, D06) |
2004-2012 |
01 |
| 521 |
89048274 |
BOLT, M/TRNS CONT LVR HSG |
T1 (MA5) |
2004-2012 |
04 |
| 522 |
89048270 |
GASKET, SHFT CONT HSG |
T1 (MA5) |
2004-2012 |
01 |
| 523 |
89048305 |
PIN, TRANS EXTN LOC (PART OF 10) (4.104) |
ST1 (MA5) |
2004-2012 |
02 |
