| Поз. | Номер | Описание | Применение | Номенклатура | Кол-во |
| 100 |
89048408 |
SHAFT, INPUT |
T1 (MA5) |
2004-2012 |
01 |
| 101 |
89048120 |
RING KIT, INPUT SHF BRG RET (2.10MM-2.40MM THK) (CONTAINS 7 RINGS) (4.408) (ACDelco #89048120) |
T1 (MA5) |
2004-2012 |
01 |
| 102 |
89048403 |
RING, INPUT SHF BRG RET |
T1 (MA5) |
2004-2012 |
01 |
| 103 |
89048351 |
BEARING, INPUT SHF |
T1 (MA5) |
2004-2012 |
01 |
| 110 |
19132811 |
GEAR, 1ST |
T1 (MA5) |
2008-2012 |
01 |
| 113 |
89048348 |
BEARING, 1ST GR |
T1 (MA5) |
2004-2012 |
01 |
| 114 |
89048343 |
SPACER, 1ST GR BRG RLR |
T1 (MA5) |
2004-2012 |
01 |
| 115 |
89048344 |
PIN, 1ST GR THR WA LOC |
T1 (MA5) |
2004-2012 |
01 |
| 116 |
89048334 |
WASHER, 1ST GR THR |
T1 (MA5) |
2004-2012 |
01 |
| 120 |
89048406 |
GEAR, 2ND |
T1 (MA5) |
2004-2012 |
01 |
| 123 |
89048349 |
BEARING, 2ND GR |
T1 (MA5) |
2004-2012 |
01 |
| 130 |
89048407 |
GEAR, 3RD (39 TEETH) |
T1 (MA5) |
2004-2012 |
01 |
| 130 |
19132887 |
GEAR, 3RD |
T1 (LLR, MA5) |
2011-2012 |
01 |
| 133 |
89048347 |
BEARING, 3RD GR (ACDelco #89048347) |
T1 (MA5) |
2004-2012 |
01 |
| 150 |
89048410 |
GEAR, 5TH |
T1 (MA5) |
2004-2012 |
01 |
| 170 |
19132797 |
GEAR, REV |
T1 (MA5) |
2004-2012 |
01 |
| 180 |
89048117 |
RING KIT, MAIN SHF RR BRG RET (ACDelco #89048117) |
T1 (MA5) |
2004-2012 |
01 |
| 191 |
89048345 |
BEARING, MAIN SHF FRT |
T1 (MA5) |
2004-2012 |
01 |
| 193 |
89048350 |
BEARING, RR OUTPUT MAIN SHF RR |
T1 (MA5) |
2004-2012 |
01 |
| 194 |
89048402 |
RING, MAIN SHF RR BRG RET |
T1 (MA5) |
2004-2012 |
01 |
| 195 |
89048332 |
SHAFT, MAIN |
T1 (MA5) |
2004-2012 |
01 |
| 201 |
89048119 |
RING KIT, 1ST 2ND GR SYN HUB RET (2.30MM-2.60MM THK) (CONTAINS 7 RINGS) (ACDelco #89048119) |
T1 (MA5) |
2004-2012 |
01 |
| 203 |
89048118 |
RING KIT, 3RD 4TH GR SYN RET (4.416) (ACDelco #89048118) |
T1 (MA5) |
2004-2012 |
01 |
| 212 |
89048354 |
SPRING, 1ST 2ND GR SYN |
T1 (MA5) |
2004-2012 |
03 |
| 213 |
89059741 |
INSERT, 1ST 2ND GR SYN |
T1 (MA5) |
2004-2012 |
03 |
| 215 |
89048335 |
HUB, 1ST 2ND GR SYN (4.380) |
T1 (MA5) |
2004-2012 |
01 |
| 216 |
|
RING, 1ST GR OTR BLOCKING (PART OF 219) |
|
2004-2012 |
|
| 217 |
|
RING, 1ST GR INTER BLOCKING (PART OF 219) |
|
2004-2012 |
|
| 218 |
|
RING, 1ST GR INR BLOCKING (PART OF 219) |
|
2004-2012 |
|
| 219 |
19180579 |
RING, 1ST GR BLOCKING (INCLS 216-218) |
T1 (LLV, MA5) |
2009-2012 |
01 |
| 226 |
|
RING, 2ND GR OTR BLOCKING (PART OF 229) |
|
2004-2012 |
|
| 227 |
|
RING, 2ND GR INTER BLOCKING (PART OF 229) |
|
2004-2012 |
|
| 228 |
|
RING, 2ND GR INR BLOCKING (PART OF 229) |
|
2004-2012 |
|
| 229 |
19180579 |
RING, 2ND GR BLOCKING (INCLS 226-228) |
T1 (MA5) |
2010-2012 |
01 |
| 232 |
89048338 |
INSERT, 3RD 4TH GR SYN |
T1 (MA5) |
2004-2012 |
03 |
| 233 |
89048354 |
SPRING, 3RD 4TH GR SYN |
T1 (MA5) |
2004-2012 |
03 |
| 234 |
89048337 |
SLEEVE, 3RD 4TH GR SYN |
T1 (MA5) |
2004-2012 |
01 |
| 235 |
89059575 |
HUB, 3RD 4TH GR SYN (ACDelco #89059575) |
T1 (MA5) |
2005-2012 |
01 |
| 236 |
|
RING, 3RD GR OTR BLOCKING (PART OF 239) |
|
2004-2012 |
|
| 237 |
|
RING, 3RD GR INTER BLOCKING (PART OF 239) |
|
2004-2012 |
|
| 238 |
|
RING, 3RD GR INR BLOCKING (PART OF 239) |
|
2004-2012 |
|
| 239 |
89059573 |
RING, 3RD GR BLOCKING (INCLS 236-238) |
T1 (MA5) |
2006-2012 |
01 |
| 239 |
19132881 |
RING, 3RD GR BLOCKING (INCLS 236-238) |
T1 (LLR, MA5) |
2012-2012 |
01 |
| 246 |
89048340 |
RING, 4TH GR BLOCKING |
T1 (MA5) |
2004-2012 |
01 |
