| Поз. | Номер | Описание | Применение | Номенклатура | Кол-во |
| 001 |
19130171 |
INLET, AIR (INCLS 2-6, 8, 9, 12, 14) |
DW29 |
2008-2011 |
01 |
| 002 |
|
SEAL, INLET (PART OF 1) |
|
2007-2011 |
|
| 003 |
|
VALVE, INLET (PART OF 1) |
|
2007-2011 |
|
| 004 |
|
CASE (PART OF 1) |
|
2007-2011 |
|
| 005 |
25640395 |
NUT, AIR INL (PART OF 1) (M6) (WELD NUT) (UNTHREADED) (9.647) |
DW29 |
2007-2011 |
04 |
| 006 |
25770699 |
BOLT, AIR INL (PART OF 1) (M4X141X16) (SCREW-PAN HEAD C/R) (9.280) |
DW29 |
2010-2011 |
08 |
| 007 |
13501703 |
MODULE, BLO MOT CONT (9.169) (ACDelco #15-81638) |
DW29 |
2007-2011 |
01 |
| 008 |
25770699 |
BOLT, BLO MOT CONT MDL (PART OF 1) (M4X141X16) (SCREW-PAN HEAD C/R) (9.280) |
DW29 |
2007-2011 |
02 |
| 009 |
11562032 |
BOLT, BLO MOT (PART OF 1) (5MM X 16 STAR TYPE4) (HEX HEAD) (8.977) |
DW29 |
2007-2011 |
03 |
| 010 |
19130001 |
MOTOR, BLO (W/IMPLR) (ACDelco #15-80930) |
DW29 |
2008-2011 |
01 |
| 010 |
19130001 |
MOTOR, BLO (W/IMPLR) (8.855) (ACDelco #15-80930) |
DW29 |
2008-2011 |
01 |
| 011 |
89023393 |
HARNESS, HTR A/C CONT WRG |
D29 |
2007-2011 |
01 |
| 012 |
|
LEVER (PART OF 1) |
|
2007-2011 |
|
| 013 |
89023395 |
ACTUATOR, AIR INL VLV (ACDelco #15-73026) |
DW29 |
2008-2011 |
01 |
| 014 |
|
SEAL, INLET (PART OF 1) |
|
2007-2011 |
|
| 015 |
25770699 |
BOLT, AIR INL VLV ACTR (M4X141X16) (SCREW-PAN HEAD C/R) |
DW29 |
2007-2011 |
03 |
