| Поз. | Номер | Описание | Применение | Номенклатура | Кол-во |
| 002 |
11561674 |
БОЛТ, HEX W/FL WA, M6X1X20, 12 THD, 24 OD, 9.8, GMW3359, M-PT (F/FLR CNSL)
|
2005-2010 |
08 |
|
| 003 |
11589183 |
ГАЙКА, PUSH IN, W/SEAL, 4.2X1.41, 6.35-6.48 SQ HL, 9.5 SQ HD, 0.787-2.765 PNL THK, NYL (ЧАСТЬ OF 1) |
|
2005-2010 |
05 |
| 004 |
25907846 |
HARNESS, F/FLR CNSL WRG |
DW (KA6, UY5, YQ4, YQ6, YQ7) |
2008-2010 |
01 |
| 005 |
25726442 |
DUCT, F/FLR CNSL RR AIR |
D29 |
2005-2010 |
01 |
| 006 |
11508765 |
SCREW, TORX, W/ RD WA, M4.2X1.41X16, 11.1 O.D., STL, NIOR (ЧАСТЬ OF 1) |
|
2005-2010 |
04 |
| 007 |
11589015 |
БОЛТ, HWH W/FL WA M4.2X1.41X20, 12.5 O.D., DOG PT, 6010M, 7253M (ЧАСТЬ OF 1)
|
2005-2010 |
02 |
|
| 008 |
11609462 |
SCREW, M4.2X1.41X13, GMW4205 (ЧАСТЬ OF 1) |
|
2005-2010 |
17 |
| 009 |
03530297 |
ГАЙКА, HFH, M6X1, 5.85THK, 14.2 O.D., 10, ZOR (F/FLR CNSL FRT SUPT) |
|
2005-2010 |
02 |
| 010 |
25762739 |
SUPPORT, F/FLR CNSL FRT |
D29 |
2005-2010 |
01 |
| 011 |
25536302 |
ГАЙКА, F/FLR COMPT STOR TRAY (4.2 X 1.41) (TAPPING NUT) (3.430)
| D29 |
2005-2010 |
03 |
|
| 012 |
11589015 |
БОЛТ, HWH W/FL WA M4.2X1.41X20, 12.5 O.D., DOG PT, 6010M, 7253M (AIR DISTR DUCT)
|
2005-2010 |
01 |
|
| 014 |
11609462 |
SCREW, M4.2X1.41X13, GMW4205 (ЧАСТЬ OF 1) |
D29 |
2005-2010 |
11 |
| 015 |
15138940 |
ПЕПЕЛЬНИЦА, F/FLR CNSL RR (INCLS 13, 16, 17) (GRAY) |
D29 (02K, 4BF) (EXC DT4) |
2010-2010 |
01 |
| 015 |
15138941 |
ПЕПЕЛЬНИЦА, F/FLR CNSL RR (INCLS 13, 16, 17) (EBONY) |
D29 (01G, 4AL) (EXC DT4) |
2010-2010 |
01 |
| 015 |
15138942 |
ПЕПЕЛЬНИЦА, F/FLR CNSL RR (INCLS 13, 16, 17) (CASHMERE) |
D29 (01D, 4BH) (EXC DT4) |
2010-2010 |
01 |
| 015 |
15138949 |
ПЕПЕЛЬНИЦА, F/FLR CNSL RR (INCLS 13, 16, 17) (GRAY) |
D29 (DT4, 02K, 4BF) |
2010-2010 |
01 |
| 015 |
15138950 |
ПЕПЕЛЬНИЦА, F/FLR CNSL RR (INCLS 13, 16, 17) (EBONY) |
D29 (DT4, 01G, 4AL) |
2010-2010 |
01 |
| 015 |
15138951 |
ПЕПЕЛЬНИЦА, F/FLR CNSL RR (INCLS 13, 16, 17) (CASHMERE) |
D29 (DT4, 01D, 4BH) |
2010-2010 |
01 |
| 016 |
|
DOOR, F/FLR CNSL ПЕПЕЛЬНИЦА (ЧАСТЬ OF 15) |
|
2005-2010 |
|
| 017 |
25770278 |
ШЛАНГИ, F/FLR CNSL ПЕПЕЛЬНИЦА (ЧАСТЬ OF 15) (BLACK) |
D29 |
2005-2010 |
01 |
| 018 |
11516141 |
LIGHTER, CIG (BLACK) (W/SMALL, PLASTIC KNOB END 14.0MM)
| D |
2005-2010 |
01 |
|
| 020 |
89044067 |
BRACKET, F/FLR CNSL ACSRY BRKT |
D29 |
2005-2010 |
01 |
| 021 |
25797586 |
SPEAKER, RDO F/FLR CNSL (3.5) (9.650) (ACDelco #25797586) |
DW (DT4, IL3, KA6, UY5, W21, YQ4, YQ6, YQ7) |
2010-2010 |
01 |
| 021 |
25798963 |
SPEAKER, RDO F/FLR CNSL (3.5) (ACDelco #25798963) |
DW (DT4, IL3, KA6, UY5, W21, YQ4, YQ6, YQ7) |
2010-2010 |
01 |
| 022 |
89044028 |
COVER, F/FLR CNSL RR (GRAY) (PO ШЛАНГИ ASM) |
D29 (02K) (EXC DT4) |
2010-2010 |
01 |
| 022 |
89044029 |
COVER, F/FLR CNSL RR (EBONY) (PO ШЛАНГИ ASM) |
D29 (01G) |
2010-2010 |
01 |
| 022 |
89044030 |
COVER, F/FLR CNSL RR (CASHMERE) (PO ШЛАНГИ ASM) |
DW (01D) |
2010-2010 |
01 |
| 023 |
25770284 |
BEZEL, RDO RR SPKR GRL (GRAY) |
D29 (02K) |
2010-2010 |
01 |
| 023 |
25770285 |
BEZEL, RDO RR SPKR GRL (EBONY) |
D29 (01G) |
2010-2010 |
01 |
| 023 |
25770286 |
BEZEL, RDO RR SPKR GRL (CASHMERE) |
D29 (01D) |
2010-2010 |
01 |
| 024 |
25741416 |
CONTROL, AUX HTR КОНДИЦИОНЕР (9.273) (ACDelco #15-73011)
| D29 (KA6) |
2005-2010 |
01 |
|
| 024 |
25741416 |
CONTROL, AUX HTR КОНДИЦИОНЕР (ACDelco #15-73011)
| D29 (KA6) |
2005-2010 |
01 |
|
| 025 |
11588650 |
CLIP, 12X14X16.6, GM4345M (ЧАСТЬ OF 1)
|
2005-2010 |
06 |
|
| 026 |
25770289 |
OUTLET, AUX FLR AIR (EBONY) |
D |
2005-2010 |
01 |
| 027 |
|
BRACKET, F/FLR CNSL (ЧАСТЬ OF 1) |
|
2005-2010 |
|
| 028 |
11517515 |
БОЛТ-HFH, M6X1X10, THD 8.5, OD 14.2, 9.8, GM6280, HDR PT. (ЧАСТЬ OF 1) |
|
2005-2010 |
02 |
| 029 |
11502553 |
ГАЙКА, STAMPED, M6.3 STUD, SELF THD, STL, PC (ЧАСТЬ OF 1)
|
2005-2010 |
04 |
|
| 031 |
25666549 |
HARNESS, AUDIO/VIDEO WRG (9.656) (ACDelco #25666549) |
D29 |
2005-2010 |
01 |
| 032 |
89044023 |
TRAY, F/FLR CNSL A/RST STOR (ЧАСТЬ OF 1) (BLACK) |
D29 (UX8) |
2005-2010 |
01 |
| 033 |
|
HINGE, F/FLR CNSL COMPT DR (ЧАСТЬ OF 34) |
|
2005-2010 |
|
| 034 |
10381490 |
COMPARTMENT, F/FLR CNSL (INCLS 33, 35-37) (GRAY) (ARMREST) |
D29 (02K) |
2010-2010 |
01 |
| 034 |
10381491 |
COMPARTMENT, F/FLR CNSL (INCLS 33, 35-37) (EBONY) (ARMREST) |
D29 (01G) (EXC W21) |
2010-2010 |
01 |
| 034 |
10381492 |
COMPARTMENT, F/FLR CNSL (INCLS 33, 35-37) (CASHMERE) (ARMREST) |
D29 (01D) (EXC W21) |
2010-2010 |
01 |
| 034 |
15138882 |
COMPARTMENT, F/FLR CNSL (INCLS 33, 35-37) (GRAY) (ARMREST) (COMPONENT LEVEL) |
D29 (02K) |
2010-2010 |
01 |
| 034 |
15138883 |
COMPARTMENT, F/FLR CNSL (INCLS 33, 35-37) (EBONY) (ARMREST) (COMPONENT LEVEL)
| D29 (01G) |
2010-2010 |
01 |
|
| 034 |
15138884 |
COMPARTMENT, F/FLR CNSL (INCLS 33, 35-37) (CASHMERE) (ARMREST) (COMPONENT LEVEL) |
D29 (01D) |
2010-2010 |
01 |
| 034 |
15774492 |
COMPARTMENT, F/FLR CNSL (INCLS 33, 35-37) (EBONY) (ARMREST) (COMPONENT LEVEL) |
DW (W21, 01G) |
2010-2010 |
01 |
| 034 |
15858574 |
COMPARTMENT, F/FLR CNSL (INCLS 33, 35-37) (COCOКОНДИЦИОНЕРASHMERE) |
D29 (W21, 01D) |
2010-2010 |
01 |
| 035 |
25737728 |
ПРУЖИНА, F/FLR RR CNSL A/RST LAT (ЧАСТЬ OF 34) |
D |
2005-2010 |
01 |
| 036 |
25737727 |
LATCH, F/FLR RR CNSL A/RST (ЧАСТЬ OF 34) (PEWTER) |
D29 |
2005-2010 |
01 |
| 037 |
22611883 |
BUMPER, F/FLR CNSL COMPT DR (ЧАСТЬ OF 34) (BLACK) (6.6 DIA X 4.7 H) (10.263) |
D29 |
2005-2010 |
02 |
| 039 |
11508765 |
SCREW, TORX, W/ RD WA, M4.2X1.41X16, 11.1 O.D., STL, NIOR (F/FLR CNSL RR BRKT) |
|
2005-2010 |
04 |
| 041 |
15930711 |
ДЕРЖАТЕЛЬ, F/FLR CNSL CUP (INCLS 42-45, 47) (GRAY) |
D29 (02K) |
2010-2010 |
01 |
| 041 |
15930712 |
ДЕРЖАТЕЛЬ, F/FLR CNSL CUP (INCLS 42-45, 47) (EBONY) |
D29 (01G, 4AL, 4BH) |
2010-2010 |
01 |
| 041 |
15930713 |
ДЕРЖАТЕЛЬ, F/FLR CNSL CUP (INCLS 42-45, 47) (CASHMERE) |
D29 (01D, 4BH) |
2010-2010 |
01 |
| 042 |
11589015 |
БОЛТ, HWH W/FL WA M4.2X1.41X20, 12.5 O.D., DOG PT, 6010M, 7253M (ЧАСТЬ OF 1, 41)
|
2005-2010 |
02 |
|
| 043 |
25749206 |
SWITCH, HAZARD WRNG (ЧАСТЬ OF 1, 41) (EBONY) |
DW (DT4, UY5, YQ6, YQ7, 133) (EXC KA6) |
2010-2010 |
01 |
| 044 |
25749204 |
SWITCH, ELEK TRACT CONT (ЧАСТЬ OF 1, 41) (ACDelco #25749204) |
D29 |
2005-2010 |
01 |
| 047 |
25770235 |
LINER, F/FLR CNSL CUP HLDR (ЧАСТЬ OF 1, 41) (EBONY) |
D29 |
2005-2010 |
01 |
| 048 |
15774496 |
RETAINER, F/FLR CNSL TRANS SHFT OPG TR PLT (EBONY) |
DW (W21, 4AL) |
2010-2010 |
01 |
| 048 |
15858570 |
RETAINER, F/FLR CNSL TRANS SHFT OPG TR PLT (CASHMERE) |
DW (W21, 4AC) |
2010-2010 |
01 |
| 048 |
15930375 |
RETAINER, F/FLR CNSL TRANS SHFT OPG TR PLT (GRAY) |
DW (4BF) |
2010-2010 |
01 |
| 048 |
15930376 |
RETAINER, F/FLR CNSL TRANS SHFT OPG TR PLT (EBONY) |
DW (4AL) (EXC W21) |
2010-2010 |
01 |
| 048 |
15930377 |
RETAINER, F/FLR CNSL TRANS SHFT OPG TR PLT (CASHMERE) |
DW (4BG) (EXC W21) |
2010-2010 |
01 |
| 048 |
25827670 |
RETAINER, F/FLR CNSL TRANS SHFT OPG TR PLT (GRAY) |
DW29 (4BF) |
2010-2010 |
01 |
| 048 |
25827671 |
RETAINER, F/FLR CNSL TRANS SHFT OPG TR PLT (EBONY) |
DW29 (4AL) (EXC W21) |
2010-2010 |
01 |
| 048 |
25827672 |
RETAINER, F/FLR CNSL TRANS SHFT OPG TR PLT (LT CASHMERE) |
DW29 (4BG) (EXC W21) |
2010-2010 |
01 |
| 049 |
15858572 |
PLATE, F/FLR CNSL TRANS SHFT OPG TR (SADDLE OLIVE ASH BURL) |
DW29 (VVU) |
2010-2010 |
01 |
| 049 |
15867655 |
PLATE, F/FLR CNSL TRANS SHFT OPG TR (ALUMINUM BRUSH) |
DW |
2010-2010 |
01 |
| 049 |
15930378 |
PLATE, F/FLR CNSL TRANS SHFT OPG TR (FIG SEPPELE) (WOOD) |
DW (4AL, 4BF, 4BG) |
2010-2010 |
01 |
| 050 |
10125439 |
RIVET, FLAT HD, 3 LEG EXPANSION, M4.8 SHAFT, 23.5 LG, 9.8 O.D., AL (ЧАСТЬ OF 1)
|
2005-2010 |
02 |
|
| 051 |
89023396 |
DUCT, AIR DISTR |
D29 |
2005-2010 |
01 |
| 054 |
25770288 |
PLATE, F/FLR CNSL CVR TR |
DW (EXC KA6) |
2005-2010 |
01 |
| 055 |
25770287 |
TRAY, F/FLR CNSL STOR |
D29 |
2005-2010 |
01 |
| 056 |
|
BRACKET, F/FLR CNSL (ЧАСТЬ OF 1) |
|
2005-2010 |
|
