| Поз. | Номер | Описание | Применение | Номенклатура | Кол-во |
| 001 |
12576262 |
GASKET, EXH MANIF
| DW (LLT, MYB, MX0, MX7) |
2010-2010 |
01 |
|
| 001 |
12608475 |
GASKET, EXH MANIF |
DW (LLT, MYB, MX0, MX7) |
2010-2010 |
01 |
| 002 |
12571101 |
MANIFOLD, EXH
| DW (LLT) |
2010-2010 |
01 |
|
| 002 |
12571102 |
MANIFOLD, EXH
| DW (LLT) |
2010-2010 |
01 |
|
| 003 |
11518860 |
БОЛТ, HFH, M8X1.25X30, 20.9 THD, 18 O.D., 10.9, GMW3179 CODE G, GM6194M (EXH MANIF H/SHLD)
|
2008-2010 |
14 |
|
| 004 |
12580706 |
SHIELD, EXH MANIF HT |
D (LLT) |
2010-2010 |
01 |
| 004 |
12617267 |
SHIELD, EXH MANIF HT |
D (LLT) |
2010-2010 |
01 |
| 005 |
11517516 |
БОЛТ, HFH, M6X1X13, 9.5 THD, 14.2 OD, 9.8, 6280M, MACH, HDR-PT (EXH MANIF H/SHLD) |
|
2008-2010 |
06 |
| 006 |
15709703 |
ГАЙКА, HEX 10X1.5THD, 21.8 OD SS (CTLTC CONV)
|
2008-2010 |
04 |
|
| 007 |
11589264 |
STUD, STRAIGHT, M10X1.5X30, M10X1.5X16, 57 TL, SS (CTLTC CONV)
| (LLT, LY7, JJA, JJB) |
2010-2010 |
02 |
|
| 008 |
25857958 |
SEAL, CTLTC CONV (ЧАСТЬ OF 10, 11) (INLET SEAL (W/O SHIELD))
| DW, DY29 (LLT, JJA, JJB) |
2008-2010 |
02 |
|
| 009 |
12594935 |
SENSOR, HTD OXY (POSN 1) (IN EXH MANIFOLD/CROSSOVER) (ACDelco #213-3850)
| D29 (LLT) |
2008-2010 |
02 |
|
| 010 |
25939989 |
CONVERTER, 3WAY CTLTC (INCLS 7, 8, 12, 13)
| DW (LLT, JJB) |
2009-2010 |
01 |
|
| 011 |
25971634 |
CONVERTER, 3WAY CTLTC (INCLS 7, 8, 12, 13)
| DW29 (LLT, JJB) |
2010-2010 |
01 |
|
| 012 |
11569946 |
STUD-STRAIGHT-M8X1.25X38, M8X1.25X12, W/EXT SOC, 56 OAL, 10.9, GM6164M (ЧАСТЬ OF 10, 11)
|
2008-2010 |
02 |
|
| 013 |
15879730 |
SEAL, CTLTC CONV (ЧАСТЬ OF 10, 11) (SPHERICAL OUTLET SEAL)
| DW (LLT, JJB) |
2010-2010 |
02 |
|
| 014 |
12616202 |
SENSOR, HTD OXY (POSN 2) |
DM, DW (LLT, MYB) |
2010-2010 |
01 |
| 014 |
12616203 |
SENSOR, HTD OXY (POSN 2) (ACDelco #213-4576) |
DM, DW (LLT, MYB) |
2010-2010 |
01 |
| 015 |
11517031 |
ГАЙКА, HFH, M8X1.25, 9.4THK, 17.4 O.D., 10, TIN ZN (EXH MUFF) |
|
2008-2010 |
04 |
| 016 |
15927179 |
MUFFLER, EXH (W/RESO, EXH TAIL PIPE)
| DW29 (LLT) |
2010-2010 |
01 |
|
| 017 |
25711603 |
INSULATOR, EXH MUFF HNGR BRKT |
D29 |
2008-2010 |
02 |
| 018 |
|
АМОРТИЗАТОР, RR BPR ENGY (СМ. ГРУППУ 07.000 БАМПЕР ЗАДНИЙ ДЛЯ ДЕТАЛЬНОГО ПРОСМОТРА) (METAL E.A. UNIT) |
|
2008-2010 |
|
| 019 |
11518444 |
ГАЙКА, U, M8X1.25, 25X14.2, 3.4-6.3 PNL, 1050, 6173M (RR BPR ENGY ABS)
|
2008-2010 |
06 |
|
| 020 |
15240254 |
BRACKET, EXH TAIL PIPE HNGR (INCLS 21)
| D29 |
2008-2010 |
01 |
|
| 020 |
25902027 |
BRACKET, EXH TAIL PIPE HNGR (INCLS 21) |
DW29 |
2010-2010 |
01 |
| 021 |
15284207 |
INSULATOR, EXH TAIL PIPE HNGR (ЧАСТЬ OF 20)
| D29 |
2008-2010 |
04 |
|
