| Поз. | Номер | Описание | Применение | Номенклатура | Кол-во |
| 001 |
15297051 |
GRILLE, W/S DEFR NOZ (INCLS 2, 5) (CASHMERE) |
DW29 (W21, 39I) (EXC UV6) |
2008-2009 |
01 |
| 001 |
25772896 |
GRILLE, W/S DEFR NOZ (INCLS 2, 5) (EBONY) |
DW29 (13I, 19I) (EXC UV6) |
2008-2009 |
01 |
| 001 |
25772896 |
GRILLE, W/S DEFR NOZ (INCLS 2, 5) (EBONY) |
DX29 (13I, 19I, 67I) (EXC UV6) |
2008-2009 |
01 |
| 001 |
25772897 |
GRILLE, W/S DEFR NOZ (INCLS 2, 5) (EBONY) |
DW29 (UV6, 13I, 19I) |
2008-2009 |
01 |
| 001 |
25772897 |
GRILLE, W/S DEFR NOZ (INCLS 2, 5) (EBONY) |
DX29 (UV6, 13I, 19I, 67I) |
2008-2009 |
01 |
| 001 |
25774060 |
GRILLE, W/S DEFR NOZ (INCLS 2, 5) (CASHMERE) |
DW (32I) (EXC UV6, W21) |
2008-2009 |
01 |
| 001 |
25774061 |
GRILLE, W/S DEFR NOZ (INCLS 2, 5) (CASHMERE) |
DW (UV6, 32I) (EXC W21) |
2008-2009 |
01 |
| 002 |
25713063 |
SENSOR, HDLP AUTO CONT AMB LGT (ЧАСТЬ OF 1) (DUAL SOLAR TWILIGHT)
| DW, DX29 |
2006-2009 |
01 |
|
| 003 |
11609989 |
БОЛТ, HEX W/FLAT WASHER, M6X1X25, 15 THD, 17 OD, 6202M STL, GMW3200, TAPTITE (I/P INFL RST MDL)
|
2005-2010 |
04 |
|
| 004 |
15281906 |
МОДУЛЬ, I/P INFL RST
| D29 |
2006-2010 |
01 |
|
| 005 |
15748479 |
RETAINER, GARNISH MOLDING TYPE, FITS SLOT 6.0MM, SPR STL, ZC (ЧАСТЬ OF 1, 10) |
|
2005-2010 |
AR |
| 006 |
25898280 |
МОДУЛЬ, BODY CONT (ЗАДНИЙ INTEGRATION МОДУЛЬ) (LABELED 25898280) (ACDelco #25898280)
| DW, DX, DY29 (EXC AE5, UHB) |
2009-2009 |
01 |
|
| 007 |
15773968 |
PANEL, INST (INCLS 11, 22) (GRAY) (W/O HUD) |
DX (13I) (EXC UV6) |
2006-2009 |
01 |
| 007 |
15773969 |
PANEL, INST (INCLS 11, 22) (EBONY) (W/O HUD) |
D29 (19I) |
2006-2009 |
01 |
| 007 |
15773969 |
PANEL, INST (INCLS 11, 22) (EBONY) (W/O HUD) |
D29 (W21, 19I) |
2006-2009 |
01 |
| 007 |
15773970 |
PANEL, INST (INCLS 11, 22) (RED) (W/O HUD) |
DX (67I) (EXC UV6) |
2006-2009 |
01 |
| 007 |
15858057 |
PANEL, INST (INCLS 11, 22) (COCOA) (PLATINUM) |
DW (39I) (EXC UV6) |
2007-2010 |
01 |
| 007 |
15858059 |
PANEL, INST (INCLS 11, 22) (EBONY) |
DW, DX (UV6, W21, 19I) |
2008-2009 |
01 |
| 007 |
15858061 |
PANEL, INST (INCLS 11, 22) (COCOA) (PLATINUM) |
DW (UV6, W21, 39I) |
2007-2009 |
01 |
| 007 |
25779496 |
PANEL, INST (INCLS 11, 22) (GRAY) (W/HUD) |
DX (UV6, 13I) |
2008-2009 |
01 |
| 007 |
25779497 |
PANEL, INST (INCLS 11, 22) (RED) (W/HUD) |
DX (UV6, 67I) |
2008-2009 |
01 |
| 007 |
89045024 |
PANEL, INST (INCLS 11, 22) (EBONY) |
DW (19I) (EXC UV6) |
2005-2009 |
01 |
| 007 |
89045025 |
PANEL, INST (INCLS 11, 22) (GRAY) |
DW (13I) (EXC UV6) |
2005-2009 |
01 |
| 007 |
89045026 |
PANEL, INST (INCLS 11, 22) (CASHMERE) |
DW (32I) (EXC UV6) |
2005-2009 |
01 |
| 007 |
89045028 |
PANEL, INST (INCLS 11, 22) (EBONY) |
DW (UV6, 19I) |
2005-2009 |
01 |
| 007 |
89045028 |
PANEL, INST (INCLS 11, 22) (EBONY) |
DW (UV6, 19I) (EXC W21) |
2005-2009 |
01 |
| 007 |
89045029 |
PANEL, INST (INCLS 11, 22) (GRAY) |
DW (UV6, 13I) |
2005-2009 |
01 |
| 007 |
89045029 |
PANEL, INST (INCLS 11, 22) (GRAY) |
DW (UV6, 13I) (EXC W21) |
2005-2009 |
01 |
| 007 |
89045030 |
PANEL, INST (INCLS 11, 22) (CASHMERE)
| DW (UV6, 32I) |
2005-2009 |
01 |
|
| 007 |
89045030 |
PANEL, INST (INCLS 11, 22) (CASHMERE)
| DW (UV6, 32I) (EXC W21) |
2005-2009 |
01 |
|
| 008 |
|
RADIO, AM/FM STEREO CLK CD PLYR (FOR SERVICE SEE GM PARTS PROCESS/POLICY BULLETIN FOR THE LATEST SERVICE INFORMATION) |
|
2008-2009 |
|
| 008 |
|
RADIO, AM/FM STEREO NAVN (FOR SERVICE SEE GM PARTS PROCESS/POLICY BULLETIN FOR THE LATEST SERVICE INFORMATION) |
|
2008-2009 |
|
| 009 |
11609989 |
БОЛТ, HEX W/FLAT WASHER, M6X1X25, 15 THD, 17 OD, 6202M STL, GMW3200, TAPTITE (RDO R/Q TR PNL SPKR)
|
2005-2010 |
04 |
|
| 010 |
|
PLATE, I/P ACSRY CTR TR (INCLS 5) (СМ. ГРУППУ 10.000 ПРИБОРНАЯ ПАНЕЛЬ ЧАСТЬ 1 ДЛЯ ДЕТАЛЬНОГО ПРОСМОТРА) (FREQUENCY) |
|
2005-2010 |
|
| 011 |
11518121 |
ГАЙКА, U, M6X1, MULTI THD, .5-4.0 THK PNL (ЧАСТЬ OF 7) |
|
2005-2010 |
04 |
| 012 |
25839372 |
CONTROL, HTR КОНДИЦИОНЕР (ACDelco #15-73845) |
DW29 (EXC KA1, KB6) |
2008-2010 |
01 |
| 012 |
25839373 |
CONTROL, HTR КОНДИЦИОНЕР (W/ D/SEAT P/SEAT HTR) (ACDelco #15-73846) |
DX29 (KA1) |
2008-2009 |
01 |
| 012 |
25839373 |
CONTROL, HTR КОНДИЦИОНЕР (W/ D/SEAT P/SEAT HTR) (ACDelco #15-73846) |
DW (CJ2, KA1) |
2008-2010 |
01 |
| 012 |
25839374 |
CONTROL, HTR КОНДИЦИОНЕР (W/ F/SEAT HTR CUSH VENT FAN) (ACDelco #15-73847) |
DW29 (CJ2, KB6) |
2008-2010 |
01 |
| 013 |
11589015 |
БОЛТ, HWH W/FL WA M4.2X1.41X20, 12.5 O.D., DOG PT, 6010M, 7253M (HTR КОНДИЦИОНЕР CONT)
|
2005-2010 |
04 |
|
| 014 |
15932866 |
PLATE, I/P CSTR TR (INCLS 15, 17, 20, 21) (EBONY) |
DX (UV6, 13I, 19I, 67I) |
2008-2009 |
01 |
| 014 |
15932866 |
PLATE, I/P CSTR TR (INCLS 15, 17, 20, 21) (EBONY) |
DW (UV6, 13I, 19I, 67I) |
2008-2010 |
01 |
| 014 |
15932867 |
PLATE, I/P CSTR TR (INCLS 15, 17, 20, 21) (CASHMERE) |
DW (UV6, 32I) |
2008-2010 |
01 |
| 014 |
15933181 |
PLATE, I/P CSTR TR (INCLS 15, 17, 20, 21) (EBONY) |
DX (13I, 19I, 67I) (EXC UV6) |
2008-2009 |
01 |
| 014 |
15933181 |
PLATE, I/P CSTR TR (INCLS 15, 17, 20, 21) (EBONY) |
DW (13I, 19I, 67I) (EXC UV6) |
2008-2010 |
01 |
| 014 |
15933182 |
PLATE, I/P CSTR TR (INCLS 15, 17, 20, 21) (CASHMERE) |
DW (32I) (EXC UV6) |
2008-2009 |
01 |
| 014 |
15933183 |
PLATE, I/P CSTR TR (INCLS 15, 17, 20, 21) (COCOA) |
DW (39I) (EXC UV6) |
2008-2009 |
01 |
| 014 |
20808511 |
PLATE, I/P CSTR TR (INCLS 15, 17, 20, 21) (COCOA) |
DW (UV6, 39I) |
2008-2010 |
01 |
| 015 |
25893239 |
SWITCH, IGN START (ЧАСТЬ OF 14) (ACDelco #D1433G) |
DX29 |
2008-2009 |
01 |
| 015 |
25893239 |
SWITCH, IGN START (ЧАСТЬ OF 14) (ACDelco #D1433G) |
DW29 |
2008-2010 |
01 |
| 016 |
11509231 |
SCREW, RD HD C/R TAP, M4.2X1.41X13.0, GM6010M STL, GM813M NICKEL ORGANIC (AIR INL HSG)
|
2005-2010 |
02 |
|
| 017 |
25752175 |
ШЛАНГИ, AIR INL (ЧАСТЬ OF 14) |
DW29 |
2005-2010 |
01 |
| 017 |
25752175 |
ШЛАНГИ, AIR INL (ЧАСТЬ OF 14) |
DX29 |
2006-2009 |
01 |
| 018 |
25687484 |
SENSOR, I/S AIR TEMP (ACDelco #15-5889)
| D |
2005-2010 |
01 |
|
| 019 |
|
DUCT, I/S AIR TEMP SEN (TUBE, SENSOR) |
|
2008-2009 |
|
| 020 |
15933006 |
ШЛАНГИ, I/P OTR AIR OTLT DFL (ЧАСТЬ OF 14) (EBONY/CHROME) |
D29 |
2008-2010 |
01 |
| 021 |
21995018 |
CLIP, I/P TR PLT (ЧАСТЬ OF 14) |
D29 |
2005-2010 |
AR |
| 022 |
11610157 |
ГАЙКА, PNL, M4.2X1.41, 8.5X11.9, 2.3-2.8 PNL, FITS 11.2X9.2 HOLE, 1050, GMW33 (ЧАСТЬ OF 7) (10.701)
|
2005-2009 |
04 |
|
| 023 |
25827228 |
SWITCH, DRVR INFO DISPLAY (EBONY) |
D29 (32I) (EXC UV6) |
2007-2009 |
01 |
| 023 |
25827228 |
SWITCH, DRVR INFO DISPLAY (EBONY) |
DW29 (JJD, 13I, 19I, 49I, 32I, 39I) (EXC UV6) |
2008-2009 |
01 |
| 023 |
25827228 |
SWITCH, DRVR INFO DISPLAY (EBONY) |
DX29 (13I, 19I, 67I) (EXC UV6) |
2008-2009 |
01 |
| 023 |
25827228 |
SWITCH, DRVR INFO DISPLAY (EBONY) |
DW29 (JJD, 67I) (EXC UV6) |
2009-2009 |
01 |
| 023 |
25827228 |
SWITCH, DRVR INFO DISPLAY (EBONY) |
DX29 (JJD, UV6, 49I) |
2009-2009 |
01 |
| 023 |
25827229 |
SWITCH, DRVR INFO DISPLAY |
D29 (B20, UV6, 32I) (EXC B19) |
2007-2009 |
01 |
| 023 |
25827229 |
SWITCH, DRVR INFO DISPLAY |
DW, DX (JJD, UV6, 13I, 19I, 67I) |
2009-2009 |
01 |
| 024 |
|
LENS, INST CSTR (ЧАСТЬ OF 26) |
|
2008-2009 |
|
| 025 |
11589015 |
БОЛТ, HWH W/FL WA M4.2X1.41X20, 12.5 O.D., DOG PT, 6010M, 7253M (INST CSTR)
|
2005-2010 |
04 |
|
| 026 |
|
CLUSTER, INST (INCLS 24) (FOR SERVICE SEE GM PARTS PROCESS/POLICY BULLETIN FOR THE LATEST SERVICE INFORMATION) |
|
2005-2009 |
|
| 027 |
|
КРОНШТЕЙН, INST PNL (СМ. ГРУППУ 10.000 ПРИБОРНАЯ ПАНЕЛЬ, ЧАСТЬ 3 ДЛЯ ДЕТАЛЬНОГО ПРОСМОТРА) |
|
2008-2009 |
|
| 028 |
25536302 |
ГАЙКА, INST CSTR (4.2 X 1.41) (TAPPING NUT) (3.430)
| D29 |
2008-2010 |
04 |
|
| 029 |
11589015 |
БОЛТ, HWH W/FL WA M4.2X1.41X20, 12.5 O.D., DOG PT, 6010M, 7253M (INST CSTR HEAD UP DISPLAY BRKT)
|
2005-2010 |
03 |
|
| 030 |
|
DISPLAY, INST CSTR HEAD UP (FOR SERVICE SEE GM PARTS PROCESS/POLICY BULLETIN FOR THE LATEST SERVICEINFORMATION) |
|
2008-2009 |
|
| 031 |
|
HARNESS, I/P WRG (СМ. ГРУППУ 02.000 ЖГУТЫ ПРОВОДОВ/ПРИБОРНАЯ ПАНЕЛЬ ДЛЯ ДЕТАЛЬНОГО ПРОСМОТРА) |
|
2008-2009 |
|
