| Поз. | Номер | Описание | Применение | Номенклатура | Кол-во |
| 001 |
10364658 |
PLATE, FRT S/D SILL NA (INCLS 2) (CADILLAC) |
DW (EXC W21) |
2007-2010 |
02 |
| 001 |
10364658 |
PLATE, FRT S/D SILL NA (INCLS 2) (CADILLAC) |
DY (EXC W21) (EXPORT) |
2008-2009 |
02 |
| 001 |
15795697 |
PLATE, FRT S/D SILL NA (INCLS 2) (CADILLAC) |
DW (W21) |
2007-2010 |
02 |
| 001 |
25762033 |
PLATE, FRT S/D SILL NA (INCLS 2) (CADILLAC) |
DX (EXC W21) |
2007-2009 |
02 |
| 002 |
11588650 |
CLIP, 12X14X16.6, GM4345M (ЧАСТЬ OF 1)
|
2005-2010 |
03 |
|
| 003 |
15244949 |
PLATE, FRT S/D SILL TR (INCLS 4, 5) (EBONY) |
D29 (19I, 67I) |
2008-2009 |
01 |
| 003 |
15244949 |
PLATE, FRT S/D SILL TR (INCLS 4, 5) (EBONY) |
DW, DX29 (19I, 67I) |
2008-2009 |
01 |
| 003 |
15244950 |
PLATE, FRT S/D SILL TR (INCLS 4, 5) (EBONY) |
D29 (19I, 67I) |
2008-2009 |
01 |
| 003 |
15244951 |
PLATE, FRT S/D SILL TR (INCLS 4, 5) (CASHMERE) |
DW29 (32I, 39I) |
2007-2009 |
01 |
| 003 |
15244951 |
PLATE, FRT S/D SILL TR (INCLS 4, 5) (CASHMERE) |
DY (32I, 39I) (EXPORT) |
2008-2009 |
01 |
| 003 |
15244952 |
PLATE, FRT S/D SILL TR (INCLS 4, 5) (CASHMERE) |
DW29 (32I, 39I) |
2007-2009 |
01 |
| 003 |
15244952 |
PLATE, FRT S/D SILL TR (INCLS 4, 5) (CASHMERE) |
DY (32I, 39I) (EXPORT) |
2008-2009 |
01 |
| 003 |
15244953 |
PLATE, FRT S/D SILL TR (INCLS 4, 5) (GRAY) |
DW, DX (13I) |
2007-2009 |
01 |
| 003 |
15244953 |
PLATE, FRT S/D SILL TR (INCLS 4, 5) (GRAY) |
DY (13I) (EXPORT) |
2008-2009 |
01 |
| 003 |
15244954 |
PLATE, FRT S/D SILL TR (INCLS 4, 5) (GRAY) |
DW, DX (13I) |
2007-2009 |
01 |
| 003 |
15244954 |
PLATE, FRT S/D SILL TR (INCLS 4, 5) (GRAY) |
DY (13I) (EXPORT) |
2008-2009 |
01 |
| 004 |
25672428 |
RETAINER, FRT S/D SILL TR PLT (ЧАСТЬ OF 3) (7 X 14MM HOLE) (RECTANGLE)
| D29 |
2005-2009 |
08 |
|
| 005 |
11588650 |
CLIP, 12X14X16.6, GM4345M (ЧАСТЬ OF 3)
|
2005-2010 |
04 |
|
| 006 |
25782787 |
MOLDING, W/S SI GARN (INCLS 7-9) (GRAY) |
DW29 (13I) |
2008-2009 |
01 |
| 006 |
25782787 |
MOLDING, W/S SI GARN (INCLS 7-9) (GRAY) |
DW29 (19I) (EXC W21) |
2008-2009 |
01 |
| 006 |
25782787 |
MOLDING, W/S SI GARN (INCLS 7-9) (GRAY) |
DX, DY29 (13I, 19I, 67I) |
2008-2009 |
01 |
| 006 |
25782788 |
MOLDING, W/S SI GARN (INCLS 7-9) (GRAY) |
DW29 (13I) |
2008-2009 |
01 |
| 006 |
25782788 |
MOLDING, W/S SI GARN (INCLS 7-9) (GRAY) |
DW29 (19I) (EXC W21) |
2008-2009 |
01 |
| 006 |
25782788 |
MOLDING, W/S SI GARN (INCLS 7-9) (GRAY) |
DX29 (13I, 19I, 67I) |
2008-2009 |
01 |
| 006 |
25782788 |
MOLDING, W/S SI GARN (INCLS 7-9) (GRAY) |
DY29 (13I, 19I, 67I) (EXPORT) |
2008-2009 |
01 |
| 006 |
25782789 |
MOLDING, W/S SI GARN (INCLS 7-9) (CASHMERE) |
D29 (32I, 39I) (EXC W21) |
2008-2009 |
01 |
| 006 |
25782790 |
MOLDING, W/S SI GARN (INCLS 7-9) (CASHMERE) |
DX29 (32I, 39I) (EXC W21) |
2008-2009 |
01 |
| 006 |
25782790 |
MOLDING, W/S SI GARN (INCLS 7-9) (CASHMERE) |
DY29 (32I, 39I) (EXC W21) (EXPORT) |
2008-2009 |
01 |
| 006 |
25782790 |
MOLDING, W/S SI GARN (INCLS 7-9) (CASHMERE) |
DW29 (32I, 39I) (EXC W21) |
2008-2010 |
01 |
| 006 |
25831771 |
MOLDING, W/S SI GARN (INCLS 7-9) (CASHMERE) (CADILLAC PLATINUM EDITION) |
DW29 (W21, 19I, 39I) |
2008-2009 |
01 |
| 006 |
25831772 |
MOLDING, W/S SI GARN (INCLS 7-9) (CASHMERE) (CADILLAC PLATINUM EDITION) |
DW29 (W21, 19I, 39I) |
2008-2009 |
01 |
| 007 |
11609651 |
ГАЙКА, W/S G/MLDG (ЧАСТЬ OF 6) (M21.8X15.0X20.5) (14.731)
| D29 |
2008-2009 |
02 |
|
| 008 |
11508765 |
SCREW, TORX, W/ RD WA, M4.2X1.41X16, 11.1 O.D., STL, NIOR (ЧАСТЬ OF 6) |
|
2005-2010 |
04 |
| 009 |
10393499 |
PLUG, C/PLR UPR G/MLDG БОЛТ HOLE FIN (ЧАСТЬ OF 6) (CASHMERE) (AIRBAG) (14.865)
| D29 (32I, 39I) |
2007-2009 |
02 |
|
| 009 |
10393499 |
PLUG, C/PLR UPR G/MLDG БОЛТ HOLE FIN (ЧАСТЬ OF 6) (CASHMERE) (AIRBAG) (14.865)
| DW29 (W21, 19I) |
2008-2009 |
02 |
|
| 009 |
25772916 |
PLUG, C/PLR UPR G/MLDG БОЛТ HOLE FIN (ЧАСТЬ OF 6) (GRAY) (AIRBAG) (14.865)
| D29 (13I, 19I, 67I) |
2008-2009 |
02 |
|
