| Поз. | Номер | Описание | Применение | Номенклатура | Кол-во |
| 001 |
88964536 |
CAP, P/S FLUID RSVR |
DW, DX29 |
2008-2009 |
01 |
| 002 |
19133714 |
RESERVOIR, P/S PUMP FLUID |
D29 |
2005-2010 |
01 |
| 003 |
19168192 |
BRACKET, P/S FLUID RSVR |
DW29 (LLT) |
2008-2010 |
01 |
| 004 |
88964537 |
БОЛТ, P/S FLUID RSVR BRKT |
DW29 |
2008-2010 |
01 |
| 005 |
11516222 |
CЛАМПА, ПРУЖИНАBAND, HOSE DIA=23, WIDTH=15, 6298M, MM (ЧАСТЬ OF 6)
|
2005-2010 |
02 |
|
| 006 |
15251170 |
HOSE, P/S FLUID RSVR OTLT (INCLS 5) |
DW29 (LLT) |
2008-2010 |
01 |
| 007 |
11588712 |
БОЛТ, HFH, M6X1X20, 17.5 THD, 14.2 O.D., 8.8, GMW3359 (P/S FLUID RSVR) |
|
2005-2010 |
01 |
| 008 |
25900770 |
PUMP, P/S (СМ. ГРУППУ 06.000 НАСОС РУЛЕВОГО УПРАВЛЕНИЯ ASM ДЛЯ ДЕТАЛЬНОГО ПРОСМОТРА)
| DW (LLT) |
2008-2010 |
01 |
|
| 009 |
|
SEAL, P/S GR INL HOSE FTG (O RING) (ЧАСТЬ OF 10) |
|
2008-2010 |
|
| 010 |
19206606 |
HOSE, P/S GR INL (INCLS 9, 12) |
DW29 (LLT) (EXC NV7) |
2008-2010 |
01 |
| 010 |
19206607 |
HOSE, P/S GR INL (INCLS 9, 12)
| DW29 (LLT, NV7) |
2008-2010 |
01 |
|
| 011 |
11517937 |
БОЛТ, HWH, M8X1.25X22.1, 13.85 THD, 15 OD, 9.8, 7114M, MACH, 6175M ADH, MAT-PT (P/S GR INL PIPE BRKT)
|
2005-2010 |
01 |
|
| 012 |
|
SEAL, P/S GR INL HOSE (O RING) (ЧАСТЬ OF 10) (*KIT1) |
|
2008-2010 |
|
| 013 |
|
SEAL, P/S GR OTLT HOSE (O-RING) (ЧАСТЬ OF 14) (*KIT1) |
|
2008-2010 |
|
| 014 |
25950911 |
HOSE, P/S GR OTLT (INCLS 13, 16)
| DW29 (NV7) (EXC JL7) |
2008-2010 |
01 |
|
| 014 |
25950912 |
HOSE, P/S GR OTLT (INCLS 13, 16) |
DW29 (EXC NV7) |
2005-2010 |
01 |
| 015 |
10199206 |
БОЛТ, P/S GR INL OTLT PIPE RET (M6X1.0X18) (4.785) |
DW29 |
2005-2010 |
06 |
| 016 |
|
CLIP, P/S GR OTLT HOSE (ЧАСТЬ OF 14) |
|
2008-2010 |
|
| 017 |
10376953 |
HOSE, P/S FLUID CLR OTLT (BRIDGE HOSE) (INCLS 21)
| DW (EXC JL7) |
2008-2010 |
01 |
|
| 018 |
|
BAR, FRT BPR IMP (СМ. ГРУППУ 07.000 БАМПЕР ПЕРЕДНИЙ ДЛЯ ДЕТАЛЬНОГО ПРОСМОТРА) |
|
2005-2010 |
|
| 019 |
15236157 |
COOLER, P/S FLUID
| DW29 (EXC JL7) |
2008-2010 |
01 |
|
| 019 |
15906726 |
COOLER, P/S FLUID |
DW (JL7) |
2008-2010 |
01 |
| 020 |
11516931 |
БОЛТ, FLAT WA METRIC HEX HD MACHINE, M8X1.25X50 (P/S FLUID CLR BRKT) |
|
2005-2010 |
02 |
| 021 |
|
CLIP, P/S FLUID CLR OTLT (ЧАСТЬ OF 17) |
|
2008-2010 |
|
| 022 |
|
CЛАМПА, P/S FLUID CLG HOSE (ЧАСТЬ OF 23) |
|
2008-2010 |
|
| 023 |
25820474 |
HOSE, P/S FLUID CLR OTLT (INCLS 22)
| DW29 (LLT) |
2008-2010 |
01 |
|
| K01 |
88964534 |
SEAL KIT, P/S GR OTLT HOSE CONN (INCLS 12, 13)
| DW, DY29 (LH2, LLT) (EXC JL7) |
2008-2008 |
01 |
|
