| Поз. | Номер | Описание | Применение | Номенклатура | Кол-во |
| 001 |
25781867 |
SHIELD, BAT HT |
DW, DX |
2008-2009 |
01 |
| 002 |
11610091 |
ГАЙКА, BAT POS CBL (M8 X 1.25) (8.917) |
DW, DX, DY29 |
2008-2008 |
01 |
| 003 |
|
COVER, BAT POS CBL TERM (ЧАСТЬ OF 4) |
|
2008-2010 |
|
| 004 |
25834438 |
CABLE, BAT POS (INCLS 3, 7, 8) (LABELED 25834438) (ACDelco #25834438) |
DW29 (LLT) |
2008-2008 |
01 |
| 005 |
21021808 |
ГАЙКА, STRTR SOL BAT TERM (M8X1.25X6, BRASS) (2.343)
| D |
2008-2009 |
01 |
|
| 006 |
11515770 |
БОЛТ, HFH, RED BODY, M10X1.5X50, THD 22.3, 9.8, 7114, PZOR (TRANS)
|
2008-2010 |
11 |
|
| 007 |
12045771 |
CLIP, BAT CBL (ЧАСТЬ OF 4) (**VPI 1-877-846-8243) |
DW29 (LLT) |
2008-2008 |
01 |
| 008 |
12146809 |
COVER, GEN WIRE TERM (ЧАСТЬ OF 4) (BLACK) (TERMINAL BOOT COVER) (2.343) |
D |
2008-2008 |
01 |
| 009 |
11515535 |
ГАЙКА, BAT WIRE (ATTACHES TO BACK OF GENERATOR) (2.559) |
D29 |
2008-2008 |
01 |
| 010 |
11518121 |
ГАЙКА, U, M6X1, MULTI THD, .5-4.0 THK PNL (ЧАСТЬ OF 11) |
|
2008-2010 |
02 |
| 011 |
25783791 |
TRAY, BAT (INCLS 10) |
DW |
2008-2010 |
01 |
| 012 |
11516589 |
SCREW, HEX HD W/CON SPR WA, M6X1X30, 29 THD, 17 O.D., 9.8, 7114M, ZE (AIR INL) |
|
2008-2010 |
03 |
| 013 |
11516589 |
SCREW, HEX HD W/CON SPR WA, M6X1X30, 29 THD, 17 O.D., 9.8, 7114M, ZE (BAT TRAY) |
|
2008-2010 |
05 |
| 014 |
11609989 |
БОЛТ, HEX W/FLAT WASHER, M6X1X25, 15 THD, 17 OD, 6202M STL, GMW3200, TAPTITE (BAT TRAY)
|
2008-2010 |
02 |
|
| 015 |
25867297 |
RETAINER, BAT HOLDN |
DW, DX29 |
2008-2009 |
01 |
| 016 |
11589407 |
БОЛТ, HWH, M8X1.25X35, 23.5 THD, 24 OD, 10.9, GMW3359, M-PT. (BAT HOLDN RET)
|
2008-2010 |
01 |
|
| 017 |
89022169 |
АККУМУЛЯТОР, (CCA 770) (TOP POST) (277X174X190) (US DEALERS CONTACT ACDELCO WD FOR ORDERING PRICING INFO) (ACDelco #48-7YR) (PROFESSIONAL - 7 YR) |
DW29 (LH2, LLT) |
2008-2009 |
01 |
| 018 |
11588564 |
БОЛТ, HEX W/FL WA, M8X1.25X25, 15.85 THD, 17 OD, 9.8, GMW3200M, MACH, MAT-PT (BAT NEG CBL GND) |
|
2008-2010 |
01 |
| 019 |
10306471 |
SENSOR, BAT CUR (ЧАСТЬ OF 22)
| DW, DY29 (LLT) |
2008-2009 |
01 |
|
| 020 |
19116749 |
COVER, BAT NEG CBL TERM (ЧАСТЬ OF 22) |
DW29 (LLT) |
2008-2010 |
01 |
| 021 |
11589258 |
БОЛТ, BAT NEG CBL GND (M8X1.25X31)
| DW29 (LLT) |
2008-2010 |
01 |
|
| 022 |
15869246 |
CABLE, BAT NEG (INCLS 19, 20) |
DW (LLT, JJA) |
2008-2008 |
01 |
| 022 |
25930835 |
CABLE, BAT NEG (INCLS 19, 20) (ACDelco #25930835) (LABELED 25930835) |
DW29 (LLT, JJB) |
2008-2008 |
01 |
| 023 |
11518121 |
ГАЙКА, U, M6X1, MULTI THD, .5-4.0 THK PNL (AIR INL HSG) |
|
2008-2010 |
05 |
