| Поз. | Номер | Описание | Применение | Номенклатура | Кол-во |
| 001 |
25751892 |
BRACKET, C/PLR T/PNL (INCLS 2, 3) |
DX |
2006-2009 |
02 |
| 001 |
25751892 |
BRACKET, C/PLR T/PNL (INCLS 2, 3) |
DW |
2006-2010 |
02 |
| 002 |
11609651 |
CLIP, C/PLR CTR T/PNL (ЧАСТЬ OF 1) (M21.8X15.0X20.5) (14.731)
| DW |
2006-2010 |
02 |
|
| 003 |
11508765 |
SCREW, TORX, W/ RD WA, M4.2X1.41X16, 11.1 O.D., STL, NIOR (ЧАСТЬ OF 1) |
|
2005-2010 |
02 |
| 004 |
25781192 |
PANEL, QTR UPR TR (INCLS 5-8) (GRAY) |
DW, DX (13I, 19I, 49I, 67I) |
2007-2007 |
01 |
| 004 |
25781193 |
PANEL, QTR UPR TR (INCLS 5-8) (GRAY) |
DW, DX (13I, 19I, 49I, 67I) |
2007-2007 |
01 |
| 004 |
25781194 |
PANEL, QTR UPR TR (INCLS 5-8) (CASHMERE) |
DW (32I, 39I) |
2007-2007 |
01 |
| 004 |
25781195 |
PANEL, QTR UPR TR (INCLS 5-8) (CASHMERE) |
DW (32I, 39I) |
2007-2007 |
01 |
| 005 |
|
ГАЙКА, QTR UPR T/PNL (ЧАСТЬ OF 4) |
|
2005-2007 |
|
| 006 |
11508765 |
SCREW, TORX, W/ RD WA, M4.2X1.41X16, 11.1 O.D., STL, NIOR (ЧАСТЬ OF 4) |
|
2005-2010 |
02 |
| 007 |
10393499 |
PLUG, C/PLR UPR G/MLDG БОЛТ HOLE FIN (ЧАСТЬ OF 4) (CASHMERE) (AIRBAG) (14.865)
| D29 (32I, 39I) |
2007-2009 |
02 |
|
| 007 |
25772916 |
PLUG, C/PLR UPR G/MLDG БОЛТ HOLE FIN (ЧАСТЬ OF 4) (GRAY) (AIRBAG) (14.865)
| D29 (13I, 19I, 49I, 67I) |
2007-2007 |
02 |
|
| 008 |
11588650 |
CLIP, 12X14X16.6, GM4345M (ЧАСТЬ OF 4)
|
2005-2010 |
04 |
|
| 009 |
15145752 |
PANEL, C/PLR UPR TR (INCLS 10-15) (GRAY) |
DW, DX (13I, 19I, 49I, 67I) |
2007-2007 |
01 |
| 009 |
15145753 |
PANEL, C/PLR UPR TR (INCLS 10-15) (GRAY) |
DW, DX (13I, 19I, 49I, 67I) |
2007-2007 |
01 |
| 009 |
15145754 |
PANEL, C/PLR UPR TR (INCLS 10-15) (CASHMERE) |
DW (32I, 39I) |
2007-2007 |
01 |
| 009 |
15145755 |
PANEL, C/PLR UPR TR (INCLS 10-15) (CASHMERE) |
DW (32I, 39I) |
2007-2007 |
01 |
| 010 |
11588650 |
CLIP, 12X14X16.6, GM4345M (ЧАСТЬ OF 9)
|
2005-2010 |
04 |
|
| 011 |
89023584 |
INSERT, BODY SI T/PNL (ЧАСТЬ OF 9) (CASHMERE) |
DW (32I, 39I) |
2007-2007 |
01 |
| 011 |
89023585 |
INSERT, BODY SI T/PNL (ЧАСТЬ OF 9) (GRAY) |
DW, DX (13I, 19I, 49I, 67I) |
2007-2007 |
01 |
| 011 |
89023587 |
INSERT, BODY SI T/PNL (ЧАСТЬ OF 9) (CASHMERE) |
DW (32I, 39I) |
2007-2007 |
01 |
| 011 |
89023588 |
INSERT, BODY SI T/PNL (ЧАСТЬ OF 9) (GRAY) |
DW, DX (13I, 19I, 49I, 67I) |
2007-2007 |
01 |
| 012 |
89023306 |
PLATE, BODY SI INR PNL UPR (ЧАСТЬ OF 9) |
D29 (32I, 39I) |
2007-2007 |
01 |
| 012 |
89023579 |
PLATE, BODY SI INR PNL UPR (ЧАСТЬ OF 9) (GRAY) |
D29 (13I, 19I, 49I, 67I) |
2007-2007 |
01 |
| 012 |
89023581 |
PLATE, BODY SI INR PNL UPR (ЧАСТЬ OF 9) (CASHMERE) |
D29 (32I, 39I) |
2007-2007 |
01 |
| 012 |
89023582 |
PLATE, BODY SI INR PNL UPR (ЧАСТЬ OF 9) (GRAY) |
D29 (13I, 19I, 49I, 67I) |
2007-2007 |
01 |
| 013 |
89023593 |
HINGE, BODY SI WDO UPR (ЧАСТЬ OF 9) (CASHMERE) (CTR PUSHBUTTON) |
D29 (32I, 39I) |
2007-2007 |
01 |
| 013 |
89023594 |
HINGE, BODY SI WDO UPR (ЧАСТЬ OF 9) (CTR PUSHBUTTON) |
D29 (13I, 19I) |
2005-2007 |
01 |
| 014 |
89023301 |
EXTENSION, BODY SI UPR T/PNL (ЧАСТЬ OF 9) (14.545) |
DW |
2005-2010 |
02 |
| 014 |
89023301 |
EXTENSION, BODY SI UPR T/PNL (ЧАСТЬ OF 9) (14.545) |
DX |
2006-2009 |
02 |
| 015 |
89023303 |
COVER, C/PLR UPR T/PNL БОЛТ (ЧАСТЬ OF 9) (CASHMERE) |
DW (32I, 39I) |
2007-2007 |
02 |
| 015 |
89023304 |
COVER, C/PLR UPR T/PNL БОЛТ (ЧАСТЬ OF 9) (GRAY) |
DW, DX (13I, 19I, 49I, 67I) |
2007-2007 |
02 |
| 016 |
15795698 |
PLATE, RR S/D SILL NA (INCLS 17) (CADILLAC) |
DW (W21) |
2007-2010 |
02 |
| 016 |
25762034 |
PLATE, RR S/D SILL NA (INCLS 17) (CADILLAC) |
DW (EXC W21) |
2007-2010 |
02 |
| 016 |
25763954 |
PLATE, RR S/D SILL NA (INCLS 17) (CADILLAC) |
DX (EXC W21) |
2007-2009 |
02 |
| 017 |
|
CLIP, RR S/D SILL TR PLT (ЧАСТЬ OF 16) |
|
2005-2010 |
|
| 018 |
25769891 |
PLATE, RR S/D SILL TR (INCLS 19, 20) (EBONY) |
DW, DX (19I, 49I, 67I) |
2007-2007 |
01 |
| 018 |
25769892 |
PLATE, RR S/D SILL TR (INCLS 19, 20) (CASHMERE)
| DW (32I, 39I) |
2007-2009 |
01 |
|
| 018 |
25769893 |
PLATE, RR S/D SILL TR (INCLS 19, 20) (GRAY) |
DW, DX (13I) |
2007-2009 |
01 |
| 018 |
25769894 |
PLATE, RR S/D SILL TR (INCLS 19, 20) (EBONY) |
DW, DX (19I, 49I, 67I) |
2007-2007 |
01 |
| 018 |
25769895 |
PLATE, RR S/D SILL TR (INCLS 19, 20) (CASHMERE) |
DW (32I, 39I) |
2007-2009 |
01 |
| 018 |
25769896 |
PLATE, RR S/D SILL TR (INCLS 19, 20) (GRAY) |
DW, DX (13I) |
2007-2009 |
01 |
| 019 |
11588650 |
CLIP, 12X14X16.6, GM4345M (ЧАСТЬ OF 18)
|
2005-2010 |
04 |
|
| 020 |
25672428 |
RETAINER, RR S/D SILL TR PLT (ЧАСТЬ OF 18) (7 X 14MM HOLE) (RECTANGLE) (11.175)
| D29 |
2005-2009 |
04 |
|
| 021 |
25769912 |
PANEL, C/PLR LWR TR (INCLS 22) (EBONY) |
DW, DX (19I, 49I, 67I) |
2007-2007 |
01 |
| 021 |
25769913 |
PANEL, C/PLR LWR TR (INCLS 22) (CASHMERE) |
DW (32I, 39I) |
2007-2009 |
01 |
| 021 |
25769914 |
PANEL, C/PLR LWR TR (INCLS 22) (GRAY) |
DW, DX (13I) |
2006-2009 |
01 |
| 021 |
25769915 |
PANEL, C/PLR LWR TR (INCLS 22) (EBONY) |
DW, DX (19I, 49I, 67I) |
2007-2007 |
01 |
| 021 |
25769916 |
PANEL, C/PLR LWR TR (INCLS 22) (CASHMERE) |
DW (32I, 39I) |
2007-2009 |
01 |
| 021 |
25769917 |
PANEL, C/PLR LWR TR (INCLS 22) (GRAY) |
DW, DX (13I) |
2006-2009 |
01 |
| 022 |
11588650 |
CLIP, 12X14X16.6, GM4345M (ЧАСТЬ OF 21)
|
2005-2010 |
16 |
|
