| Поз. | Номер | Описание | Применение | Номенклатура | Кол-во |
| 001 |
15235576 |
SHAFT, PROP (INCLS CTR SUPT BRG)
| DW (LY7, MX7) |
2007-2007 |
01 |
|
| 001 |
15937535 |
SHAFT, PROP |
DW29 (LH2, MX7) |
2007-2007 |
01 |
| 002 |
11589166 |
БОЛТ, HEX W/CON WA, M10X1.5X39.8, 25.45 THD, 28 OD, 10.9, GMW3359, M-PT (PROP SHF BRG SUPT) |
|
2005-2007 |
02 |
| 003 |
25708829 |
SHIM, PROP SHF CTR SUPT BRG (BLACK) (OVERALL HEIGHT 2MM)
| D29 |
2005-2007 |
AR |
|
| 003 |
25708830 |
SHIM, PROP SHF CTR SUPT BRG (GREEN) (OVERALL HEIGHT 4MM)
| D29 |
2005-2007 |
AR |
|
| 003 |
25708831 |
SHIM, PROP SHF CTR SUPT BRG (BLUE) (OVERALL HEIGHT 6MM)
| D29 |
2005-2007 |
AR |
|
| 003 |
25708832 |
SHIM, PROP SHF CTR SUPT BRG (YELLOW) (OVERALL HEIGHT 8MM)
| D29 |
2005-2007 |
AR |
|
| 003 |
25708833 |
SHIM, PROP SHF CTR SUPT BRG (WHITE) (OVERALL HEIGHT 10MM)
| D29 |
2005-2007 |
AR |
|
| 003 |
25708834 |
SHIM, PROP SHF CTR SUPT BRG (PURPLE) (OVERALL HEIGHT 12MM)
| D29 |
2005-2007 |
AR |
|
| 004 |
11588658 |
БОЛТ, FRT PROP SHF (M12X1.75X70) (HEX) (8.900)
| D29 |
2005-2007 |
03 |
|
| 005 |
11588689 |
WASHER, FRT PROP SHF (ID 12.25, OD 23.0, THK 3.38MM)
| D29 |
2005-2007 |
03 |
|
| 006 |
11516073 |
ГАЙКА, FRT PROP SHF (M12X1.75X11.5, 10) (HEX LK PREV TORQ) (7111M ZE) (8.917)
| D29 |
2005-2007 |
03 |
|
| 007 |
11516073 |
ГАЙКА, RR PROP SHF (M12X1.75X11.5, 10) (HEX LK PREV TORQ) (7111M ZE) (8.917)
| D29 |
2005-2007 |
03 |
|
| 008 |
11588689 |
WASHER, RR PROP SHF (ID 12.25, OD 23.0, THK 3.38MM)
| D29 |
2005-2007 |
03 |
|
| 009 |
11588658 |
БОЛТ, RR PROP SHF (M12X1.75X70) (HEX) (8.900)
| D29 |
2005-2007 |
03 |
|
