| Поз. | Номер | Описание | Применение | Номенклатура | Кол-во |
| 001 |
|
COVER, R/SEAT CTR H/RST (ЧАСТЬ OF 18) |
|
2005-2010 |
|
| 002 |
|
COVER, R/SEAT CTR H/RST (ЧАСТЬ OF 19) |
|
2005-2010 |
|
| 003 |
|
LINER, R/SEAT A/RST CUP HLDR (ЧАСТЬ OF 5) |
|
2005-2010 |
|
| 004 |
22527475 |
SCREW, SEMS HEX W/FL WA M6.3X1.81X20 ABPT 6010M SOFT WA PZOR (R/SEAT) |
|
2005-2010 |
04 |
| 005 |
19123153 |
ARMREST, R/SEAT (INCLS 3) (EBONY) |
DX (194, 674) |
2006-2006 |
01 |
| 005 |
19123154 |
ARMREST, R/SEAT (INCLS 3) (GRAY) |
DX (134) |
2006-2006 |
01 |
| 005 |
88993911 |
ARMREST, R/SEAT (INCLS 3) (EBONY) |
DW (192) |
2005-2006 |
01 |
| 005 |
88993912 |
ARMREST, R/SEAT (INCLS 3) (GRAY) |
DW (132) |
2005-2006 |
01 |
| 005 |
88993913 |
ARMREST, R/SEAT (INCLS 3) (CASHMERE) |
DW (322) |
2005-2006 |
01 |
| 005 |
88995125 |
ARMREST, R/SEAT (INCLS 3) (EBONY) |
DW (193) |
2005-2006 |
01 |
| 005 |
88995126 |
ARMREST, R/SEAT (INCLS 3) (CASHMERE) |
DW (323) |
2005-2006 |
01 |
| 005 |
88995273 |
ARMREST, R/SEAT (INCLS 3) (GRAY) |
DW (133) |
2005-2008 |
01 |
| 006 |
11508388 |
ГАЙКА, HEX W/CON WA, M6X1, 23.75 O.D., 5.55THK, 9, POR (R/SEAT) (8.915) |
|
2005-2010 |
04 |
| 007 |
19123277 |
COVER, R/SEAT CUSH (GRAY) |
DX (134) |
2006-2006 |
01 |
| 007 |
88992790 |
COVER, R/SEAT CUSH (GRAY) |
DW (132) (EXC KA6) |
2005-2006 |
01 |
| 007 |
88992791 |
COVER, R/SEAT CUSH (EBONY) |
DW (192) (EXC KA6) |
2005-2006 |
01 |
| 007 |
88992792 |
COVER, R/SEAT CUSH (CASHMERE) |
DW (322) (EXC KA6) |
2005-2006 |
01 |
| 007 |
88992793 |
COVER, R/SEAT CUSH (GRAY) |
DW (KA6, 132) |
2005-2006 |
01 |
| 007 |
88992794 |
COVER, R/SEAT CUSH (EBONY) |
DW (KA6, 192) |
2005-2006 |
01 |
| 007 |
88992795 |
COVER, R/SEAT CUSH (CASHMERE) |
DW (KA6, 322) |
2005-2006 |
01 |
| 007 |
88995110 |
COVER, R/SEAT CUSH (CASHMERE) |
DW (KA6, 323) |
2005-2006 |
01 |
| 007 |
88995111 |
COVER, R/SEAT CUSH (EBONY) |
DW (KA6, 193) |
2005-2006 |
01 |
| 007 |
88995256 |
COVER, R/SEAT CUSH (EBONY) (15.000) |
DW (193) (EXC KA6) |
2005-2006 |
01 |
| 007 |
88995257 |
COVER, R/SEAT CUSH (CASHMERE) (15.000) |
DW (323) (EXC KA6) |
2005-2006 |
01 |
| 007 |
88995258 |
COVER, R/SEAT CUSH (GRAY) (15.000) |
DW (133) (EXC KA6) |
2005-2009 |
01 |
| 007 |
88995259 |
COVER, R/SEAT CUSH (GRAY) |
DW (KA6, 133) |
2005-2009 |
01 |
| 007 |
88995714 |
COVER, R/SEAT CUSH (EBONY W/RED INSERT) |
DX (674) |
2006-2006 |
01 |
| 007 |
88995715 |
COVER, R/SEAT CUSH (EBONY) |
DX (194) |
2006-2006 |
01 |
| 008 |
19123042 |
PAD, R/SEAT CUSH (W/FRM) (BUILT OCT 10, 2005 AFTER) (FOR 1ST DES SEE 88949048) |
D29 (2ND DES) |
2006-2006 |
01 |
| 008 |
88949048 |
PAD, R/SEAT CUSH (W/FRM) (BUILT PRIOR TO OCT 10, 2005) (FOR 2ND DES SEE 19123042) |
D29 (1ST DES) |
2006-2006 |
01 |
| 009 |
88993003 |
HARNESS, R/SEAT HTR (11.610) |
D29 |
2005-2010 |
01 |
| 010 |
88992782 |
COVER, R/SEAT BK CUSH (GRAY) |
DW (A82, 132) (EXC KA6) (EXPORT) |
2005-2006 |
01 |
| 010 |
88992783 |
COVER, R/SEAT BK CUSH (EBONY) |
DW (A82, 192) (EXC KA6) (EXPORT) |
2005-2006 |
01 |
| 010 |
88992784 |
COVER, R/SEAT BK CUSH (CASHMERE) |
DW (A82, 322) (EXC KA6) (EXPORT) |
2005-2006 |
01 |
| 010 |
88995102 |
COVER, R/SEAT BK CUSH (EBONY) |
DW (KA6, 193) |
2005-2006 |
01 |
| 010 |
88995241 |
COVER, R/SEAT BK CUSH (GRAY) |
DW (A82, KA6, 132) (EXPORT) |
2005-2006 |
01 |
| 010 |
88995242 |
COVER, R/SEAT BK CUSH (EBONY) |
DW (A82, KA6, 192) (EXPORT) |
2005-2007 |
01 |
| 010 |
88995243 |
COVER, R/SEAT BK CUSH (CASHMERE) |
DW (A82, KA6, 322) (EXPORT) |
2005-2006 |
01 |
| 010 |
88995251 |
COVER, R/SEAT BK CUSH (GRAY) |
DW (A82, 133) (EXC KA6) (EXPORT) |
2005-2009 |
01 |
| 010 |
88995252 |
COVER, R/SEAT BK CUSH (EBONY) |
DW (A82, 193) (EXC KA6) (EXPORT) |
2005-2006 |
01 |
| 010 |
88995253 |
COVER, R/SEAT BK CUSH (CASHMERE) |
DW (A82, 323) (EXC KA6) (EXPORT) |
2005-2006 |
01 |
| 010 |
88995721 |
COVER, R/SEAT BK CUSH (GRAY) |
DX (A82, 134) (EXPORT) |
2006-2007 |
01 |
| 010 |
88995722 |
COVER, R/SEAT BK CUSH (CASHMERE) |
DX (A82, 314) (EXPORT) |
2006-2006 |
01 |
| 010 |
88995723 |
COVER, R/SEAT BK CUSH (EBONY) |
DX (A82, 194) (EXPORT) |
2006-2006 |
01 |
| 011 |
88949049 |
PAD, R/SEAT BK CUSH |
D29 |
2005-2010 |
01 |
| 012 |
11589015 |
БОЛТ, HWH W/FL WA M4.2X1.41X20, 12.5 O.D., DOG PT, 6010M, 7253M (R/SEAT BK CUSH)
|
2005-2010 |
01 |
|
| 013 |
88993002 |
WIRE, R/SEAT BK CUSH PAD |
D29 |
2005-2010 |
01 |
| 014 |
11515552 |
ГАЙКА, HEX W/CON WA, M10X1.5X13.5, 31.75 OD, 9, ZF (R/SEAT BK CUSH BRKT) |
|
2005-2010 |
04 |
| 015 |
25721760 |
МОДУЛЬ, R/SEAT HTR CONT |
D29 |
2005-2010 |
01 |
| 016 |
88995212 |
РАМА, R/SEAT BK CUSH |
DW |
2005-2010 |
01 |
| 016 |
88995212 |
РАМА, R/SEAT BK CUSH |
DX |
2006-2009 |
01 |
| 017 |
88994546 |
GUIDE, R/SEAT H/RST (EBONY) (W/BUTTON) (11.376) |
DW (19I) |
2006-2006 |
02 |
| 017 |
88994546 |
GUIDE, R/SEAT H/RST (EBONY) (W/BUTTON) (11.376) |
DX (19I, 67I) |
2006-2007 |
02 |
| 017 |
88994608 |
GUIDE, R/SEAT H/RST (GRAY) (W/BUTTON) |
DX (13I) |
2006-2007 |
02 |
| 017 |
88994608 |
GUIDE, R/SEAT H/RST (GRAY) (W/BUTTON) |
DW (13I) |
2006-2009 |
02 |
| 017 |
88994609 |
GUIDE, R/SEAT H/RST (CASHMERE) (W/BUTTON) |
DW (32I) |
2005-2006 |
02 |
| 017 |
88994611 |
GUIDE, R/SEAT H/RST (GRAY) (W/O BUTTON) |
DX (13I) |
2006-2007 |
02 |
| 017 |
88994611 |
GUIDE, R/SEAT H/RST (GRAY) (W/O BUTTON) |
DW (13I) |
2006-2009 |
02 |
| 017 |
88994612 |
GUIDE, R/SEAT H/RST (CASHMERE) (W/O BUTTON) |
DW (32I) |
2005-2006 |
02 |
| 017 |
88994613 |
GUIDE, R/SEAT H/RST (EBONY) (W/O BUTTON) |
DW (19I) |
2005-2006 |
02 |
| 017 |
88994613 |
GUIDE, R/SEAT H/RST (EBONY) (W/O BUTTON) |
DX (19I, 67I) |
2006-2007 |
02 |
| 018 |
19123162 |
RESTRAINT, R/SEAT HD (INCLS 1) (EBONY) (INNER) |
DX (194, 674) |
2006-2006 |
01 |
| 018 |
19123163 |
RESTRAINT, R/SEAT HD (INCLS 1) (GRAY) (INNER) |
DX (134) |
2006-2006 |
01 |
| 018 |
88993928 |
RESTRAINT, R/SEAT HD (INCLS 1) (EBONY) (INNER) |
DW (192) |
2005-2006 |
01 |
| 018 |
88993929 |
RESTRAINT, R/SEAT HD (INCLS 1) (GRAY) (INNER) |
DW (132) |
2005-2006 |
01 |
| 018 |
88993930 |
RESTRAINT, R/SEAT HD (INCLS 1) (CASHMERE) (INNER) |
DW (322) |
2005-2006 |
01 |
| 018 |
88995122 |
RESTRAINT, R/SEAT CTR HD (INCLS 1) (EBONY) |
DW (193) |
2005-2006 |
01 |
| 018 |
88995123 |
RESTRAINT, R/SEAT CTR HD (INCLS 1) (CASHMERE) (INNER)
| DW (323) |
2005-2006 |
01 |
|
| 018 |
88995272 |
RESTRAINT, R/SEAT CTR HD (INCLS 1) (GRAY) |
DW (A82, 133) (EXPORT) |
2005-2009 |
01 |
| 019 |
19123159 |
RESTRAINT, R/SEAT HD (INCLS 2) (EBONY) (OUTER) |
DX (194, 674) |
2006-2006 |
02 |
| 019 |
19123160 |
RESTRAINT, R/SEAT HD (INCLS 2) (GRAY) (OUTER) |
DX (134) |
2006-2006 |
02 |
| 019 |
88993925 |
RESTRAINT, R/SEAT HD (INCLS 2) (EBONY) (OUTER) |
DW (192) |
2005-2006 |
02 |
| 019 |
88993926 |
RESTRAINT, R/SEAT HD (INCLS 2) (GRAY) (OUTER) |
DW (132) |
2005-2006 |
02 |
| 019 |
88993927 |
RESTRAINT, R/SEAT HD (INCLS 2) (CASHMERE) (OUTER) |
DW (322) |
2005-2006 |
02 |
| 019 |
88995119 |
RESTRAINT, R/SEAT HD (INCLS 2) (EBONY) (OUTER) |
DW (193) |
2005-2006 |
02 |
| 019 |
88995120 |
RESTRAINT, R/SEAT HD (INCLS 2) (CASHMERE) (OUTER) |
DW (323) |
2005-2006 |
02 |
| 019 |
88995271 |
RESTRAINT, R/SEAT HD (INCLS 2) (GRAY) (OUTER) |
DW (133) |
2005-2006 |
02 |
| 020 |
19122855 |
GUIDE, R/SEAT SHLDR BELT (EBONY) |
D29 (19I) |
2005-2009 |
01 |
| 020 |
19122856 |
GUIDE, R/SEAT SHLDR BELT (CASHMERE) |
D29 (32I) |
2005-2009 |
01 |
| 020 |
19122857 |
GUIDE, R/SEAT SHLDR BELT (GRAY) |
D29 (13I) |
2005-2009 |
01 |
| 020 |
19122859 |
GUIDE, R/SEAT SHLDR BELT (EBONY) |
D29 (19I) |
2005-2009 |
01 |
| 020 |
19122860 |
GUIDE, R/SEAT SHLDR BELT (CASHMERE) |
D29 (32I) |
2005-2009 |
01 |
| 020 |
19122861 |
GUIDE, R/SEAT SHLDR BELT (GRAY) |
D29 (13I) |
2005-2009 |
01 |
