(6D14-055) - 2006-2009 DW,DY29 СИДЕНЬЕ ПАССАЖИРА (VENTED/HEATED KB6) CADILLAC - STS 2006

Поз.НомерОписаниеПрименениеНоменклатураКол-во
001 15929635 SEAT, PASS (INCLS 2-56, 58-64) (EBONY) DW (AL2, AQ9, KB6, UY5, 193) (EXC AX4, KA1, MTF) 2006-2006 01
002 19123390 COVER, P/SEAT BK CUSH (CASHMERE) DW (AQ9, AX4, 322) (EXC KA1) (EXPORT) 2006-2006 01
002 19123391 COVER, P/SEAT BK CUSH (GRAY) DW (AQ9, AX4, 132) (EXC KA1) (EXPORT) 2006-2006 01
002 19123397 COVER, P/SEAT BK CUSH (EBONY) DW (AQ9, AX4, 193) (EXC KA1) (EXPORT) 2006-2006 01
002 19123398 COVER, P/SEAT BK CUSH (CASHMERE) DW (AQ9, AX4, 323) (EXC KA1) (EXPORT) 2006-2006 01
002 19123399 COVER, P/SEAT BK CUSH (GRAY) DW (AQ9, AX4, 133) (EXC KA1) (EXPORT) 2006-2006 01
002 88992643 COVER, P/SEAT BK CUSH (EBONY) DW (AQ9, UX8, 192) 2006-2006 01
002 88992826 COVER, P/SEAT BK CUSH (GRAY) (W/SIAB, HEAT, BOSE) DW (AL2, AQ9, KB6, UY5, 323) (EXC KA1) 2006-2006 01
002 88992826 COVER, P/SEAT BK CUSH (GRAY) (W/SIAB, HEAT, BOSE) DW (AL2, AQ9, KB6, UY5, 132) (EXC KA1) 2006-2007 01
002 88995086 COVER, P/SEAT BK CUSH (CASHMERE) DW (AL2, AQ9, KB6, UY5, 323) (EXC KA1) 2006-2006 01
002 88995087 COVER, P/SEAT BK CUSH (EBONY) (W/BOSE) DW (AL2, AQ9, KB6, UY5, 193) (EXC KA1) 2006-2006 01
002 88995269 COVER, P/SEAT BK CUSH (GRAY) DW (AL2, AQ9, KB6, UY5, 133) (EXC KA1) 2006-2009 01
003 88992715 COVER, P/SEAT CUSH (EBONY) DW (AL2, AQ9, KB6, 192) (EXC KA1) 2006-2006 01
003 88992716 COVER, P/SEAT CUSH (CASHMERE) DW (AL2, AQ9, KB6, 322) (EXC KA1) 2006-2006 01
003 88992717 COVER, P/SEAT CUSH (GRAY) DW (AL2, AQ9, KB6, 132) (EXC KA1) 2006-2006 01
003 88994372 COVER, P/SEAT CUSH (EBONY) DW (192) (EXC AL2) 2006-2006 01
003 88994373 COVER, P/SEAT CUSH (CASHMERE) DW (322) (EXC AL2) 2006-2006 01
003 88995092 COVER, P/SEAT CUSH (CASHMERE) DW (323) 2006-2006 01
003 88995093 COVER, P/SEAT CUSH (EBONY) DW (193) 2006-2006 01
003 88995267 COVER, P/SEAT CUSH (GRAY) (14.924) DW (133) 2006-2009 01
004 PAD, P/SEAT CUSH (ЧАСТЬ OF 64) 2006-2009
005 88993045 ПОДОГРЕВАТЕЛЬ, P/SEAT CUSH (ЧАСТЬ OF 64) DW (KB6) (EXC KA1) 2006-2010 01
006 88992718 COVER, P/SEAT H/RST (EBONY) DW (192) 2006-2006 01
006 88992719 COVER, P/SEAT H/RST (CASHMERE) DW (322) 2006-2006 01
006 88992720 COVER, P/SEAT H/RST (GRAY) DW (132) 2006-2006 01
006 88995098 COVER, P/SEAT H/RST (CASHMERE) DW (323) 2006-2006 01
006 88995099 COVER, P/SEAT H/RST (EBONY) DW (193) 2006-2006 01
006 88995270 COVER, P/SEAT H/RST (GRAY) DW (133) 2006-2009 01
007 88952658 PAD, P/SEAT H/RST D29 2006-2010 01
008 88897670 SUPPORT, P/SEAT H/RST D 2006-2007 01
009 88994546 GUIDE, P/SEAT H/RST (EBONY) (W/BUTTON) DW (19I) 2006-2007 01
009 88994608 GUIDE, P/SEAT H/RST (GRAY) (W/BUTTON) (11.625) DW (13I) 2006-2009 01
009 88994609 GUIDE, P/SEAT H/RST (CASHMERE) (W/BUTTON) (11.625) DW (32I) 2006-2006 01
009 88994611 GUIDE, P/SEAT H/RST (GRAY) (W/O BUTTON) (11.625) DW (13I) 2006-2009 01
009 88994612 GUIDE, P/SEAT H/RST (CASHMERE) (W/O BUTTON) (11.625) DW (32I) 2006-2006 01
009 88994613 GUIDE, P/SEAT H/RST (EBONY) (W/O BUTTON) (11.625) DW (19I) 2006-2006 01
010 11517996 ГАЙКА, HFH, M10X1.5, 11.2THK, 21.5 O.D., 7111M (P/SEAT BELT (RETR SI)) (ACDelco #11517996) 2006-2009 01
011 11570654 ГАЙКА, P/SEAT (4.2 X 1.41) (FITS 8.75 SQ HOLE) (9.665) DW, DX 2006-2009 02
012 88994323 CAP, P/SEAT H/RST GDE DW 2006-2010 01
012 88994324 CAP, P/SEAT H/RST GDE DW 2006-2010 01
013 88992768 PANEL, P/SEAT BK CUSH FIN (FILLER) (INBOARD) DW 2006-2010 01
014 00332364 RETAINER - PUSH IN, FITS HOLE SIZE 0.245 - 0.260, GRIP LENGTH 0.52, 0.7 OD, MATERIAL NYLON 6/6 PER GMP.PA66.015 (P/SEAT BK CUSH FIN PNL (PUSH IN)) 2006-2010 07
015 88993992 COVER, P/SEAT RECL FIN (GRAY) (INBOARD) DW, DX (13I) 2006-2009 01
015 88993993 COVER, P/SEAT RECL FIN (EBONY) (INBOARD) DW (19I) 2006-2006 01
015 88993994 COVER, P/SEAT RECL FIN (CASHMERE) (INBOARD) DW (32I) 2006-2006 01
016 88952676 РАМА, P/SEAT CUSH DW 2006-2010 01
017 88994010 COVER, P/SEAT ADJR FIN (GRAY) DW, DX (13I) 2006-2009 01
017 88994011 COVER, P/SEAT ADJR FIN (EBONY) DW (19I) 2006-2006 01
017 88994012 COVER, P/SEAT ADJR FIN (CASHMERE) (RR INBOARD) DW (32I) 2006-2006 01
018 10367763 BELT, P/SEAT (BKL SI) (CASHMERE) DW (AQ9, AX4, UX8, UY5, 322) (EXPORT) 2006-2006 01
018 10367764 BELT, P/SEAT (BKL SI) (GRAY) DW (AX4, 13I) (EXPORT) 2006-2009 01
018 10367765 BELT, P/SEAT (BKL SI) (EBONY) DW (AQ9, AL2, KB6, UY5, 323) (EXC KA1) 2006-2006 01
018 10367765 BELT, P/SEAT (BKL SI) (EBONY) DW (AQ9, AX4, 19I) (EXPORT) 2006-2006 01
018 15210813 BELT, P/SEAT (BKL SI) (CASHMERE) DW (AX4, KA1, 33I) (EXPORT) 2006-2007 01
018 89024406 BELT KIT, P/SEAT (BKL SI) (CASHMERE) DW (32I) (EXC AX4) 2006-2009 01
018 89024408 BELT KIT, P/SEAT (BKL SI) (EBONY) DW (19I) (EXC AX4) 2006-2008 01
019 11517781 NUT-HEX SPL, M10X1.5X20.2, 9, 4345M, 6175M (P/SEAT BELT TR CVR) 2006-2010 01
020 88994292 COVER, P/SEAT BELT OPG TR (RETR SI) (CASHMERE) DW29 (AQ9, 32I) 2006-2009 01
020 88994296 COVER, P/SEAT BELT OPG TR (RETR SI) (GRAY) DW (AQ9, 13I) 2006-2009 01
020 88994298 COVER, P/SEAT BELT OPG TR (RETR SI) (EBONY) DW29 (AQ9, 19I) 2006-2009 01
021 88992747 МОДУЛЬ, P/SEAT HTR CONT (HEAT COOL) DW (KB6) (EXC KA1) 2006-2009 01
022 88993047 ВЕНТИЛЯТОР, P/SEAT CUSH VENTILATION HEAT COOL DW (KB6) 2006-2010 01
023 11509428 БОЛТ/SCREW, HEX, W/FLAT WA, M4.2X1.4X13, 12.3 O.D., BHL PT, 6010M, NO (P/SEAT) (8.977) 2006-2010 06
024 19122908 COVER, P/SEAT CUSH FRT (CASHMERE) DW (322, 323) 2006-2006 01
024 19122909 COVER, P/SEAT CUSH FRT (EBONY) DW (192, 193) 2006-2006 01
024 19122910 COVER, P/SEAT CUSH FRT (GRAY) DW (132, 133) 2006-2009 01
025 88994022 COVER, P/SEAT ADJR FIN (GRAY) (FRT ПОЛ) DW, DX (13I) 2006-2009 01
025 88994023 COVER, P/SEAT ADJR FIN (EBONY) (FRT ПОЛ) DW (19I) 2006-2009 01
025 88994024 COVER, P/SEAT ADJR FIN (CASHMERE) (FRT ПОЛ) DW, DX (32I) 2006-2006 01
026 11515756 БОЛТ, HFH, M8X1.25X20, 17THD, 18 O.D., 10.9, 7114M (P/SEAT RECL LWR FIN CVR) 2006-2010 01
027 88994342 BRACKET, P/SEAT RECL LWR FIN CVR DW 2006-2010 01
028 88992728 ADJUSTER, P/SEAT DW 2006-2010 01
029 11570654 ГАЙКА, P/SEAT (4.2 X 1.41) (FITS 8.75 SQ HOLE) (9.665) DW, DX 2006-2009 02
030 11609257 БОЛТ, PAN HD, TORX, M12X1.75X34, 9.8 STEEL, GMW3179 (P/SEAT ADJR (W/BELT)) (8.907) 2006-2010 02
031 88994016 COVER, P/SEAT ADJR FIN (GRAY) DW, DX (13I) 2006-2009 01
031 88994017 COVER, P/SEAT ADJR FIN (EBONY) DW (19I) 2006-2009 01
031 88994018 COVER, P/SEAT ADJR FIN (CASHMERE) DW (32I) 2006-2006 01
032 25752511 KNOB, P/SEAT RECL (GRAY) D29 (13I) 2006-2009 01
032 25770401 KNOB, P/SEAT RECL (CASHMERE) DW (32I) 2006-2006 01
032 89043626 KNOB, P/SEAT RECL (EBONY) (11.588) DW, DX (19I) 2006-2006 01
033 12450264 SWITCH, P/SEAT ADJR (8-WAY) D29 2006-2006 01
034 12451443 KNOB, P/SEAT ADJR SW (EBONY) (11.588) DW, DX (19I) 2006-2006 01
034 25752512 KNOB, P/SEAT ADJR SW (GRAY) D29 (13I) 2006-2006 01
034 25770402 KNOB, P/SEAT ADJR SW (CASHMERE) DW (32I) 2006-2006 01
035 25745585 SWITCH, P/SEAT LUMBAR CONT (CASHMERE) DW (32I) 2006-2006 01
035 25752513 SWITCH, P/SEAT LUMBAR CONT (GRAY) D29 (13I) 2006-2009 01
035 25770400 SWITCH, P/SEAT LUMBAR CONT (EBONY) (USED W/4-WAY PWR LUMBAR) D29 (19I) 2006-2006 01
036 25742613 PLATE, P/SEAT BELT ANC (RETR SI) D29 2006-2009 01
037 11517996 ГАЙКА, P/SEAT BELT (BKL SI) (M10X1.5, 11.2 THK) (8.917) (ACDelco #11517996) DW, DX 2006-2009 04
038 88993974 BEZEL, P/SEAT ADJR SW (GRAY) DW (AL2, 13I) 2006-2009 01
038 88993975 BEZEL, P/SEAT ADJR SW (EBONY) DW (AL2, 19I) 2006-2006 01
038 88993976 BEZEL, P/SEAT ADJR SW (CASHMERE) DW (AL2, 32I) 2006-2006 01
039 88993986 COVER, P/SEAT RECL FIN (GRAY) (OUTBOARD) DW, DX (13I) 2006-2009 01
039 88993987 COVER, P/SEAT RECL FIN (EBONY) (OUTBOARD) DW (19I) 2006-2006 01
039 88993988 COVER, P/SEAT RECL FIN (CASHMERE) (OUTBOARD) DW (32I) 2006-2006 01
040 15218855 HARNESS, INFL RST WRG D29 (IL2, IL3) 2006-2010 02
041 19123419 HARNESS, P/SEAT WRG (LUMBAR/HEAT COOL) D29 2006-2009 01
041 88996097 HARNESS, P/SEAT WRG (LUMBAR, HEAT, SUP) DW 2006-2010 01
041 88996099 HARNESS, P/SEAT WRG DW29 (AL2, AQ9, KB6, UY5) (EXC AX4, KA1, MTF) 2006-2006 01
041 88996099 HARNESS, P/SEAT WRG DW29 (AL2, AQ9, AX4, KB6, UY5) (EXC KA1, MTF) 2006-2007 01
041 88996099 HARNESS, P/SEAT WRG DW29 (AL2, AQ9, IL3, KB6, UY5) (EXC AX4, KA1) 2006-2009 01
042 15781669 МОДУЛЬ, P/SEAT SI INFL RST (GRAY) DW (132) 2006-2007 01
042 15939007 МОДУЛЬ, P/SEAT SI INFL RST (CASHMERE) DW (32I) 2006-2009 01
042 25760561 МОДУЛЬ, P/SEAT SI INFL RST (GRAY) DW (13I) 2006-2006 01
042 25760562 МОДУЛЬ, P/SEAT SI INFL RST (EBONY) DW, DX (19I) 2006-2007 01
043 88993161 ШЛАНГИ, INFL RST F/SEAT SI MDL DW 2006-2010 01
043 88993162 ШЛАНГИ, INFL RST F/SEAT SI MDL DW 2006-2010 01
044 11516075 ГАЙКА, HFH SELF LK, M6X1, 7.7THK, 14.2 O.D., 9, PZOR (P/SEAT SI INFL RST) 2006-2010 04
045 88992020 PANEL, P/SEAT BK CUSH FIN (FILLER) (OUTBOARD) DW, DX 2006-2009 01
045 88992768 PANEL, P/SEAT BK CUSH FIN (FILLER) (INBOARD) DW, DX 2006-2009 01
046 88994921 РАМА, P/SEAT BK CUSH (W/O MEMORY) (W/RECL MOTOR) DW, DX 2006-2009 01
047 88994004 COVER, P/SEAT ADJR FIN (GRAY) (RR) DW, DX (13I) 2006-2009 01
047 88994005 COVER, P/SEAT ADJR FIN (EBONY) (RR) DW (19I) 2006-2006 01
047 88994006 COVER, P/SEAT ADJR FIN (CASHMERE) (RR) DW (32I) 2006-2006 01
048 19123713 PANEL, P/SEAT BK CUSH FIN (GRAY) (MATTE FINISH) DW (132) 2006-2009 01
048 19123714 PANEL, P/SEAT BK CUSH FIN (EBONY) (MATTE FINISH) DW (192) 2006-2006 01
048 88993967 PANEL, P/SEAT BK CUSH FIN (GRAY) DW (132) 2006-2006 01
048 88993968 PANEL, P/SEAT BK CUSH FIN (EBONY) DW (192) 2006-2006 01
048 88993969 PANEL, P/SEAT BK CUSH FIN (CASHMERE) DW (322) 2006-2006 01
048 88995213 PANEL, P/SEAT BK CUSH FIN (CASHMERE) DW (323) 2006-2006 01
048 88995214 PANEL, P/SEAT BK CUSH FIN (EBONY) DW (193) 2006-2006 01
048 88995265 PANEL, P/SEAT BK CUSH FIN (GRAY) DW (133) 2006-2009 01
049 88993281 RETAINER, D/SEAT BK CUSH FIN PNL (TRIM RING) (14.924) DW 2006-2010 01
050 11609406 SCREW, RD, M4.2X1.41X20, TYPE AB PT, GM6010M, GMW4205 (P/SEAT BK CUSH FRM) 2006-2010 02
051 88992597 ШЛАНГИ, P/SEAT H/RST SPKR (LOWER) DW29 (AL2, AQ9, A45) (EXC KA1) 2006-2009 01
051 88992598 ШЛАНГИ, P/SEAT H/RST SPKR DW29 (AL2, AQ9, A45) (EXC KA1) 2006-2009 01
052 88992595 ШЛАНГИ, P/SEAT H/RST SPKR DW29 (AL2, AQ9, AX4, A45, IL3, KB6, UY5, 133, 193, 323, 393) (EXC KA1) 2006-2008 01
052 88992596 ШЛАНГИ, P/SEAT H/RST SPKR (UPPER) DW29 (AL2, AQ9, A45, KA1) 2006-2009 01
053 SUPPORT, P/SEAT H/RST SPKR HSG 2006-2010
053 88992600 SUPPORT, P/SEAT H/RST SPKR HSG DW29 2006-2007 02
054 SPEAKER, P/SEAT H/RST 2006-2010
054 25773787 SPEAKER, P/SEAT H/RST DW29 (AL2, AQ9, UY5) 2006-2007 02
055 БОЛТ, P/SEAT BK CUSH FRM 2006-2009
056 GRILLE, P/SEAT H/RST SPKR 2006-2010
056 88994025 GRILLE, P/SEAT H/RST SPKR (LT. GREY) DW29 (132, KA1) 2006-2006 02
056 88994025 GRILLE, P/SEAT H/RST SPKR (LT. GREY) D29 (132, 133) (EXC KA1) 2006-2007 02
056 88994026 GRILLE, P/SEAT H/RST SPKR (EBONY) DW29 (AL2, AQ9, A45, KB6, UY5, 193) (EXC KA1) 2006-2009 02
056 88994027 GRILLE, P/SEAT H/RST SPKR (CASHMERE) DW29 (323) (EXC KA1, MTF) 2006-2006 02
058 19124085 ПОДОГРЕВАТЕЛЬ, P/SEAT BK CUSH DW (KB6) (EXC KA1) 2006-2010 01
059 88993050 LUMBAR SUB, P/SEAT D29 2006-2010 01
060 88993048 ВЕНТИЛЯТОР, P/SEAT BACK VENTILATION HEAT COOL DW (KB6) 2006-2010 01
061 88992747 МОДУЛЬ, P/SEAT HTR CONT (HEAT COOL) DW (KB6) (EXC KA1) 2006-2009 01
062 BRACKET, P/SEAT CUSH FRM FRT 2006-2010
062 88994322 BRACKET, P/SEAT CUSH FRM FRT DW, DX (AX4) (EXPORT) 2006-2009 01
063 19124089 PAD, P/SEAT BK CUSH (W/HEAT, COOL) (W/O BOSE) DW (KB6) (EXC KA1) 2006-2009 01
063 88992743 PAD, P/SEAT BK CUSH (W/SIAB, HEAT, COOL, BOSE) (11.419) DW (KB6) (EXC KA1) 2006-2009 01
064 19123721 МОДУЛЬ KIT, INFL RST FRT PASS PRESENCE (W/ SEN) (INCLS 4, 5) DW (KB6) (EXC KA1) 2006-2010 01
