| Поз. | Номер | Описание | Применение | Номенклатура | Кол-во |
| 001 |
15231209 |
MIRROR, O/S RR VIEW (INCLS 2) (PEARL) |
DW (DR2, 06U) (EXC A45) |
2005-2005 |
01 |
| 001 |
15231210 |
MIRROR, O/S RR VIEW (INCLS 2) (PEARL) |
DW (A45, DR2, 06U) |
2005-2005 |
01 |
| 001 |
15231211 |
MIRROR, O/S RR VIEW (INCLS 2) (PEARL) |
DW (A45, DR2, 06U) |
2005-2005 |
01 |
| 001 |
15248443 |
MIRROR, O/S RR VIEW (INCLS 2) (RED) |
DW (DR2, 29U) (EXC A45) |
2005-2005 |
01 |
| 001 |
15248449 |
MIRROR, O/S RR VIEW (INCLS 2) (GRAY) |
DW (DR2, 62U) (EXC A45) |
2005-2005 |
01 |
| 001 |
15248450 |
MIRROR, O/S RR VIEW (INCLS 2) (GRAY) |
DW (DR2, 62U) (EXC A45) |
2005-2005 |
01 |
| 001 |
15248482 |
MIRROR, O/S RR VIEW (INCLS 2) (SILVER) |
DW (A45, DR2, 92U) |
2005-2005 |
01 |
| 001 |
15248500 |
MIRROR, O/S RR VIEW (INCLS 2) (RED) (USE ON VEHICLES BUILT 03/21/05 AFTER) (FOR 1ST DES SEE 25767417) |
DW (A45, DL7, 29U) (EXC Z5X, Z5Y) (2ND DES) |
2005-2005 |
01 |
| 001 |
15248506 |
MIRROR, O/S RR VIEW (INCLS 2) (GRAY) |
DW (A45, DL7, 62U) (EXC Z5X, Z5Y) |
2005-2005 |
01 |
| 001 |
15248521 |
MIRROR, O/S RR VIEW (INCLS 2) (WHITE) |
DW (A45, DL7, Z5X, 98U) (EXC Z5Y) (EXPORT) |
2005-2005 |
01 |
| 001 |
15248522 |
MIRROR, O/S RR VIEW (INCLS 2) (WHITE) |
DW (A45, DL7, Z5X, 98U) (EXC Z5Y) (EXPORT) |
2005-2005 |
01 |
| 001 |
15248557 |
MIRROR, O/S RR VIEW (INCLS 2) (RED) |
DW (A45, DL7, Z5Y, 29U) (EXC Z5X) (EXPORT) |
2005-2005 |
01 |
| 001 |
15248558 |
MIRROR, O/S RR VIEW (INCLS 2) (RED) |
DW (A45, DL7, Z5Y, 29U) (EXC Z5X) (EXPORT) |
2005-2005 |
01 |
| 001 |
15248563 |
MIRROR, O/S RR VIEW (INCLS 2) (GRAY) |
DW (A45, DL7, Z5Y, 62U) (EXC Z5X) (EXPORT) |
2005-2005 |
01 |
| 001 |
15248564 |
MIRROR, O/S RR VIEW (INCLS 2) (GRAY) |
DW (A45, DL7, Z5Y, 62U) (EXC Z5X) (EXPORT) |
2005-2005 |
01 |
| 001 |
15248567 |
MIRROR, O/S RR VIEW (INCLS 2) (SILVER) (USE ON VEHICLES BUILT 03/28/05 AFTER) (FOR 1ST DES SEE 25767458) |
DW (A45, DL7, Z5Y, 92U) (EXC Z5X) (2ND DES) (EXPORT) |
2005-2005 |
01 |
| 001 |
15248568 |
MIRROR, O/S RR VIEW (INCLS 2) (SILVER) (USE ON VEHICLES BUILT 03/28/05 AFTER) (FOR 1ST DES SEE 25767459) |
DW (A45, DL7, Z5Y, 92U) (EXC Z5X) (2ND DES) (EXPORT) |
2005-2005 |
01 |
| 001 |
15819742 |
MIRROR, O/S RR VIEW (WHEN USING TO SERVICE VEHICLES BUILT 09/18/05 AND PRIOR, MUST BE CHANGED T/W GASKET 15812404.) (INCLS 2) (WHITE) |
DW (DR2, 98U) (EXC A45) |
2005-2005 |
01 |
| 001 |
15819748 |
MIRROR, O/S RR VIEW (WHEN USING TO SERVICE VEHICLES BUILT 09/18/05 AND PRIOR, MUST BE CHANGED T/W GASKET P/N 15812404.) (INCLS 2) (SILVER) |
DW (DR2, 42U) (EXC A45) |
2005-2006 |
01 |
| 001 |
15819799 |
MIRROR, O/S RR VIEW (WHEN USING TO SERVICE VEHICLES BUILT 09/18/05 AND PRIOR, MUST BE CHANGED T/W GASKET P/N 15812405.) (INCLS 2) (WHITE) |
DW (A45, DL7, 98U) (EXC Z5X, Z5Y) |
2005-2006 |
01 |
| 001 |
15819802 |
MIRROR, O/S RR VIEW (WHEN USING TO SERVICE VEHICLES BUILT 09/18/05 AND PRIOR, MUST BE CHANGED T/W GASKET 15812404.) (INCLS 2) (BLUE) (USE ON VEHICLES BUILT 03/21/05 AFTER) (FOR 1ST DES SEE 25767414) |
DW (A45, DL7, 25U) (EXC Z5X, Z5Y) (2ND DES) |
2005-2005 |
01 |
| 001 |
15819807 |
MIRROR, O/S RR VIEW (WHEN USING TO SERVICE VEHICLES BUILT 09/18/05 AND PRIOR, MUST BE CHANGED T/W GASKET 15812405.) (INCLS 2) (GOLD) (USE ON VEHICLES BUILT 03/28/05 AFTER) (FOR 1ST DES SEE 25767421) |
DW (A45, DL7, 61U) (EXC Z5X, Z5Y) (2ND DES) |
2005-2005 |
01 |
| 001 |
15819831 |
MIRROR, O/S RR VIEW (WHEN USING TO SERVICE VEHICLES BUILT 09/18/05 AND PRIOR, MUST BE CHANGED T/W GASKET 15812405.) (INCLS 2) (BLUE) |
DW (A45, DL7, Z5X, 25U) (EXC Z5Y) (EXPORT) |
2005-2005 |
01 |
| 001 |
15819832 |
MIRROR, O/S RR VIEW (WHEN USING TO SERVICE VEHICLES BUILT 09/18/05 AND PRIOR, MUST BE CHANGED T/W GASKET 15812404.) (INCLS 2) (SILVER) |
DW (A45, DL7, Z5X, 42U) (EXC Z5Y) (EXPORT) |
2005-2005 |
01 |
| 001 |
15819833 |
MIRROR, O/S RR VIEW (WHEN USING TO SERVICE VEHICLES BUILT 09/18/05 AND PRIOR, MUST BE CHANGED T/W GASKET 15812405.) (INCLS 2) (SILVER) |
DW (A45, DL7, Z5X, 42U) (EXC Z5Y) (EXPORT) |
2005-2005 |
01 |
| 001 |
15819834 |
MIRROR, O/S RR VIEW (WHEN USING TO SERVICE VEHICLES BUILT 09/18/05 AND PRIOR, MUST BE CHANGED T/W GASKET 15812404.) (INCLS 2) (GOLD) (USE ON VEHICLES BUILT 03/28/05 AFTER) (FOR 1ST DES SEE 25767436) |
DW (A45, DL7, Z5X, 61U) (EXC Z5Y) (2ND DES) (EXPORT) |
2005-2005 |
01 |
| 001 |
15819836 |
MIRROR, O/S RR VIEW (WHEN USING TO SERVICE VEHICLES BUILT 09/18/05 AND PRIOR, MUST BE CHANGED T/W GASKET 15812404.) (INCLS 2) (SILVER) |
DW (A45, DL7, Z5X, 67U) (EXC Z5Y) (EXPORT) |
2005-2005 |
01 |
| 001 |
15819854 |
MIRROR, O/S RR VIEW (WHEN USING TO SERVICE VEHICLES BUILT 09/18/05 AND PRIOR, MUST BE CHANGED T/W GASKET P/N 15812404.) (INCLS 2) (WHITE) |
DW (A45, DL7, Z5Y, 98U) (EXC Z5X) (EXPORT) |
2005-2006 |
01 |
| 001 |
15819868 |
MIRROR, O/S RR VIEW (WHEN USING TO SERVICE VEHICLES BUILT 09/18/05 AND PRIOR, MUST BE CHANGED T/W GASKET P/N 15812404.) (INCLS 2) (SILVER) |
DW (A45, DL7, Z5Y, 67U) (EXC Z5X) (EXPORT) |
2005-2006 |
01 |
| 001 |
15819869 |
MIRROR, O/S RR VIEW (WHEN USING TO SERVICE VEHICLES BUILT 09/18/05 AND PRIOR, MUST BE CHANGED T/W GASKET P/N 15812405.) (INCLS 2) (SILVER) (USE ON VEHICLES BUILT 03/14/05 AFTER) (FOR 1ST DES SEE 25767457) |
DW (A45, DL7, Z5Y, 67U) (EXC Z5X) (2ND DES) (EXPORT) |
2005-2005 |
01 |
| 001 |
25767395 |
MIRROR, O/S RR VIEW (INCLS 2) (GREEN) |
DW (DR2, 92U) (EXC A45) |
2005-2005 |
01 |
| 001 |
25767414 |
MIRROR, O/S RR VIEW (INCLS 2) (BLUE) |
DW (A45, DL7, 25U) (EXC Z5X, Z5Y) |
2005-2005 |
01 |
| 001 |
25767415 |
MIRROR, O/S RR VIEW (INCLS 2) (BLUE) |
DW (A45, DL7, 25U) (EXC Z5X, Z5Y) |
2005-2005 |
01 |
| 001 |
25767416 |
MIRROR, O/S RR VIEW (INCLS 2) (RED) |
DW (A45, DL7, 29U) (EXC Z5X, Z5Y) |
2005-2005 |
01 |
| 001 |
25767417 |
MIRROR, O/S RR VIEW (INCLS 2) (RED) |
DW (A45, DL7, 29U) (EXC Z5X, Z5Y) |
2005-2005 |
01 |
| 001 |
25767419 |
MIRROR, O/S RR VIEW (INCLS 2) (SILVER) |
DW (A45, DL7, 42U) (EXC Z5X, Z5Y) |
2005-2005 |
01 |
| 001 |
25767421 |
MIRROR, O/S RR VIEW (INCLS 2) (GOLD) (USE ON VEHICLES BUILT 03/27/05 PRIOR) (FOR 2ND DES SEE 15819807) |
DW (A45, DL7, 61U) (EXC Z5X, Z5Y) (1ST DES) |
2005-2005 |
01 |
| 001 |
25767422 |
MIRROR, O/S RR VIEW (INCLS 2) (GRAY) |
DW (A45, DL7, 62U) (EXC Z5X, Z5Y) |
2005-2005 |
01 |
| 001 |
25767426 |
MIRROR, O/S RR VIEW (INCLS 2) (GREEN) |
DW (A45, DL7, 92U) (EXC Z5X, Z5Y) |
2005-2005 |
01 |
| 001 |
25767436 |
MIRROR, O/S RR VIEW (INCLS 2) (GOLD) (USE ON VEHICLES BUILT 03/27/05 PRIOR) (FOR 2ND DES SEE 15819834) |
DW (A45, DL7, Z5X, 61U) (EXC Z5Y) (1ST DES) (EXPORT) |
2005-2005 |
01 |
| 001 |
25767438 |
MIRROR, O/S RR VIEW (INCLS 2) (GRAY) |
DW (A45, DL7, Z5X, 62U) (EXC Z5Y) (EXPORT) |
2005-2005 |
01 |
| 001 |
25767442 |
MIRROR, O/S RR VIEW (INCLS 2) (SILVER) |
DW (A45, DL7, Z5X, 92U) (EXC Z5Y) (EXPORT) |
2005-2005 |
01 |
| 001 |
25767452 |
MIRROR, O/S RR VIEW (INCLS 2) (GOLD) |
DW (A45, DL7, Z5Y, 61U) (EXC Z5X) (EXPORT) |
2005-2005 |
01 |
| 001 |
25767453 |
MIRROR, O/S RR VIEW (INCLS 2) (GOLD) |
DW (A45, DL7, Z5Y, 61U) (EXC Z5X) (EXPORT) |
2005-2005 |
01 |
| 001 |
25767457 |
MIRROR, O/S RR VIEW (INCLS 2) (SILVER) (USE ON VEHICLES BUILT 03/13/05 PRIOR) (FOR 2ND DES SEE 15819869) |
DW (A45, DL7, Z5Y, 67U) (EXC Z5X) (1ST DES) (EXPORT) |
2005-2005 |
01 |
| 001 |
25767458 |
MIRROR, O/S RR VIEW (INCLS 2) (SILVER) (USE ON VEHICLES BUILT 03/27/05 PRIOR) (FOR 2ND DES SEE 15248567) |
DW (A45, DL7, Z5Y, 92U) (EXC Z5X) (1ST DES) (EXPORT) |
2005-2005 |
01 |
| 001 |
25767459 |
MIRROR, O/S RR VIEW (INCLS 2) (SILVER) (USE ON VEHICLES BUILT 03/27/05 PRIOR) (FOR 2ND DES SEE 15248568) |
DW (A45, DL7, Z5Y, 92U) (EXC Z5X) (1ST DES) (EXPORT) |
2005-2005 |
01 |
| 001 |
25827587 |
MIRROR, O/S RR VIEW (WHEN USING TO SERVICE VEHICLES BUILT 09/18/05 AND PRIOR, MUST BE CHANGED T/W GASKET 15812404.) (INCLS 2) (КРАСКА TO MATCH) |
DW (A45, DL7, Z5Y) (EXC Z5X) (EXPORT) |
2005-2005 |
01 |
| 001 |
25827588 |
MIRROR, O/S RR VIEW (WHEN USING TO SERVICE VEHICLES BUILT 09/18/05 AND PRIOR, MUST BE CHANGED T/W GASKET 15812405.) (INCLS 2) (КРАСКА TO MATCH) |
DW (A45, DL7, Z5Y) (EXC Z5X) |
2005-2005 |
01 |
| 001 |
25827589 |
MIRROR, O/S RR VIEW (WHEN USING TO SERVICE VEHICLES BUILT 09/18/05 AND PRIOR, MUST BE CHANGED T/W GASKET P/N 15812404.) (INCLS 2) (КРАСКА TO MATCH) (REPL ALL COLORS) |
DW (DR2) |
2005-2006 |
01 |
| 001 |
25827590 |
MIRROR, O/S RR VIEW (WHEN USING TO SERVICE VEHICLES BUILT 09/18/05 AND PRIOR, MUST BE CHANGED T/W GASKET P/N 15812405.) (INCLS 2) (КРАСКА TO MATCH) (REPL ALL COLORS) |
DW (DR2) |
2005-2006 |
01 |
| 001 |
25827591 |
MIRROR, O/S RR VIEW (WHEN USING TO SERVICE VEHICLES BUILT 09/18/05 AND PRIOR, MUST BE CHANGED T/W GASKET P/N 15812404.) (INCLS 2) (КРАСКА TO MATCH) (REPL ALL COLORS) |
DW (DL7, Z5X) (EXPORT) |
2005-2006 |
01 |
| 001 |
25827592 |
MIRROR, O/S RR VIEW (WHEN USING TO SERVICE VEHICLES BUILT 09/18/05 AND PRIOR, MUST BE CHANGED T/W GASKET P/N 15812405.) (INCLS 2) (КРАСКА TO MATCH) (REPL ALL COLORS) |
DW (DL7, Z5X) (EXPORT) |
2005-2006 |
01 |
| 001 |
25827593 |
MIRROR, O/S RR VIEW (WHEN USING TO SERVICE VEHICLES BUILT 09/18/05 AND PRIOR, MUST BE CHANGED T/W GASKET P/N 15812405.) (INCLS 2) (КРАСКА TO MATCH) |
DW (A45, DL7) (EXC Z5X, Z5Y) |
2005-2006 |
01 |
| 001 |
25827594 |
MIRROR, O/S RR VIEW (WHEN USING TO SERVICE VEHICLES BUILT 09/18/05 AND PRIOR, MUST BE CHANGED T/W GASKET P/N 15812404.) (INCLS 2) (КРАСКА TO MATCH)
| DW (A45, DL7) (EXC Z5X, Z5Y) |
2005-2006 |
01 |
|
| 002 |
88980973 |
GLASS, O/S RR VIEW MIR (ЧАСТЬ OF 1) |
DW (DL7, DR2, Z5Y) (EXC Z5X) |
2005-2005 |
01 |
| 002 |
88980974 |
GLASS, O/S RR VIEW MIR (ЧАСТЬ OF 1) |
DW (DR2) |
2005-2005 |
01 |
| 002 |
88980975 |
GLASS, O/S RR VIEW MIR (ЧАСТЬ OF 1) |
DW (A45, DL7) (EXC Z5X, Z5Y) |
2005-2005 |
01 |
| 002 |
88980976 |
GLASS, O/S RR VIEW MIR (ЧАСТЬ OF 1) |
DW (A45, DL7) (EXC Z5X, Z5Y) |
2005-2005 |
01 |
| 002 |
88980977 |
GLASS, O/S RR VIEW MIR (W/BKG PLATE) (ЧАСТЬ OF 1) |
DW (A45, DL7, Z5X) (EXC Z5Y) (EXPORT) |
2005-2006 |
01 |
| 002 |
88980978 |
GLASS, O/S RR VIEW MIR (W/BKG PLATE) (ЧАСТЬ OF 1) |
DW (A45, DL7, Z5X) (EXC Z5Y) (EXPORT) |
2005-2006 |
01 |
| 002 |
88980979 |
GLASS, O/S RR VIEW MIR (ЧАСТЬ OF 1)
| DW (A45, DL7, Z5Y) (EXC Z5X) |
2005-2006 |
01 |
|
| 003 |
11609411 |
ГАЙКА, HEX W/CON WA, M6X1, 5.7 THK, 16 OD, 9, GMW3200 (O/S RR VIEW MIR REINF)
|
2005-2010 |
06 |
|
| 004 |
15812405 |
GASKET, O/S RR VIEW MIR |
DW |
2005-2010 |
01 |
| 004 |
25909276 |
GASKET, O/S RR VIEW MIR |
DW |
2005-2010 |
01 |
