| Поз. | Номер | Описание | Применение | Номенклатура | Кол-во |
| 560 |
12580644 |
RAIL, SEQ M/PORT F/INJN FUEL (INCLS 580, 581) (ACDelco #217-1556) |
D (LH2) |
2005-2006 |
01 |
| 561 |
|
INJECTOR, M/PORT FUEL (*KIT1) |
|
2005-2006 |
|
| 562 |
|
RETAINER, F/INJR (*KIT1, KIT2) |
|
2005-2006 |
|
| 563 |
|
SEAL, F/INJR (O RING) (UPPER) (*KIT1, KIT3) |
|
2005-2006 |
|
| 564 |
|
SEAL, F/INJR (O RING) (LOWER) (*KIT1, KIT3) |
|
2005-2006 |
|
| 565 |
12584592 |
CAP, FUEL PRESS SERV VLV (ЧАСТЬ OF 566) (INCLUDES CAP AND VALVE) (ACDelco #12584592)
| D (LC3, LH2) |
2005-2006 |
01 |
|
| 565 |
25532662 |
CAP, FUEL PRESS SERV VLV (ЧАСТЬ OF 566) (CAP FOR PRESSURE TEST SCHRADER VALVE) (3.163) (ACDelco #214-1044)
| D (LH2) |
2005-2006 |
01 |
|
| 566 |
12580648 |
VALVE KIT, FUEL PRESS SERV (INCLS 565) (ACDelco #12580648) |
D (LH2) |
2005-2006 |
01 |
| 580 |
|
DAMPENER, FUEL PULSE (ЧАСТЬ OF 560) |
|
2005-2006 |
|
| 581 |
|
SEAL, FUEL PULSE DPNR (ЧАСТЬ OF 560) |
|
2005-2006 |
|
| K01 |
12580645 |
INJECTOR KIT, SEQ M/PORT FUEL (INCLS 561-564) (INCLS 1 INJECTOR, UPR AND LWR SEAL RINGS RET) (ACDelco #217-1553)
| D (LH2) |
2005-2005 |
08 |
|
| K02 |
12580646 |
RETAINER KIT, F/INJR (INCLS 562) (INCLS 8 INJECTOR RET CLIPS) (ACDelco #12580646) |
D (LH2) |
2005-2006 |
01 |
| K03 |
12580647 |
SEAL KIT, F/INJR (O RING) (INCLS 563, 564) (INCLS 8 UPR INJECTOR O-RINGS 8 LWR INJECTOR O-RINGS) (ACDelco #217-1555)
| D (LH2) |
2005-2006 |
01 |
|
