| Поз. | Номер | Описание | Применение | Номенклатура | Кол-во |
| 001 |
22909204 |
MODULE, F/PMP PWR CONT (ACDelco #22909204) (LABELED 22909204) |
N (LFW, LFX) |
2013-2013 |
01 |
| 001 |
25971464 |
MODULE, F/PMP PWR CONT (ACDelco #25971464) (LABELED 25971464) |
N (LFW, LFX) |
2013-2013 |
01 |
| 002 |
11519377 |
BOLT, HEX HD W/FL WA, M6X1X28, 18.15 THD, 17 OD, 8.8 STEEL, GMW3359 (F/PMP PWR CONT MDL) |
|
2013-2013 |
02 |
| 003 |
|
HARNESS, BODY WRG (SEE GROUP 13.000 WIRING HARNESSBODY FOR DETAILED ILLUSTRATED VIEW) |
|
2013-2013 |
|
| 004 |
11570819 |
NUT, F/PMP PWR CONT MDL BRKT (U-DIMPLED) (8.131) |
N |
2013-2013 |
02 |
