| Поз. | Номер | Описание | Применение | Номенклатура | Кол-во |
| 001 |
20907461 |
PLATE, RF CNSL BKG (INCLS 20, 21) |
NG (C3U) |
2012-2013 |
01 |
| 002 |
22848194 |
HARNESS, RF CNSL WRG (PART OF 6) |
N (AL0, C3U, LHD, UA6, UG1, UPH, UYY, U19) (EXPORT) |
2012-2012 |
01 |
| 003 |
22770294 |
SWITCH, INTR LP (PART OF 6) (ARGENT) |
N (4AA, 4AF, 4AJ, 4A5) |
2012-2012 |
01 |
| 004 |
25964421 |
SWITCH, DM RDG LP (PART OF 6) (ACDelco #25964421) |
N |
2012-2012 |
01 |
| 005 |
11589329 |
CLIP, 12X8.9X15.5, SAE 1050 SPR STL, GMW3044 (PART OF 6) |
|
2012-2013 |
06 |
| 006 |
22770269 |
CONSOLE, RF (INCLS 2-5, 7-19) (SHALE) |
NG (AL0, C3U, LHD, UA6, UE1, UG1, 4AF, 4A5) (EXC UPH, UPJ, U19) |
2012-2012 |
01 |
| 006 |
22770270 |
CONSOLE, RF (INCLS 2-5, 7-19) (TITANIUM) |
NG (AL0, C3U, LHD, UA6, UE1, UG1, 4AA, 4AJ) (EXC UPH, UPJ, U19) |
2012-2013 |
01 |
| 006 |
22770272 |
CONSOLE, RF (INCLS 2-5, 7-19) (TITANIUM) |
NG (AL0, C3U, LHD, UA6, UE1, UG1, U19, 4AA, 4AJ) (EXC UPH, UPJ) (EXPORT) |
2012-2013 |
01 |
| 006 |
22770273 |
CONSOLE, RF (INCLS 2-5, 7-19) (SHALE) |
NG (AL0, C3U, LHD, UA6, UE1, UG1, U19, 4AF, 4A5) (EXC UPH, UPJ) (EXPORT) |
2012-2012 |
01 |
| 006 |
22769127 |
CONSOLE, RF (INCLS 2-5, 7-19) (TITANIUM) (BUILT PRIOR TO 06/10/11) (FOR 2ND DES SEE 22848743) |
N (AL0, C3U, UA6, UG1, UPH, UYY, U19, 4AA, 4AJ) (1ST DES) (EXPORT) |
2012-2012 |
01 |
| 006 |
22769128 |
CONSOLE, RF (INCLS 2-5, 7-19) (SHALE) (BUILT PRIOR TO 06/10/11) (FOR 2ND DES SEE 22848744) |
N (AL0, C3U, UA6, UG1, UPH, UYY, U19, 4AF, 4A5) (1ST DES) (EXPORT) |
2012-2012 |
01 |
| 006 |
22848743 |
CONSOLE, RF (INCLS 2-5, 7-19) (TITANIUM) (BUILT 06/10/11 AFTER) (FOR 1ST DES SEE 22769127) |
N (AL0, C3U, UA6, UG1, UPH, UYY, U19, 4AA, 4AJ) (2ND DES) (EXPORT) |
2012-2012 |
01 |
| 006 |
22848744 |
CONSOLE, RF (INCLS 2-5, 7-19) (SHALE) (BUILT 06/10/11 AFTER) (FOR 1ST DES SEE 22769128) |
N (AL0, C3U, UA6, UG1, UPH, UYY, U19, 4AF, 4A5) (2ND DES) (EXPORT) |
2012-2012 |
01 |
| 007 |
25964511 |
PLATE, M/TEL MIC OPG TR (PART OF 6) (BLACK) |
N |
2012-2013 |
01 |
| 008 |
25964503 |
PLATE, RF CNSL OPG TR (PART OF 6) (SHALE) |
NG (4AF, 4A5) |
2012-2013 |
01 |
| 008 |
25964504 |
PLATE, RF CNSL OPG TR (PART OF 6) (TITANIUM) |
NG (4AA, 4AJ) |
2012-2012 |
01 |
| 008 |
25964506 |
PLATE, RF CNSL OPG TR (PART OF 6) (TITANIUM) |
NG (4AA, 4AJ) |
2012-2012 |
01 |
| 008 |
25964505 |
PLATE, RF CNSL OPG TR (PART OF 6) (SHALE) |
NG (4AF, 4A5) |
2012-2013 |
01 |
| 008 |
20920278 |
PLATE, RF CNSL OPG TR (PART OF 6) (TITANIUM) |
NG (4AA, 4AJ) |
2012-2012 |
01 |
| 008 |
20920280 |
PLATE, RF CNSL OPG TR (PART OF 6) (SHALE) |
NG (4AF, 4A5) |
2012-2013 |
01 |
| 009 |
12768551 |
SWITCH, SUN RF SUNSHADE (PART OF 6) (BLACK) |
N (AL0, C3U, LHD, UA6, UE1, UG1, 4AA, 4AJ) (EXC UPH, UPJ, U19) |
2012-2012 |
01 |
| 009 |
12768552 |
SWITCH, SUN RF SUNSHADE (PART OF 6) (ARGENT) |
NG (4AA, 4AF, 4AJ, 4A5) |
2012-2012 |
01 |
| 010 |
25919341 |
SWITCH, SUN RF (PART OF 6) (BLACK) (USE 25919341 (2ND DESIGN) ON CARS W/GREEN BACKLIGHT SUNROOF SWITCH USE 25919342 (1ST DESIGN) ON CARS W/WHITE BACKLIGHT SUNROOF SWITCH.) |
N (4AA, 4AF, 4AJ, 4A5) (2ND DES) |
2012-2012 |
01 |
| 010 |
25919342 |
SWITCH, SUN RF (PART OF 6) (W/WHITE BACKLIGHT SUN ROOF SWITCH) (USE 1ST DESIGN P/N 25919342 ON CARS W/WHITE BACKLIGHT SUNROOF SWITCH USE 2ND DESIGN P/N 25919341 ON CARS W/GREEN BACKLIGHT SUNROOF SWITCH.) |
N (4AA, 4AF, 4AJ, 4A5) (1ST DES) |
2012-2012 |
01 |
| 011 |
15241529 |
MICROPHONE, MOBILE TEL (PART OF 6) (2-WAY CAVITY) |
N (UE1) |
2012-2013 |
01 |
| 011 |
13242355 |
MICROPHONE, MOBILE TEL (PART OF 6) (3-WAY CAVITY) |
N (UG1, UPH, UYY, U19) (EXPORT) |
2012-2012 |
01 |
| 012 |
25964415 |
LENS, DM LP (PART OF 6) |
N (UG1) |
2012-2013 |
01 |
| 012 |
88892575 |
LENS, DM LP (PART OF 6) (ONE BULB STYLE) (16.495) |
NG (TB5) |
2012-2012 |
01 |
| 013 |
20846676 |
DISPLAY, I/P AIRBAG ARMING STATUS (PART OF 6) |
N (EXC U19) |
2012-2013 |
01 |
| 013 |
20846675 |
DISPLAY, I/P AIRBAG ARMING STATUS (PART OF 6) |
N (U19) (EXPORT) |
2012-2013 |
01 |
| 014 |
25924768 |
PUSHBUTTON, GARAGE DR OPENER XMTR (PART OF 6) (GRAY) |
N (UG1) |
2012-2013 |
01 |
| 014 |
25992324 |
PUSHBUTTON, GARAGE DR OPENER XMTR (PART OF 6) (BLACK) |
N (4AA, 4AF, 4AJ, 4A5) |
2012-2012 |
01 |
| 015 |
13501111 |
TRANSMITTER, GARAGE DR OPENER (PART OF 6) |
N (UG1) |
2012-2013 |
01 |
| 016 |
11588920 |
SCREW, W/RND WA, M3.5X1.59X9.5, 6 THD, 7 O.D., GM512M, GMW3044 (PART OF 6) |
|
2012-2013 |
02 |
| 017 |
22815447 |
LAMP, F/FLR CNSL FLOOD (PART OF 6) |
N |
2012-2013 |
01 |
| 018 |
25964422 |
HARNESS, RDG LP WRG (PART OF 6) |
N |
2012-2013 |
01 |
| 019 |
01999382 |
BULB, (PART OF 6) (ACDelco #W5WLL) (LONGER LIFE) |
|
2012-2013 |
02 |
| 020 |
11589044 |
BOLT, HEX-HD, W/ WA, M6X1.0X43.0, 8.8, GMW3359 (PART OF 1) |
|
2012-2013 |
03 |
| 021 |
11569965 |
NUT, RF CNSL BRKT (PART OF 1) (M4.2X1.41) (PUSH IN) (12.8 HOLE) (FOR .7-1.1 PANEL RNG) (10.219) |
NG |
2012-2013 |
03 |
