| Поз. | Номер | Описание | Применение | Номенклатура | Кол-во |
| 001 |
13505726 |
SENSOR, VEH YAW (W/ VEH LATL LGTDNL ACCLRM) |
N |
2010-2012 |
01 |
| 002 |
11588712 |
BOLT, HFH, M6X1X20, 17.5 THD, 14.2 O.D., 8.8, GMW3359 (WHL SPD SEN) |
|
2010-2013 |
04 |
| 003 |
|
KNUCKLE, RR SUSP (SEE GROUP 07.000 SUSPENSION/REAR FOR DETAILED ILLUSTRATED VIEW) |
|
2010-2013 |
|
| 004 |
25896666 |
HARNESS, CHAS WRG (SEE GROUP 02.000 WIRING HARNESS/CHASSIS REAR FOR DETAILED ILLUSTRATED VIEW) |
N |
2012-2013 |
01 |
| 005 |
15921850 |
SENSOR, RR WHL SPD (ACDelco #15921850) |
N (JL9) |
2010-2012 |
01 |
| 005 |
25894693 |
SENSOR, RR WHL SPD (ACDelco #25894693) |
N (JL9) |
2010-2012 |
01 |
| 006 |
|
HARNESS, BODY WRG (SEE GROUP 13.000 WIRING HARNESS/BODY FOR DETAILED ILLUSTRATED VIEW) |
|
2010-2013 |
|
| 007 |
11609411 |
NUT, HEX W/CON WA, M6X1, 5.7 THK, 16 OD, 9, GMW3200 (BRK PRESS MOD VLV BRKT) |
|
2010-2013 |
03 |
| 008 |
|
KNUCKLE, STRG (W/HUB) (SEE GROUP 06.000 SUSPENSION/FRONT FOR DETAILED ILLUSTRATED VIEW) |
|
2010-2013 |
|
| 009 |
15921849 |
SENSOR, FRT WHL SPD (ACDelco #15921849) |
N (JL9) |
2010-2012 |
02 |
| 010 |
22841382 |
HARNESS, FRT WHL SPD SEN WRG (LABELED 22841382 OR 13894203) (FOR 1ST DES SEE 22798579) |
N (TT6, TT7, TT8) (EXC F45) (2ND DES) |
2012-2012 |
01 |
| 010 |
22870905 |
HARNESS, FRT WHL SPD SEN WRG |
N (EXC F45) |
2012-2013 |
01 |
| 010 |
22798579 |
HARNESS, FRT WHL SPD SEN WRG (LABELED 22798579 OR 13862414) (FOR 2ND DES SEE 22841382) |
NG (TT6, TT7, TT8) (EXC F45) (1ST DES) |
2012-2012 |
01 |
| 010 |
20979198 |
HARNESS, FRT WHL SPD SEN WRG (ACDelco #20979198) (LABELED 20979198 OR 13820380) ( FOR 2ND DES SEE 22806721) |
NG (EXC F45) (1ST DES) |
2011-2012 |
01 |
| 010 |
22806721 |
HARNESS, FRT WHL SPD SEN WRG (LABELED 22806721 OR 13864834) (FOR 1ST DES SEE 20979198) |
NG (EXC F45, TT6, TT7, TT8) (2ND DES) |
2011-2013 |
01 |
| 010 |
20979198 |
HARNESS, FRT WHL SPD SEN WRG (ACDelco #20979198) (LABELED 20979198 OR 13820380) ( FOR 2ND DES SEE 22806721) |
NG (EXC F45, TT6, TT7, TT8) (1ST DES) |
2011-2012 |
01 |
| 010 |
20911155 |
HARNESS, FRT WHL SPD SEN WRG |
NG (EXC F45, TT6, TT7, TT8) |
2011-2013 |
01 |
| 011 |
|
VALVE, BRK PRESS MOD (W/ELEK BRK TRACT CONT MDL) (SEE GROUP 04.000 BRAKE PRESSURE MODULATOR VALVE FOR DETAILED ILLUSTRATED VIEW) |
|
2010-2013 |
|
| 012 |
03530297 |
NUT, HFH, M6X1, 5.85THK, 14.2 O.D., 10, ZOR (VEH YAW SEN) |
|
2010-2013 |
02 |
