| Поз. | Номер | Описание | Применение | Номенклатура | Кол-во |
| 500 |
08680884 |
BOLT, PARK PAWL ACTR BRKT (M6X1.0X31) (4.228) |
N (MH4) |
2012-2012 |
04 |
| 500 |
08680884 |
BOLT, PARK PAWL ACTR BRKT (M6X1.0X31) (4.228) |
N (MH2) |
2012-2012 |
03 |
| 501 |
24225200 |
BRACKET, PARK PAWL ACTR (ACDelco #24225200) |
N (MH2, MH4) |
2010-2012 |
01 |
| 502 |
24225697 |
SHAFT, PARK PAWL (ACDelco #24225697) |
N (MH2, MH4) |
2010-2012 |
01 |
| 503 |
24225191 |
PAWL, PARK (ACDelco #24225191) |
N (MH2, MH4) |
2010-2012 |
01 |
| 504 |
24240586 |
SPRING, PARK PAWL (ACDelco #24240586) |
N (MH2, MH4) |
2010-2012 |
01 |
| 505 |
24216994 |
PIN, PARK PAWL ACTR GDE (4.294) (ACDelco #24216994) |
N (MH2, MH4) |
2010-2012 |
02 |
| 506 |
24225199 |
GUIDE, PARK PAWL ACTR (ACDelco #24225199) |
N (MH2, MH4) |
2010-2012 |
01 |
| 507 |
|
CASE, A/TRNS |
|
2010-2012 |
|
| 508 |
24256576 |
SEAL, MAN SHFT SHF (ACDelco #24256576) |
N (MH2, MH4) |
2012-2012 |
01 |
| 509 |
24225198 |
ACTUATOR, PARK PAWL (ACDelco #24225198) |
N (MH2, MH4) |
2010-2012 |
01 |
| 510 |
08685700 |
PIN, MAN SHFT SHF (ACDelco #8685700) |
N (MH2, MH4) |
2010-2012 |
01 |
| 511 |
24239240 |
LEVER, MAN SHFT DTNT (W/SHF POSN SW) (INCLS CABLES, CLIPS BRKT) (BUY TOGETHER W/ 08685700) (ACDelco #24239240) |
N (MH2, MH4) |
2010-2012 |
01 |
