| Поз. | Номер | Описание | Применение | Номенклатура | Кол-во |
| 001 |
22770789 |
WHEEL, 20X8 (CHROME) (ALUM) (53MM O/S) |
N (P47) |
2010-2011 |
04 |
| 001 |
22770789 |
WHEEL, 20X8 (14.3 KGS) (INSTALL .25) (CHROME) (ALUM) (53MM O/S) (5.803) |
NG |
2010-2011 |
04 |
| 002 |
09598179 |
NUT, WHL (M14X1.5) (STAINLESS STEEL CAP) |
N (P47, Q62) |
2010-2011 |
24 |
| 003 |
09596628 |
CAP, HUB (SILVER BACKGROUND) (MULTI-COLORED CREST EMBLEM) (CODE BJC FPN) |
N (P47, Q62) |
2010-2011 |
04 |
| 003 |
09599024 |
CAP, HUB |
N (P47, Q62) |
2010-2011 |
04 |
| 004 |
09597324 |
WEIGHT, WHL BAL (6.00 OZ) (STICK-ON REPLACEMENT) (TRIM AS REQUIRED) (WHL BAL) |
|
2010-2011 |
AR |
| 005 |
19209740 |
WEIGHT, WHL BAL (CLIP-ON REPLACEMENT) (TRIM AS REQUIRED) (WHL BAL) |
|
2010-2011 |
AR |
| 006 |
09597423 |
WHEEL, 20X8 (SILVER) (ALUM) (53MM O/S 120.0X6 B/C) |
N (Q62) |
2010-2011 |
04 |
| 006 |
20988113 |
WHEEL, 20X8 (MIDNIGHT SILVER) (INSTALL .25) (13.4 KGS) (REQS AL WHL TAG 14002325) (5.803) |
N (W/ACSRY WHL 20 X 8.0 J AL-DES 1) |
2011-2011 |
04 |
| 006 |
20988112 |
WHEEL, 20X8 (REQS AL WHL TAG 14002325) (INSTALL .25) (14.3 KGS) (INCLS BASE WHEEL LUG NUT TAG) (5.803) |
N |
2011-2011 |
04 |
| 006 |
20988113 |
WHEEL, 20X8 (MIDNIGHT SILVER) (INSTALL .25) (13.4 KGS) (REQS AL WHL TAG 14002325) |
N (SH9) |
2011-2011 |
04 |
| 007 |
|
BOLT, TIRE PRESS IND SEN (PART OF 8) (*KIT1) |
|
2010-2011 |
|
| 008 |
22854866 |
SENSOR, TIRE PRESS IND (INCLS 7, 9-11) (315 MHZ) (ACDelco #22854866) |
N (EXC XL8) |
2010-2011 |
04 |
| 008 |
22853740 |
SENSOR, TIRE PRESS IND (INCLS 7, 9-11) (433MHZ) (ACDelco #22853740) |
N (XL8) (EXPORT) |
2010-2011 |
04 |
| 009 |
|
STEM, TIRE VLV (PART OF 8) (*KIT1) |
|
2010-2011 |
|
| 010 |
|
VALVE, TIRE (PART OF 8) (*KIT1) |
|
2010-2011 |
|
| 011 |
25858636 |
CAP, TIRE PRESS IND SEN (PART OF 8) (BLACK) (*KIT1) (ACDelco #25858636) |
N |
2010-2011 |
04 |
| 012 |
09597415 |
WHEEL, 18X8 (MACH FACE) (ALUM) (53MM O/S 120.0X6 B/C) |
N (PW2) |
2010-2011 |
04 |
| 012 |
09597417 |
WHEEL, 18X8 (ULTRA BRIGHT) (ALUM) (53MM O/S 120.0X6 B/C) |
N (QF8) |
2010-2011 |
04 |
| 013 |
09598177 |
NUT, WHL (M14X1.5) (NON-DECORATIVE) |
N (PW2, QF8) |
2010-2011 |
24 |
| 014 |
09599024 |
CAP, HUB |
N (PW2, QF8) |
2010-2011 |
04 |
| K01 |
15263240 |
VALVE KIT, TIRE (INCLS 7, 9-11) (INCLS BLK CAP, STEM, BOLT) (ACDelco #15263240) |
N |
2010-2011 |
04 |
