| Поз. | Номер | Описание | Применение | Номенклатура | Кол-во |
| 400 |
24262387 |
SENSOR, A/TRNS INPUT SPD (INCLS 402) (ACDelco #24262387) |
N (MH2, MH4) |
2010-2012 |
01 |
| 400 |
24262387 |
SENSOR, A/TRNS INPUT SPD (INCLS 402) (4.329) (ACDelco #24262387) |
N (MH2, MH4) |
2010-2012 |
01 |
| 401 |
24235897 |
BOLT, A/TRNS INPUT SPD SEN (M6 X 25) (4.329) |
N (MH2, MH4) |
2010-2012 |
01 |
| 401 |
24235897 |
BOLT, A/TRNS INPUT SPD SEN (M6 X 25) |
N (MH2, MH4) |
2010-2012 |
01 |
| 402 |
24234865 |
SEAL, A/TRNS INPUT SPD SEN (O RING) (PART OF 400) (*KIT1) (ACDelco #24234865) |
N (MH2, MH4) |
2010-2012 |
02 |
| 403 |
24260590 |
COVER, A/TRNS CASE (INCLS 404-406, 900-902) (ACDelco #24260590) |
N (MH4, F07) |
2010-2012 |
01 |
| 403 |
24260590 |
COVER, A/TRNS CASE (INCLS 404-406, 900-902) (ACDelco #24260590) |
N (MH2, F07) |
2011-2011 |
01 |
| 404 |
|
ORIFICE, LUB FLUID (PART OF 403) |
|
2010-2012 |
|
| 405 |
|
SUPPORT, INPUT SHF (PART OF 403) |
|
2010-2012 |
|
| 406 |
|
BOLT, INPUT SHF SUPT (PART OF 403) |
|
2010-2012 |
|
| 407 |
24237428 |
RING, 3-5-REV 4-5-6 CLU FLUID SEAL (*KIT1) (4.105) (ACDelco #24237428) |
N (MH2, MH4) |
2010-2012 |
04 |
| 408 |
24223887 |
PISTON, 2-6 CLU (ACDelco #24223887) |
N |
2010-2013 |
01 |
| 409 |
24228952 |
SPRING, 2-6 CLU (ACDelco #24228952) |
N (MH2, MH4) |
2010-2012 |
01 |
| 410 |
24223889 |
RING, 2-6 CLU SPR RET (ACDelco #24223889) |
N |
2010-2013 |
01 |
| 411 |
24223884 |
PISTON, LOW REV CLU (ACDelco #24223884) |
N |
2010-2013 |
01 |
| 412 |
24233792 |
SPRING, LOW REV CLU (ACDelco #24233792) |
N (MH2, MH4) |
2010-2012 |
01 |
| 413 |
24224037 |
RING, LOW REV CLU SPR RET (ACDelco #24224037) |
N |
2010-2013 |
01 |
| 413 |
24224037 |
RING, LOW REV CLU SPR RET (4.189) (ACDelco #24224037) |
N |
2010-2013 |
01 |
| 900 |
|
SPRING, CLU PSTN DAM FEED BLOWOFF BALL VLV (PART OF 403) |
|
2010-2012 |
|
| 901 |
00104919 |
BALL, 5/16 CHROME STEEL (PART OF 403) (ACDelco #104919) |
|
2010-2013 |
01 |
| 902 |
|
PLUG, CLU PSTN DAM FEED BLOWOFF BALL VLV (PART OF 403) |
|
2010-2012 |
|
| K01 |
24256112 |
SEAL KIT, A/TRNS SERV (INCLS 402, 407) (O/H KIT) (ACDelco #24256112) (INCLUDES TRANS FILTER) (DOES NOT INCLUDE CLUTCH PISTONS W/BONDED SEALS. CLUTCH PISTONS WITH BONDED SEALS MUST BE ORDERED SEPARATELY) |
N (MH2, MH4) |
2011-2011 |
01 |
