| Поз. | Номер | Описание | Применение | Номенклатура | Кол-во |
| 001 |
|
RESERVOIR, P/S FLUID (INCLS 2, 3) |
|
2010-2010 |
|
| 002 |
|
SEAL, P/S FLUID RSVR CAP (O RING) (ЧАСТЬ OF 1, 3) |
|
2010-2010 |
|
| 003 |
|
CAP, P/S FLUID RSVR (ЧАСТЬ OF 1) (INCLS 2) |
|
2010-2010 |
|
| 004 |
11588712 |
БОЛТ, HFH, M6X1X20, 17.5 THD, 14.2 O.D., 8.8, GMW3359 (P/S FLUID RSVR) |
|
2010-2010 |
01 |
| 005 |
11588712 |
БОЛТ, HFH, M6X1X20, 17.5 THD, 14.2 O.D., 8.8, GMW3359 (P/S FLUID RSVR BRKT) |
|
2010-2010 |
01 |
| 006 |
11518121 |
ГАЙКА, U, M6X1, MULTI THD, .5-4.0 THK PNL (P/S FLUID RSVR BRKT) |
|
2010-2010 |
01 |
| 007 |
25932310 |
BRACKET, P/S FLUID RSVR |
N (LAU) |
2010-2010 |
01 |
| 008 |
20832552 |
COOLER, P/S FLUID |
N |
2010-2010 |
01 |
| 009 |
|
БОЛТ, P/S FLUID CLR BRKT |
|
2010-2010 |
|
| 010 |
|
CЛАМПА, P/S FLUID CLR INL OTLT HOSE) (ЧАСТЬ OF 11) |
|
2010-2010 |
|
| 011 |
20850642 |
HOSE, P/S FLUID CLR INL OTLT (INCLS 10) |
N (LAU) (NOT YET AVAILABLE) |
2010-2010 |
01 |
| 012 |
11588712 |
БОЛТ, HFH, M6X1X20, 17.5 THD, 14.2 O.D., 8.8, GMW3359 (P/S FLUID CLG PIPE BRKT) |
|
2010-2010 |
01 |
| 013 |
11588853 |
RETAINER - PLASTIC TREE, 5.7 DIA HOLE, 2.2 THK PNL, HOLDS 5.5 WIRE (ЧАСТЬ OF 14) |
|
2010-2010 |
01 |
| 014 |
15872965 |
HOSE, P/S FLUID RSVR INL (INCLS 13, 15) |
N (LAU) |
2010-2010 |
01 |
| 015 |
11517127 |
CЛАМПА, ПРУЖИНА, 17MM-NOM, BLK (ЧАСТЬ OF 14) |
|
2010-2010 |
01 |
| 016 |
20850645 |
HOSE, P/S GR OTLT (INCLS 17, 20) |
N (LAU, LHD) (NOT YET AVAILABLE) |
2010-2010 |
01 |
| 016 |
20850646 |
HOSE, P/S GR OTLT (INCLS 17, 20) |
N (LAU, RHD) (NOT YET AVAILABLE) (EXPORT) |
2010-2010 |
01 |
| 017 |
|
BRACKET, P/S GR OTLT PIPE INSL (ЧАСТЬ OF 16) |
|
2010-2010 |
|
| 018 |
11588712 |
БОЛТ, HFH, M6X1X20, 17.5 THD, 14.2 O.D., 8.8, GMW3359 (P/S GR OTLT HOSE BRKT) |
|
2010-2010 |
02 |
| 019 |
25622442 |
БОЛТ, P/S GR OTLT HOSE BRKT (M8X1.25X13) (4.785) |
N (LAU, LF1, LHD) |
2010-2010 |
01 |
| 020 |
|
SEAL, P/S GR OTLT HOSE (ЧАСТЬ OF 16) |
|
2010-2010 |
|
| 021 |
20872548 |
HOSE, P/S GR INL (INCLS 22) |
N (LAU, LHD) |
2010-2010 |
01 |
| 022 |
|
SEAL, P/S GR INL HOSE (O RING) (ЧАСТЬ OF 21) |
|
2010-2010 |
|
| 023 |
13501428 |
PUMP, P/S |
N (LAU) |
2010-2010 |
01 |
| 024 |
11519980 |
БОЛТ, HFH, M8X1.25X40, 22 THD, 18 OD, 8.8, GMW3359, 6MM MATPOINT. (P/S PUMP) |
|
2010-2010 |
03 |
| 025 |
|
CЛАМПА, P/S FLUID RSVR OTLT HOSE (ЧАСТЬ OF 26) |
|
2010-2010 |
|
| 026 |
20872554 |
HOSE, P/S FLUID RSVR OTLT (INCLS 25) |
N (LAU) |
2010-2010 |
01 |
