| Поз. | Номер | Описание | Применение | Номенклатура | Кол-во |
| 001 |
15888710 |
GRILLE, W/S DEFR NOZ (INCLS 2, 3, 9) (EBONY)
| E (13I, 19I) |
2007-2009 |
01 |
|
| 001 |
15888711 |
GRILLE, W/S DEFR NOZ (INCLS 2, 3, 9) (COCOA) |
E (39I) |
2007-2009 |
01 |
| 002 |
25713063 |
SENSOR, HDLP AUTO CONT AMB LGT (ЧАСТЬ OF 1) (DUAL SOLAR TWILIGHT)
| E |
2007-2009 |
01 |
|
| 003 |
|
WIRE, SUN LOAD TEMP SEN (ЧАСТЬ OF 1) |
|
2007-2009 |
|
| 004 |
11589015 |
БОЛТ, HWH W/FL WA M4.2X1.41X20, 12.5 O.D., DOG PT, 6010M, 7253M (RDO FRT SPKR)
|
2007-2009 |
04 |
|
| 005 |
11609989 |
БОЛТ, HEX W/FLAT WASHER, M6X1X25, 15 THD, 17 OD, 6202M STL, GMW3200, TAPTITE (RDO)
|
2007-2009 |
02 |
|
| 006 |
15931510 |
АНТЕННА, ELEK NAVIGATION (ACDelco #15931510) |
E26 (U2V, U2X, U2Y) |
2007-2009 |
01 |
| 007 |
11513599 |
ГАЙКА, U-TYPE, M4.2X1.41, 0.65-3.80 PNL THK, PZ (ЧАСТЬ OF 48) (ACDelco #11513599) |
|
2007-2009 |
04 |
| 008 |
25797586 |
SPEAKER, RDO FRT (3.5) (ACDelco #25797586) |
E |
2008-2009 |
01 |
| 008 |
25798963 |
SPEAKER, RDO FRT (3.5) (9.665) (ACDelco #25798963) |
E |
2008-2009 |
01 |
| 009 |
19167691 |
CLIP, I/P (ЧАСТЬ OF 1) |
E |
2007-2009 |
AR |
| 010 |
|
HARNESS, I/P WRG (СМ. ГРУППУ 02.000 ЖГУТЫ ПРОВОДОВ/ПРИБОРНАЯ ПАНЕЛЬ ДЛЯ ДЕТАЛЬНОГО ПРОСМОТРА) |
|
2007-2009 |
|
| 011 |
25874549 |
КРОНШТЕЙН, INST (СМ. ГРУППУ 10.000 ПРИБОРНАЯ ПАНЕЛЬ, STRUCTURE ДЛЯ ДЕТАЛЬНОГО ПРОСМОТРА) |
EB |
2007-2009 |
01 |
| 012 |
15940339 |
МОДУЛЬ, I/P INFL RST |
EB |
2007-2009 |
01 |
| 013 |
11561388 |
БОЛТ, HEX W/FL WA, M6X1X20, 11 THD, 17 OD, 9.8, GMW3359 W/ADH 6175M (I/P INFL RST MDL) |
|
2007-2009 |
01 |
| 014 |
15685170 |
ГАЙКА, HEX-HD, W/FL WA, M6X1, 5.5 THK, 9, 7111M, 2MM THK 19 OD WA, NYLOC (INFL RST I/P MDL) (8.917) |
|
2007-2009 |
06 |
| 015 |
22549046 |
SCREW, M4.2X1.4X25, 11.1 O.D., 6010M, NZ (I/P LWR INSL) |
|
2007-2009 |
02 |
| 016 |
15796483 |
INSULATOR, I/P |
EB |
2007-2009 |
01 |
| 017 |
03525213 |
ЛАМПА, CTSY (WITHOUT LENS) (IN I/P) |
E |
2007-2009 |
02 |
| 018 |
11610157 |
ГАЙКА, PNL, M4.2X1.41, 8.5X11.9, 2.3-2.8 PNL, FITS 11.2X9.2 HOLE, 1050, GMW33 (ЧАСТЬ OF 48) (10.701)
|
2007-2009 |
05 |
|
| 019 |
25687484 |
SENSOR, I/S AIR TEMP (ACDelco #15-5889)
| E (JJD) |
2008-2009 |
01 |
|
| 020 |
15796362 |
COVER, КОНДИЦИОНЕР EVAP ACC |
EB26 |
2007-2009 |
01 |
| 021 |
22625546 |
INDICATOR, INFL RST I/P MDL (W/WORDS ON AND OFF FOR AIRBAG) |
EB (EXC BAG) |
2008-2009 |
01 |
| 021 |
22627868 |
INDICATOR, INFL RST I/P MDL (W/AIRBAG SYMBOLS FOR ON AND OFF) |
EB (BAG, JJD) (EXPORT) |
2008-2009 |
01 |
| 022 |
15776576 |
SWITCH, HAZARD WRNG
| EB26 |
2007-2009 |
01 |
|
| 023 |
11561265 |
SCREW - RND WA, M3X1.12X12, 10.5 THD, 6.21 OD, GM512M STL, GMW4205 (ПЕПЕЛЬНИЦА) |
|
2007-2009 |
04 |
| 024 |
|
HARNESS, ПЕПЕЛЬНИЦА WRG (ЧАСТЬ OF 25) |
|
2007-2009 |
|
| 025 |
25815004 |
ШЛАНГИ, I/P ПЕПЕЛЬНИЦА (INCLS 24, 29, 30, 33, 53) |
EB (DT4) |
2007-2009 |
01 |
| 025 |
25815005 |
ШЛАНГИ, I/P ПЕПЕЛЬНИЦА (INCLS 24, 29, 30, 33, 53) |
EB (EXC DT4) |
2007-2009 |
01 |
| 026 |
11589015 |
БОЛТ, HWH W/FL WA M4.2X1.41X20, 12.5 O.D., DOG PT, 6010M, 7253M (ПЕПЕЛЬНИЦА)
|
2007-2009 |
05 |
|
| 027 |
15880845 |
COVER, I/P ПЕПЕЛЬНИЦА |
EB (EXC B19) |
2007-2009 |
01 |
| 027 |
15880846 |
COVER, I/P ПЕПЕЛЬНИЦА |
E (B19) |
2007-2009 |
01 |
| 028 |
15776575 |
SWITCH, ELEK TRACT CONT |
E |
2007-2009 |
01 |
| 029 |
25749635 |
RETAINER, C/LTR RCPT (ЧАСТЬ OF 25) (EBONY) (W/O CAP)
| E |
2007-2009 |
AR |
|
| 030 |
25776667 |
RECEPTACLE, C/LTR (ЧАСТЬ OF 25) (2 TERMINALS)
| E |
2007-2009 |
AR |
|
| 031 |
15776590 |
SWITCH, A/TRNS TOW/HAUL |
E |
2007-2009 |
01 |
| 032 |
11609406 |
SCREW, RD, M4.2X1.41X20, TYPE AB PT, GM6010M, GMW4205 (I/P DRVR KNEE BOLS)
|
2007-2009 |
03 |
|
| 033 |
11516141 |
LIGHTER, CIG (ЧАСТЬ OF 25) (BLACK) (W/SMALL, PLASTIC KNOB END 14.0MM)
| EB26 |
2008-2009 |
01 |
|
| 034 |
11609455 |
БОЛТ, I/P DRVR KNEE BOLS (KNEE BOLSTER TO PARK BRAKE @ HDLS) (8.977) |
E |
2007-2009 |
01 |
| 035 |
25939882 |
BOLSTER, I/P DRVR KNEE (INCLS 36, 39, 40, 58) (СМ. ГРУППУ 10.000 ПРИБОРНАЯ ПАНЕЛЬ, TRIM ДЛЯ ДЕТАЛЬНОГО ПРОСМОТРА) (GRAY) |
EB (13I) |
2007-2009 |
01 |
| 035 |
25939883 |
BOLSTER, I/P DRVR KNEE (INCLS 36, 39, 40, 58) (СМ. ГРУППУ 10.000 ПРИБОРНАЯ ПАНЕЛЬ, TRIM ДЛЯ ДЕТАЛЬНОГО ПРОСМОТРА) (EBONY) |
EB (19I) |
2007-2009 |
01 |
| 035 |
25939884 |
BOLSTER, I/P DRVR KNEE (INCLS 36, 39, 40, 58) (СМ. ГРУППУ 10.000 ПРИБОРНАЯ ПАНЕЛЬ, TRIM ДЛЯ ДЕТАЛЬНОГО ПРОСМОТРА) (CASHMERE) |
EB (39I) |
2007-2009 |
01 |
| 036 |
15868878 |
SWITCH, I/P LP DIMR (ЧАСТЬ OF 35) (ACDelco #D1592H) |
EB |
2007-2009 |
01 |
| 037 |
11610157 |
ГАЙКА, PNL, M4.2X1.41, 8.5X11.9, 2.3-2.8 PNL, FITS 11.2X9.2 HOLE, 1050, GMW33 (ЧАСТЬ OF 48) (10.701)
|
2007-2009 |
04 |
|
| 038 |
11610157 |
ГАЙКА, PNL, M4.2X1.41, 8.5X11.9, 2.3-2.8 PNL, FITS 11.2X9.2 HOLE, 1050, GMW33 (ЧАСТЬ OF 48) (10.701)
|
2007-2009 |
04 |
|
| 039 |
11561265 |
SCREW - RND WA, M3X1.12X12, 10.5 THD, 6.21 OD, GM512M STL, GMW4205 (ЧАСТЬ OF 35) |
|
2007-2009 |
03 |
| 040 |
15882574 |
SWITCH, DRVR INFO DISPLAY (ЧАСТЬ OF 35) |
E |
2007-2009 |
01 |
| 041 |
11589015 |
БОЛТ, HWH W/FL WA M4.2X1.41X20, 12.5 O.D., DOG PT, 6010M, 7253M (HTR КОНДИЦИОНЕР CONT)
|
2007-2009 |
04 |
|
| 042 |
25808945 |
CONTROL, HTR КОНДИЦИОНЕР (W/R/WDO DEFG SW) (LABELED 25808945) (ACDelco #15-73803) |
EB26 |
2008-2009 |
01 |
| 042 |
25808945 |
CONTROL, HTR КОНДИЦИОНЕР (W/R/WDO DEFG SW) (LABELED 25808945) (9.273) (ACDelco #15-73803) |
EB26 |
2008-2009 |
01 |
| 042 |
25839380 |
CONTROL, HTR КОНДИЦИОНЕР (W/R/WDO DEFG SW) (LABELED 25839380 OR 25855590) (ACDelco #15-73884) |
EB26 |
2008-2009 |
01 |
| 042 |
25839380 |
CONTROL, HTR КОНДИЦИОНЕР (W/R/WDO DEFG SW) (LABELED 25839380 OR 25855590) (9.273) (ACDelco #15-73884) |
EB26 |
2008-2009 |
01 |
| 043 |
11589015 |
БОЛТ, HWH W/FL WA M4.2X1.41X20, 12.5 O.D., DOG PT, 6010M, 7253M (RDO)
|
2007-2009 |
04 |
|
| 044 |
|
RADIO, AM/FM STEREO CLK CD PLYR (СМ. ГРУППУ 09.000 АУДИОСИСТЕМА/FRONT ДЛЯ ДЕТАЛЬНОГО ПРОСМОТРА) (REQUIRES DLR PROGRAMMING) |
|
2007-2009 |
|
| 045 |
25961448 |
CLUSTER, INST (LABELED 25961448) |
EB (EXC UC2, U19) |
2008-2009 |
01 |
| 045 |
25961449 |
CLUSTER, INST (ACDelco #25961449) (LABELED 25961449) |
E26 (UC2, U19) (EXC TGD, TGJ) |
2008-2009 |
01 |
| 045 |
25961450 |
CLUSTER, INST (LABELED 25961450) |
E (JJD, TGD, UC2) |
2008-2009 |
01 |
| 045 |
25961451 |
CLUSTER, INST (ACDelco #25961451) |
EB26 (TGJ, UC2, JJD) |
2008-2009 |
01 |
| 046 |
11589015 |
БОЛТ, HWH W/FL WA M4.2X1.41X20, 12.5 O.D., DOG PT, 6010M, 7253M (INST CSTR)
|
2007-2009 |
03 |
|
| 047 |
11610157 |
ГАЙКА, PNL, M4.2X1.41, 8.5X11.9, 2.3-2.8 PNL, FITS 11.2X9.2 HOLE, 1050, GMW33 (ЧАСТЬ OF 48) (10.701)
|
2007-2009 |
03 |
|
| 048 |
|
PANEL, INST (INCLS 7, 18, 37, 38, 47, 52) (СМ. ГРУППУ 10.000 ПРИБОРНАЯ ПАНЕЛЬ, TRIM ДЛЯ ДЕТАЛЬНОГО ПРОСМОТРА) (GRAY) |
|
2007-2009 |
|
| 049 |
25974173 |
DEFLECTOR, I/P CTR AIR OTLT
| E |
2007-2009 |
01 |
|
| 050 |
15889347 |
CLOCK, (LABELED W/OEM PN 15889347.)
| E |
2007-2009 |
01 |
|
| 051 |
11589015 |
БОЛТ, HWH W/FL WA M4.2X1.41X20, 12.5 O.D., DOG PT, 6010M, 7253M (I/P CTR AIR OTLT)
|
2007-2009 |
03 |
|
| 052 |
11610157 |
ГАЙКА, PNL, M4.2X1.41, 8.5X11.9, 2.3-2.8 PNL, FITS 11.2X9.2 HOLE, 1050, GMW33 (ЧАСТЬ OF 48) (10.701)
|
2007-2009 |
03 |
|
| 053 |
15187371 |
RETAINER, C/LTR HSG (ЧАСТЬ OF 25) (EBONY) (INCLS COVER)
| E26 |
2007-2009 |
02 |
|
| 054 |
15921352 |
МОДУЛЬ, BODY CONT (REQUIRES PROGRAMMING) (LABELED 15921352) (ACDelco #15921352) |
E |
2009-2009 |
01 |
| 055 |
15796482 |
INSULATOR, BCM |
EB |
2007-2009 |
01 |
| 056 |
11609457 |
SCREW, ROUNDWA, M4.2X1.41X20, 14.1 THD, 11.35 OD, 6010M, GMW4205, TAP, (I/P LWR INSL) |
|
2007-2009 |
08 |
| 057 |
03525213 |
ЛАМПА, CTSY (WITHOUT LENS) (IN I/P) |
E (JJD) |
2009-2009 |
02 |
| 058 |
11513599 |
ГАЙКА, U-TYPE, M4.2X1.41, 0.65-3.80 PNL THK, PZ (ЧАСТЬ OF 35) (ACDelco #11513599) |
|
2007-2009 |
02 |
