| Поз. | Номер | Описание | Применение | Номенклатура | Кол-во |
| 001 |
19130428 |
COVER, PASS COMPT AIR FLTR ACC HOLE |
E |
2008-2009 |
01 |
| 002 |
19130403 |
FILTER KIT, PASS COMPT AIR (ЧАСТЬICLE FILTER) (ACDelco #CF133)
| E |
2007-2009 |
01 |
|
| 003 |
19130429 |
ШЛАНГИ, PASS COMPT AIR FLTR (9.169) |
E |
2008-2009 |
01 |
| 004 |
25768129 |
PANEL, AIR INL HSG FRT |
EB |
2007-2009 |
01 |
| 005 |
11516589 |
SCREW, HEX HD W/CON SPR WA, M6X1X30, 29 THD, 17 O.D., 9.8, 7114M, ZE (AIR INL) |
|
2007-2009 |
03 |
| 006 |
25760173 |
PANEL, AIR INL HSG LWR (INCLS 7, 8) |
EB26 |
2007-2009 |
01 |
| 007 |
11569577 |
STUD, FLANGE M6X1X20, M6.3X1.69X16, 15 OD, 6010M, 4345M, TAP (ЧАСТЬ OF 6) |
|
2007-2009 |
01 |
| 008 |
11518121 |
ГАЙКА, U, M6X1, MULTI THD, .5-4.0 THK PNL (ЧАСТЬ OF 6) |
|
2007-2009 |
05 |
| 009 |
11609989 |
БОЛТ, HEX W/FLAT WASHER, M6X1X25, 15 THD, 17 OD, 6202M STL, GMW3200, TAPTITE (BAT TRAY)
|
2007-2009 |
02 |
|
| 010 |
11516589 |
SCREW, HEX HD W/CON SPR WA, M6X1X30, 29 THD, 17 O.D., 9.8, 7114M, ZE (AIR INL) |
|
2007-2009 |
01 |
| 011 |
11609411 |
ГАЙКА, HEX W/CON WA, M6X1, 5.7 THK, 16 OD, 9, GMW3200 (AIR INL HSG)
|
2007-2009 |
01 |
|
| 012 |
11609411 |
ГАЙКА, HEX W/CON WA, M6X1, 5.7 THK, 16 OD, 9, GMW3200 (AIR INL HSG)
|
2007-2009 |
03 |
|
| 013 |
11570097 |
ГАЙКА, U-TYPE, M6X1, 21.4X15, 11.7 C/E, SAE 1050 STL, GMW3359. (ЧАСТЬ OF 16)
|
2007-2009 |
02 |
|
| 014 |
15216960 |
SEAL, AIR INL GRL PNL (1RH BTWN FDR AND АККУМУЛЯТОР TRAY) |
EB |
2007-2009 |
01 |
| 015 |
11516589 |
SCREW, HEX HD W/CON SPR WA, M6X1X30, 29 THD, 17 O.D., 9.8, 7114M, ZE (BAT TRAY) |
|
2007-2009 |
05 |
| 016 |
25783791 |
TRAY, BAT (INCLS 13) |
EB |
2008-2009 |
01 |
