| Поз. | Номер | Описание | Применение | Номенклатура | Кол-во |
| 001 |
25810468 |
RADIO, AM/FM STEREO VIDEO DISC PLYR NAVN (INCLS 2, 3, 5, 6) (ACDelco #25810468)
| E26 (U2Y) (EXC FCN) |
2008-2009 |
01 |
|
| 001 |
25848914 |
RADIO, AM/FM STEREO VIDEO DISC PLYR NAVN (INCLS 2, 3, 5, 6) (LABELED 25848914) |
E26 (U2X) |
2008-2009 |
01 |
| 001 |
25848915 |
RADIO, AM/FM STEREO VIDEO DISC PLYR NAVN (INCLS 2, 3, 5, 6) (ACDelco #25848915) |
E26 (FCN, U2Y) (EXPORT) |
2008-2009 |
01 |
| 001 |
25851426 |
RADIO, AM/FM STEREO VIDEO DISC PLYR NAVN (INCLS 2, 3, 5, 6) (ACDelco #25851426) (USE ON VEHICLES BUILT ON OR AFTER 10/08/07.)
| E26 (U2V) |
2007-2009 |
01 |
|
| 002 |
|
KNOB, RDO TUNING CONT (ЧАСТЬ OF 1) |
|
2007-2009 |
|
| 003 |
|
PUSHBUTTON, RDO TUNE (ЧАСТЬ OF 1) |
|
2007-2009 |
|
| 004 |
|
DISC, NAVN DATA (FOR SERVICE SEE GM PARTS PROCESS/POLICY BULLETIN FOR LATEST SERVICE INFORMATION) |
|
2007-2009 |
|
| 005 |
|
PUSHBUTTON, RDO PWR (ЧАСТЬ OF 1) |
|
2007-2009 |
|
| 006 |
|
KNOB, RDO VOL CONT (ЧАСТЬ OF 1) |
|
2007-2009 |
|
| 007 |
11589015 |
БОЛТ, HWH W/FL WA M4.2X1.41X20, 12.5 O.D., DOG PT, 6010M, 7253M (RDO)
|
2007-2009 |
04 |
|
| 008 |
11610157 |
ГАЙКА, PNL, M4.2X1.41, 8.5X11.9, 2.3-2.8 PNL, FITS 11.2X9.2 HOLE, 1050, GMW33 (RADIO) (10.701)
|
2007-2009 |
04 |
|
| 009 |
|
HARNESS, I/P WRG (СМ. ГРУППУ 02.000 ЖГУТЫ ПРОВОДОВ/ПРИБОРНАЯ ПАНЕЛЬ ДЛЯ ДЕТАЛЬНОГО ПРОСМОТРА) |
|
2007-2009 |
|
| 010 |
15931510 |
АНТЕННА, ELEK NAVIGATION (ACDelco #15931510) |
E26 (U2V, U2X, U2Y) |
2007-2009 |
01 |
| 011 |
11609989 |
БОЛТ, HEX W/FLAT WASHER, M6X1X25, 15 THD, 17 OD, 6202M STL, GMW3200, TAPTITE (RDO)
|
2007-2009 |
02 |
|
