| Поз. | Номер | Описание | Применение | Номенклатура | Кол-во |
| 001 |
|
CASE, КОНДИЦИОНЕР EVPR (*KIT1) |
|
2004-2009 |
|
| 002 |
15266665 |
CLIP, КОНДИЦИОНЕР EVPR CASE (9.215) |
E |
2004-2009 |
01 |
| 003 |
25740401 |
SEAL, HTR CORE CASE (THIN) |
E |
2004-2009 |
01 |
| 004 |
|
SEAL, HTR CORE CASE (THICK) |
|
2004-2009 |
|
| 005 |
|
BRACKET, HTR КОНДИЦИОНЕР EVPR MDL LWR |
|
2004-2009 |
|
| 006 |
|
БОЛТ, HTR CASE FRT PLT |
|
2004-2009 |
|
| 007 |
|
ГАЙКА, HTR CASE |
|
2004-2009 |
|
| 008 |
|
БОЛТ, HTR CASE |
|
2004-2009 |
|
| 009 |
89024960 |
ACTUATOR, TEMP VLV (INCLS 10) (ACDelco #15-73209) |
E |
2007-2009 |
02 |
| 010 |
|
LEVER, MODE VLV (ЧАСТЬ OF 9) |
|
2007-2008 |
|
| 011 |
19129863 |
DUCT, FLR FRT AIR OTLT |
E |
2006-2009 |
01 |
| 011 |
19130220 |
DUCT, FLR FRT AIR OTLT |
EE26 |
2007-2008 |
01 |
| 012 |
25740392 |
CORE, HTR (ACDelco #15-62716)
| E |
2004-2009 |
01 |
|
| 013 |
|
DIVIDER |
|
2004-2009 |
|
| 014 |
|
CASE, КОНДИЦИОНЕР EVPR (*KIT1) |
|
2004-2009 |
|
| 015 |
|
БОЛТ, КОНДИЦИОНЕР EVPR CASE |
|
2004-2009 |
|
| 016 |
|
ГАЙКА, КОНДИЦИОНЕР EVPR CASE |
|
2004-2009 |
|
| 017 |
19129864 |
DUCT, FLR AIR OTLT |
EB |
2007-2009 |
01 |
| 018 |
25740400 |
HOSE, КОНДИЦИОНЕР EVPR BLO MDL DRN |
E |
2004-2009 |
01 |
| 019 |
25740397 |
ASPIRATOR, I/S AIR TEMP SEN |
E |
2004-2009 |
01 |
| 020 |
|
LEVER, MODE VLV |
|
2004-2009 |
|
| 021 |
19130240 |
ACTUATOR, MODE VLV (INCLS 25) (ACDelco #15-73823) |
EB26 |
2007-2008 |
01 |
| 021 |
19130240 |
ACTUATOR, MODE VLV (INCLS 25) (ACDelco #15-73823) |
EE26 (EXPORT) |
2007-2008 |
01 |
| 022 |
|
БОЛТ, MODE VLV ACTR |
|
2004-2009 |
|
| 023 |
|
БОЛТ, TEMP VLV LVR BRKT |
|
2004-2009 |
|
| 024 |
|
DUCT, BLO OTLT |
|
2004-2009 |
|
| 025 |
|
LEVER, MODE VLV (ЧАСТЬ OF 21) |
|
2007-2008 |
|
| 026 |
|
LEVER, MODE VLV (*KIT1) |
|
2004-2009 |
|
| 027 |
|
LEVER, MODE VLV (*KIT1) |
|
2004-2009 |
|
| 028 |
|
LEVER, MODE VLV (*KIT1) |
|
2004-2009 |
|
| 029 |
19130353 |
VALVE KIT, КОНДИЦИОНЕР EVPR THERMAL EXPN (INCLS 30, 31, 38, 39) (ACDelco #15-50798) |
E |
2007-2009 |
01 |
| 030 |
|
PLATE, КОНДИЦИОНЕР EVPR INL TUBE BRKT BKG (ЧАСТЬ OF 29) |
|
2004-2009 |
|
| 031 |
|
БОЛТ, КОНДИЦИОНЕР EVPR BRKT (ЧАСТЬ OF 29) |
|
2004-2009 |
|
| 032 |
25740420 |
TUBE KIT, КОНДИЦИОНЕР EVPR TXV (INCLS 33) (ACDelco #15-33185)
| E |
2004-2009 |
01 |
|
| 033 |
|
TUBE, КОНДИЦИОНЕР EVPR (ЧАСТЬ OF 32) |
|
2004-2009 |
|
| 034 |
|
БОЛТ, BLO UPR CASE |
|
2004-2009 |
|
| 035 |
|
BRACKET, HTR КОНДИЦИОНЕР EVPR MDL UPR |
|
2004-2009 |
|
| 036 |
|
SEAL, КОНДИЦИОНЕР EVPR CASE (THICK) |
|
2004-2009 |
|
| 037 |
|
SEAL, КОНДИЦИОНЕР EVPR CASE (THIN) |
|
2004-2009 |
|
| 038 |
|
SEAL, КОНДИЦИОНЕР EVPR TXV (ЧАСТЬ OF 29) |
|
2004-2009 |
|
| 039 |
|
SEAL, КОНДИЦИОНЕР EVPR TXV (ЧАСТЬ OF 29) |
|
2004-2009 |
|
| 040 |
|
INSULATOR, КОНДИЦИОНЕР EVPR TXV (ЧАСТЬ OF 41) |
|
2004-2009 |
|
| 041 |
89024954 |
EVAPORATOR KIT, КОНДИЦИОНЕР (INCLS 40) (ACDelco #15-62717) |
E |
2004-2009 |
01 |
| 042 |
|
VALVE, MIXER |
|
2004-2009 |
|
| 043 |
|
VALVE, MIXER |
|
2004-2009 |
|
| 044 |
|
VALVE, DEFR |
|
2004-2009 |
|
| 045 |
|
VALVE, MODE |
|
2004-2009 |
|
| 046 |
|
SEAL, VENT VLV |
|
2004-2009 |
|
| 047 |
19129776 |
HARNESS, HTR КОНДИЦИОНЕР CONT WRG (INCLS TEMP SENSOR) |
EE (JJD) |
2008-2008 |
01 |
| 047 |
19129776 |
HARNESS, HTR КОНДИЦИОНЕР CONT WRG (INCLS TEMP SENSOR) |
EB (JJD) |
2008-2009 |
01 |
| 048 |
25740391 |
CLIP, КОНДИЦИОНЕР REFRIG TEMP SEN LEAD |
E |
2004-2009 |
01 |
| 049 |
|
SENSOR, КОНДИЦИОНЕР EVAP TEMP (ЧАСТЬ OF 47) |
|
2006-2008 |
|
| 050 |
|
DUCT, BLO OTLT |
|
2004-2009 |
|
| K01 |
19130190 |
МОДУЛЬ KIT, HTR КОНДИЦИОНЕР EVPR BLO (INCLS 1, 14) (ACDelco #15-80937) |
EB26 |
2007-2009 |
01 |
| K01 |
19130192 |
МОДУЛЬ KIT, HTR КОНДИЦИОНЕР EVPR BLO (INCLS 1, 14) |
EE26 |
2007-2008 |
01 |
