| Поз. | Номер | Описание | Применение | Номенклатура | Кол-во |
| 001 |
12583604 |
SHIELD, UPR INT MANIF SIGHT (INCLS 2, 5, 18)
| E (LY7) |
2007-2008 |
01 |
|
| 002 |
|
EMBLEM, INT MANIF CVR (ЧАСТЬ OF 1) |
|
2007-2008 |
|
| 003 |
12593356 |
CAP, OIL FIL (INCLS 4) (ЧАСТЬ OF 7) (ACDelco #FC221)
| E (LY7) |
2007-2008 |
01 |
|
| 004 |
12593348 |
SEAL, OIL FIL CAP (O RING) (ЧАСТЬ OF 3, 7) (27.94MM I.D.) (SIZE #320)
| E (LY7) |
2007-2008 |
01 |
|
| 005 |
12606862 |
GROMMET, UPR INT MANIF SIGHT SHLD (ЧАСТЬ OF 1) (32MM OD) |
E (LY7) |
2007-2008 |
02 |
| 006 |
11609319 |
STUD, UPR INT MANIF SIGHT SHLD (3.671) |
E (LY7) |
2007-2008 |
02 |
| 007 |
12597946 |
TUBE, OIL FIL (INCLS 3, 4, 8)
| E (LY7) |
2007-2008 |
01 |
|
| 008 |
12593348 |
SEAL, OIL FIL TUBE (O RING) (ЧАСТЬ OF 7) (27.94MM I.D.) (SIZE #320) (1.758)
| E (LY7) |
2007-2008 |
01 |
|
| 009 |
12604673 |
BRACE, INT MANIF |
E (LY7) |
2007-2008 |
01 |
| 010 |
11588723 |
БОЛТ, HFH, M8X1.25X25, 18 THD, 18 OD, 8.8 STL, GMW3359, M-PT (INT MANIF BR) |
|
2007-2008 |
01 |
| 011 |
11588723 |
БОЛТ, HFH, M8X1.25X25, 18 THD, 18 OD, 8.8 STL, GMW3359, M-PT (INT MANIF SIGHT SHLD) |
|
2007-2008 |
01 |
| 012 |
11518712 |
БОЛТ-HEX W/CON WA, M12X1.75X59, 53.6 THD, 24OD, 10.9, 7114M, MACH, 6175M, HDR (INT MANIF SIGHT SHLD) |
|
2007-2008 |
01 |
| 013 |
11516075 |
ГАЙКА, HFH SELF LK, M6X1, 7.7THK, 14.2 O.D., 9, PZOR (ЧАСТЬ OF 14)
|
2007-2008 |
01 |
|
| 014 |
12616618 |
BRACKET, INT MANIF SIGHT SHLD (INCLS 13, 16) |
E (LY7) |
2007-2008 |
01 |
| 015 |
11588967 |
STUD, BALL W/HFH, M6X1X20.65, 14.2 O.D., 8.8, GMW3359 (INT MANIF BR) |
|
2007-2008 |
01 |
| 016 |
11588967 |
STUD, BALL W/HFH, M6X1X20.65, 14.2 O.D., 8.8, GMW3359 (ЧАСТЬ OF 14) |
|
2007-2008 |
01 |
| 017 |
12567371 |
GROMMET, UPR INT MANIF SIGHT SHLD
| E (LY7) |
2007-2008 |
01 |
|
| 018 |
|
GROMMET, UPR INT MANIF SIGHT SHLD (ЧАСТЬ OF 1) |
|
2007-2008 |
|
