| Поз. | Номер | Описание | Применение | Номенклатура | Кол-во |
| 001 |
15215744 |
SPEAKER, RDO W/S SI G/MLDG (LH RH) (W/O GRILLE) (ACDelco #15215744) |
E26 |
2007-2009 |
02 |
| 002 |
|
GRILLE, RDO W/S SI G/MLDG SPKR (СМ. ГРУППУ 14.000 ПЕРЕДНЯЯ ОТДЕЛКА ДЛЯ ДЕТАЛЬНОГО ПРОСМОТРА) |
|
2007-2009 |
|
| 003 |
11561847 |
ГАЙКА, RDO FRT S/D SPKR (12MM X 16.7MM) (2.664) |
E |
2007-2009 |
04 |
| 004 |
25645757 |
ГАЙКА, RDO FRT S/D SPKR (EBONY) (20MM SQUARE, 16MM THK) (FITS 9.8MM HOLE) |
E |
2007-2009 |
04 |
| 005 |
15941727 |
SPEAKER, RDO FRT S/D (ACDelco #15941727) (LABELED W/OEM PN 15941727.)
| E |
2007-2007 |
02 |
|
| 006 |
11609370 |
БОЛТ-HWH, M4.2X1.41X20, HI - LOW THD, , OD 12, 6010 STL, GMW4205, TAP (RDO FRT S/D SPKR) (9.667) |
|
2007-2009 |
08 |
| 007 |
25725733 |
SPEAKER, RDO RR S/D (ACDelco #25725733)
| E |
2007-2009 |
02 |
|
| 008 |
|
GRILLE, RDO RR S/D SPKR (СМ. ГРУППУ 14.000 ОТДЕЛКА/ЗАДНЯЯ ДВЕРЬ ДЛЯ ДЕТАЛЬНОГО ПРОСМОТРА) |
|
2007-2009 |
|
| 009 |
11509231 |
SCREW, RD HD C/R TAP, M4.2X1.41X13.0, GM6010M STL, GM813M NICKEL ORGANIC (RDO RR S/D LWR SPKR (RPR))
|
2007-2009 |
16 |
|
| 010 |
11519502 |
ГАЙКА, TYPE U, M6X1, 23.5X12.5, 13.5 C/E, 0.8-4.0 PNL, GM7111M (RDO RR SPKR) |
|
2007-2009 |
01 |
| 011 |
15284794 |
SPEAKER, RDO RR OTR (ACDelco #15284794) |
E26 |
2007-2007 |
01 |
| 012 |
11515908 |
БОЛТ, HEX HD, W/FL WA, 6X1X45, 17 O.D., DOG PT, 9.8, 7112M (RDO RR SPKR) (ACDelco #11515908) (11515908 T/W 12345382 REPLS 25535052) |
|
2007-2009 |
01 |
| 013 |
11609411 |
ГАЙКА, HEX W/CON WA, M6X1, 5.7 THK, 16 OD, 9, GMW3200 (R/FLR PNL CPT RET BRKT)
|
2007-2009 |
02 |
|
| 014 |
11561711 |
БОЛТ, RDO SPKR AMPF BRKT |
E |
2007-2007 |
01 |
| 015 |
15284793 |
УСИЛИТЕЛЬ, RDO SPKR (ACDelco #15284793) (LABELED WITH OEM PN 15284793.) |
E (UQA) |
2007-2007 |
01 |
| 015 |
25790123 |
УСИЛИТЕЛЬ, RDO SPKR (LABELED WITH OEM PN 25790123.)
| E26 (UQA) |
2007-2007 |
01 |
|
| 016 |
03530297 |
ГАЙКА, HFH, M6X1, 5.85THK, 14.2 O.D., 10, ZOR (AUDIO PWR BOOS) |
|
2007-2009 |
04 |
| 017 |
11609411 |
ГАЙКА, HEX W/CON WA, M6X1, 5.7 THK, 16 OD, 9, GMW3200 (AUDIO PWR BOOS BRKT)
|
2007-2009 |
01 |
|
| 018 |
15284790 |
BRACKET, RDO SPKR AMPF |
E (EXC FCN) |
2007-2007 |
01 |
| 019 |
11609599 |
STUD, SPL, M6X1X25, 13 THD, 11 OD HD W/26 WIDE CLIP, 9.8, 6280M, P-PT (RDO SPKR AMPF BRKT) |
|
2007-2009 |
01 |
| 020 |
11609599 |
STUD, SPL, M6X1X25, 13 THD, 11 OD HD W/26 WIDE CLIP, 9.8, 6280M, P-PT (RDO SPKR AMPF) |
|
2007-2009 |
01 |
