| Поз. | Номер | Описание | Применение | Номенклатура | Кол-во |
| 001 |
12160209 |
COVER, BAT NEG CBL TERM (ЧАСТЬ OF 6) (BLACK VINYL) (SURROUNDS CABLE END AT BATT SIDE TERM) |
EE (LH2, LY7) |
2007-2008 |
01 |
| 002 |
19115561 |
БОЛТ, HEX HD, 3/8-16X13/32, 1/4 THD, 1 5/32 TOTAL LG, 51/64 O.D., STL, ZP (ЧАСТЬ OF 6) (8.900) (ACDelco #19115561)
|
2007-2008 |
01 |
|
| 003 |
12010049 |
COVER, BAT NEG CBL БОЛТ (ЧАСТЬ OF 6) (BLACK) (SNAPS ON TO АККУМУЛЯТОР БОЛТ) |
EE (LH2, LY7) |
2007-2008 |
01 |
| 004 |
11589258 |
БОЛТ, BAT NEG CBL GND (M8X1.25X31)
| E (LH2, LY7) |
2007-2008 |
01 |
|
| 005 |
10306471 |
SENSOR, BAT CUR (ЧАСТЬ OF 6)
| EE26 (LH2, LY7) |
2007-2008 |
01 |
|
| 006 |
15804414 |
CABLE, BAT NEG (INCLS 1-3, 5) (ACDelco #15804414) |
EE (LY7, JJA, JJB, KG4) (EXPORT) |
2007-2008 |
01 |
| 007 |
12160210 |
COVER, BAT POS CBL TERM (ЧАСТЬ OF 10) (RED) (SURROUNDS CABLE END AT BATT SIDE TERM) |
EE (LY7, JJA, KG4) (EXPORT) |
2007-2008 |
01 |
| 007 |
12160210 |
COVER, BAT POS CBL TERM (ЧАСТЬ OF 10) (RED) (SURROUNDS CABLE END AT BATT SIDE TERM) |
EE (LY7, KG4) (EXPORT) |
2007-2008 |
01 |
| 008 |
19115561 |
БОЛТ, HEX HD, 3/8-16X13/32, 1/4 THD, 1 5/32 TOTAL LG, 51/64 O.D., STL, ZP (ЧАСТЬ OF 10) (8.900) (ACDelco #19115561)
|
2007-2008 |
01 |
|
| 009 |
12010050 |
COVER, BAT POS CBL БОЛТ (ЧАСТЬ OF 10) (RED) (HAS SLOTTED HOLE) (SNAPS ON TO АККУМУЛЯТОР БОЛТ) |
EE (LH2, LY7) (EXPORT) |
2007-2008 |
01 |
| 010 |
25834437 |
CABLE, BAT POS (INCLS 7-9, 13) (LABELED 25834437) (ACDelco #25834437) |
EE (LY7, JJB, KG4) |
2007-2008 |
01 |
| 011 |
21021808 |
ГАЙКА, STRTR SOL BAT TERM (LARGER) (M8X1.25X6, BRASS) (2.343)
| E |
2007-2008 |
01 |
|
| 012 |
25751146 |
GENERATOR, (СМ. ГРУППУ 02.000 КРЕПЛЕНИЕ ГЕНЕРАТОРА FOR DETAILLED ILLUSTRATED VIEW) (ACDelco #25751146)
| E (LY7, KG4) |
2007-2008 |
01 |
|
| 013 |
12146809 |
COVER, GEN WIRE TERM (ЧАСТЬ OF 10) (BLACK) (TERMINAL BOOT COVER) (2.343) |
E26 (LH2, LY7) |
2007-2008 |
01 |
| 014 |
11515535 |
ГАЙКА, BAT WIRE (2.559) |
E (LH2, LY7) |
2007-2007 |
01 |
| 015 |
11610091 |
ГАЙКА, BAT POS CBL (M8 X 1.25) (8.917) |
E (LH2, LY7) |
2007-2008 |
01 |
| 016 |
12608653 |
STARTER, (СМ. ГРУППУ 02.000 STARTER MOTOR ДЛЯ ДЕТАЛЬНОГО ПРОСМОТРА) (MAIN АККУМУЛЯТОР TERMINALS AT 1 7 OCLOCK) (ACDelco #12608653) |
E (LY7) |
2007-2007 |
01 |
| 017 |
|
CLIP, WRG HARN (ЧАСТЬ OF 23) |
|
2007-2008 |
|
| 018 |
11518121 |
ГАЙКА, U, M6X1, MULTI THD, .5-4.0 THK PNL (AIR INL HSG) |
|
2007-2008 |
05 |
| 019 |
11518121 |
ГАЙКА, U, M6X1, MULTI THD, .5-4.0 THK PNL (ЧАСТЬ OF 23) |
|
2007-2008 |
02 |
| 020 |
11516589 |
SCREW, HEX HD W/CON SPR WA, M6X1X30, 29 THD, 17 O.D., 9.8, 7114M, ZE (AIR INL) |
|
2007-2008 |
03 |
| 021 |
11516589 |
SCREW, HEX HD W/CON SPR WA, M6X1X30, 29 THD, 17 O.D., 9.8, 7114M, ZE (BAT TRAY) |
|
2007-2008 |
05 |
| 022 |
11609989 |
БОЛТ, HEX W/FLAT WASHER, M6X1X25, 15 THD, 17 OD, 6202M STL, GMW3200, TAPTITE (BAT TRAY)
|
2007-2008 |
02 |
|
| 023 |
15796853 |
TRAY, BAT (INCLS 17, 19) |
EE (EXPORT) |
2007-2008 |
01 |
| 024 |
25558374 |
RETAINER, BAT HOLDN (CENTER SLOT)
| E |
2007-2007 |
01 |
|
| 025 |
11610388 |
STUD, HFLGE, M8X1.25X20, M10X1.5X25, 22.3 OD, 9.8, GMW3200 (BAT CBL TERM) |
|
2007-2008 |
01 |
| 026 |
11589407 |
БОЛТ, HWH, M8X1.25X35, 23.5 THD, 24 OD, 10.9, GMW3359, M-PT. (BAT HOLDN RET)
|
2007-2008 |
01 |
|
| 027 |
88901964 |
АККУМУЛЯТОР, (CCA 650) (SIDE TERM) (260X178X168) (US DEALERS CONTACT ACDELCO WD FOR ORDERING PRICING INFO) (ACDelco #101-6YR) (PROFESSIONAL - 6 YR) |
EE26 (LH2, LY7) |
2007-2007 |
01 |
| 028 |
25747792 |
SHIELD, BAT HT (INSTALLED ON RH SIDE OF CAR) |
E26 |
2007-2007 |
01 |
