| Поз. | Номер | Описание | Применение | Номенклатура | Кол-во |
| 001 |
89058614 |
ГАЙКА, DIFF DRV P/GR
| E26 (MV3, MX5, M82, M22) |
2004-2006 |
01 |
|
| 002 |
|
FLANGE, RR WHL DRV SHF (*KIT2) |
|
2004-2007 |
|
| 003 |
19179933 |
SEAL KIT, DIFF DRV P/GR (INCLS FLANGE (105MM), SEAL NUT) (USE W/O CASTING NUMBER 6457038590 ON ШЛАНГИ DIFF DRV PINION GEAR, FOR 2ND DESIGN SEAL SERVICED SEPARATELY SEE 25861283.)
| E26 (M22, M82) (1ST DES) |
2004-2006 |
01 |
|
| 003 |
19179935 |
SEAL KIT, DIFF DRV P/GR (INCLS FLANGE (96MM), SEAL NUT) (USE W/O CASTING NUMBER 6457038590 ON ШЛАНГИ DIFF DRV PINION GEAR, FOR 2ND DESIGN SEAL SERVICED SEPARATELY SEE 25861283.)
| E26 (MV3, MX5) (1ST DES) |
2004-2004 |
01 |
|
| 003 |
25861283 |
SEAL, DIFF DRV P/GR (CAN USE SEAL ONLY W/CASTING #6457038590 ON ШЛАНГИ DIFF DRV PINION GEAR, FOR 1ST DESIGN MUST USE SEAL KIT 19179933.)
| E26 (M22, M82) (2ND DES) |
2004-2006 |
01 |
|
| 003 |
25861283 |
SEAL, DIFF DRV P/GR (CAN USE SEAL ONLY W/CASTING #6457038590 ON ШЛАНГИ DIFF DRV PINION GEAR, FOR 1ST DESIGN MUST USE SEAL KIT 19179935.)
| E26 (MV3, MX5) (2ND DES) |
2004-2004 |
01 |
|
| 004 |
|
BEARING, FRT DIFF DRV P/GR INR (ЧАСТЬ OF 5) |
|
2004-2009 |
|
| 005 |
19178962 |
ШЛАНГИ, DIFF DRV P/GR BRG (INCLS 4, 8, 9) (USED ON VEHICLES WITH CASTING NUMBER 6457038590 ON DIFF P/GR ШЛАНГИ , SEE 89048176 FOR 1ST DESIGN W/O CASTING NUMBER 6457038590.) |
E26 (MV3, MX5, M22, M82) (2ND DES) |
2004-2006 |
01 |
| 005 |
89048176 |
ШЛАНГИ, DIFF DRV P/GR BRG (INCLS 4, 8, 9) (5.453) (USED ON VEHICLES W/O CASTING NUMBER 6457038590 ON DIFF P/GR ШЛАНГИ, SEE 19178962 FOR 2ND DESIGN WITH CASTING NUMBER 6457038590.) |
E26 (MV3, MX5, M22, M82) (1ST DES) |
2004-2006 |
01 |
| 006 |
89048209 |
SHIM, DIFF DRV P/GR BRG (118X168X1.30MM) |
E26 (MV3, MX5, M22, M82) |
2004-2005 |
01 |
| 006 |
89048210 |
SHIM, DIFF DRV P/GR BRG (118X168X1.35MM) |
E26 (MV3, MX5, M22, M82) |
2004-2005 |
01 |
| 006 |
89048211 |
SHIM, DIFF DRV P/GR BRG (118X168X1.40MM) |
E26 (MV3, MX5, M22, M82) |
2004-2005 |
01 |
| 006 |
89048212 |
SHIM, DIFF DRV P/GR BRG (118X168X1.45MM) |
E26 (MV3, MX5, M22, M82) |
2004-2005 |
01 |
| 006 |
89048213 |
SHIM, DIFF DRV P/GR BRG (118X168X1.50MM) |
E26 (MV3, MX5, M22, M82) |
2004-2005 |
01 |
| 006 |
89048214 |
SHIM, DIFF DRV P/GR BRG (118X168X1.55MM) |
E26 (MV3, MX5, M22, M82) |
2004-2005 |
01 |
| 006 |
89048215 |
SHIM, DIFF DRV P/GR BRG (118X168X1.60MM) |
E26 (MV3, MX5, M22, M82) |
2004-2005 |
01 |
| 006 |
89048216 |
SHIM, DIFF DRV P/GR BRG (118X168X1.65MM) |
E26 (MV3, MX5, M22, M82) |
2004-2005 |
01 |
| 006 |
89048217 |
SHIM, DIFF DRV P/GR BRG (118X168X1.70MM) |
E26 (MV3, MX5, M22, M82) |
2004-2005 |
01 |
| 006 |
89048218 |
SHIM, DIFF DRV P/GR BRG (118X168X1.75MM) |
E26 (MV3, MX5, M22, M82) |
2004-2005 |
01 |
| 006 |
89048219 |
SHIM, DIFF DRV P/GR BRG (118X168X1.80MM) |
E26 (MV3, MX5, M22, M82) |
2004-2005 |
01 |
| 006 |
89048220 |
SHIM, DIFF DRV P/GR BRG (118X168X1.85MM) |
E26 (MV3, MX5, M22, M82) |
2004-2005 |
01 |
| 006 |
89048221 |
SHIM, DIFF DRV P/GR BRG (118X168X1.90MM) |
E26 (MV3, MX5, M22, M82) |
2004-2005 |
01 |
| 007 |
88984427 |
SEAL, DIFF DRV P/GR (O RING) |
E26 (MV3, MX5, M22, M82) |
2004-2006 |
01 |
| 008 |
|
SPACER, DIFF DRV P/GR BRG (ЧАСТЬ OF 5) |
|
2004-2009 |
|
| 009 |
|
BEARING, DIFF DRV P/GR INR (ЧАСТЬ OF 5) |
|
2004-2009 |
|
| 010 |
89058602 |
БОЛТ, DIFF CARR CVR (M8X1.25X30, 24 THD) (FLANGE HEAD) (5.476) |
E26 (MX5, M82) |
2004-2006 |
15 |
| 011 |
88984422 |
BUSHING, DIFF CARR SUPT (3.23 RATIO) (BUSHING W/O METAL SLEEVE) (1ST DES USED ON VEHICLES WITH LAST 6 OF VIN 156138 PRIOR FOR 2ND DES SEE 89058605.) |
E26 (M22) (1ST DES) |
2004-2004 |
01 |
| 011 |
88984422 |
BUSHING, DIFF CARR SUPT (3.23 RATIO) (BUSHING W/O METAL SLEEVE) (1ST DES USED ON VEHICLES WITH LAST 6 OF VIN 156273 PRIOR FOR 2ND DES SEE 89058605.) |
E26 (MV3) (1ST DES) |
2004-2004 |
01 |
| 011 |
88984422 |
BUSHING, DIFF CARR SUPT (3.73 RATIO) (BUSHING W/O METAL SLEEVE) (1ST DES USED ON VEHICLES WITH LAST 6 OF VIN 158091 PRIOR FOR 2ND DES SEE 89058605.) |
E26 (M82) (1ST DES) |
2004-2004 |
01 |
| 011 |
88984422 |
BUSHING, DIFF CARR SUPT (3.90 RATIO) (BUSHING W/O METAL SLEEVE) (1ST DES USED ON VEHICLES WITH LAST 6 OF VIN 156610 PRIOR FOR 2ND DES SEE 89058605.) |
E26 (MX5) (1ST DES) |
2004-2004 |
01 |
| 011 |
89058605 |
BUSHING, DIFF CARR SUPT (3.23 RATIO) (BUSHING W/METAL SLEEVE) (2ND DES USED ON VEHICLES WITH LAST 6 OF VIN 156139 AFTER FOR 1ST DES SEE 88984422.)
| E26 (M22) (2ND DES) |
2004-2004 |
01 |
|
| 011 |
89058605 |
BUSHING, DIFF CARR SUPT (3.23 RATIO) (BUSHING W/METAL SLEEVE) (2ND DES USED ON VEHICLES WITH LAST 6 OF VIN 156274 AFTER FOR 1ST DES SEE 88984422.)
| E26 (MV3) (2ND DES) |
2004-2004 |
01 |
|
| 011 |
89058605 |
BUSHING, DIFF CARR SUPT (3.73 RATIO) (BUSHING W/METAL SLEEVE) (2ND DES USED ON VEHICLES WITH LAST 6 OF VIN 158092 AFTER FOR 1ST DES SEE 88984422.)
| E26 (M82) (2ND DES) |
2004-2004 |
01 |
|
| 011 |
89058605 |
BUSHING, DIFF CARR SUPT (3.90 RATIO) (BUSHING W/METAL SLEEVE) (2ND DES USED ON VEHICLES WITH LAST 6 OF VIN 156611 AFTER FOR 1ST DES SEE 88984422.)
| E26 (MX5) (2ND DES) |
2004-2004 |
01 |
|
| 012 |
88996591 |
SEAL, R/AXL SHF |
E26 (MV3, MX5, M22, M82) |
2004-2006 |
02 |
| 013 |
|
КРОНШТЕЙН, DIFF |
|
2004-2009 |
|
| 014 |
|
GEAR, DIFF DRV PINION (*KIT1) |
|
2004-2009 |
|
| 015 |
89059039 |
PLUG, R/AXL HSG MAG DRN |
E26 (MV3, MX5, M22, M82) |
2004-2006 |
01 |
| 016 |
89058621 |
SHIM, DIFF BRG (79X89.3X1.30MM) |
E26 (MV3, MX5, M22, M82) |
2004-2005 |
02 |
| 016 |
89058622 |
SHIM, DIFF BRG (79X89.3X1.35MM) |
E26 (MV3, MX5, M22, M82) |
2004-2005 |
02 |
| 016 |
89058623 |
SHIM, DIFF BRG (79X89.3X1.40MM) |
E26 (MV3, MX5, M22, M82) |
2004-2005 |
02 |
| 016 |
89058624 |
SHIM, DIFF BRG (79X89.3X1.45MM) |
E26 (MV3, MX5, M22, M82) |
2004-2005 |
02 |
| 016 |
89058625 |
SHIM, DIFF BRG (79X89.3X1.50MM) |
E26 (MV3, MX5, M22, M82) |
2004-2005 |
02 |
| 016 |
89058626 |
SHIM, DIFF BRG (79X89.3X1.55MM) |
E26 (MV3, MX5, M22, M82) |
2004-2005 |
02 |
| 016 |
89058627 |
SHIM, DIFF BRG (79X89.3X1.60MM) |
E26 (MV3, MX5, M22, M82) |
2004-2005 |
02 |
| 016 |
89058628 |
SHIM, DIFF BRG (79X89.3X1.65MM) |
E26 (MV3, MX5, M22, M82) |
2004-2005 |
02 |
| 016 |
89058629 |
SHIM, DIFF BRG (79X89.3X1.70MM) |
E26 (MV3, MX5, M22, M82) |
2004-2005 |
02 |
| 016 |
89058630 |
SHIM, DIFF BRG (79X89.3X1.75MM) |
E26 (MV3, MX5, M22, M82) |
2004-2005 |
02 |
| 016 |
89058631 |
SHIM, DIFF BRG (79X89.3X1.80MM) |
E26 (MV3, MX5, M22, M82) |
2004-2005 |
02 |
| 016 |
89058632 |
SHIM, DIFF BRG (79X89.3X1.85MM) |
E26 (MV3, MX5, M22, M82) |
2004-2005 |
02 |
| 016 |
89058633 |
SHIM, DIFF BRG (79X89.3X1.90MM) |
E26 (MV3, MX5, M22, M82) |
2004-2005 |
02 |
| 016 |
89058634 |
SHIM, DIFF BRG (79X89.3X1.95MM) |
E26 (MV3, MX5, M22, M82) |
2004-2005 |
02 |
| 016 |
89058635 |
SHIM, DIFF BRG (79X89.3X2.00MM) |
E26 (MV3, MX5, M22, M82) |
2004-2005 |
02 |
| 016 |
89058636 |
SHIM, DIFF BRG (79X89.3X2.05MM) |
E26 (MV3, MX5, M22, M82) |
2004-2005 |
02 |
| 016 |
89058637 |
SHIM, DIFF BRG (79X89.3X2.10MM) |
E26 (MV3, MX5, M22, M82) |
2004-2005 |
02 |
| 016 |
89058638 |
SHIM, DIFF BRG (79X89.3X2.15MM) |
E26 (MV3, MX5, M22, M82) |
2004-2005 |
02 |
| 016 |
89058639 |
SHIM, DIFF BRG (79X89.3X2.20MM) |
E26 (MV3, MX5, M22, M82) |
2004-2005 |
02 |
| 016 |
89058640 |
SHIM, DIFF BRG (79X89.3X2.25MM) |
E26 (MV3, MX5, M22, M82) |
2004-2005 |
02 |
| 016 |
89058641 |
SHIM, DIFF BRG (79X89.3X2.30MM) |
E26 (MV3, MX5, M22, M82) |
2004-2005 |
02 |
| 016 |
89058642 |
SHIM, DIFF BRG (79X89.3X2.35MM) |
E26 (MV3, MX5, M22, M82) |
2004-2005 |
02 |
| 016 |
89058643 |
SHIM, DIFF BRG (79X89.3X2.40MM) |
E26 (MV3, MX5, M22, M82) |
2004-2005 |
02 |
| 017 |
88964481 |
BEARING, DIFF CARR |
E26 (MV3, MX5, M22, M82) |
2004-2006 |
02 |
| 018 |
19133286 |
DIFFERENTIAL, (СМ. ГРУППУ 05.000 DIFFERENTIAL КРОНШТЕЙН ЧАСТЬ 2 ДЛЯ ДЕТАЛЬНОГО ПРОСМОТРА) |
E26 (MV3, MX5, M22, M82) (EXC G80) |
2004-2006 |
01 |
| 018 |
19133286 |
DIFFERENTIAL, (СМ. ГРУППУ 05.000 DIFFERENTIAL КРОНШТЕЙН ЧАСТЬ 2 ДЛЯ ДЕТАЛЬНОГО ПРОСМОТРА) (5.510) |
E26 (MV3, MX5, M22, M82) (EXC G80) |
2004-2006 |
01 |
| 019 |
89058617 |
SEAL, DIFF CARR CVR |
E26 (MV3, MX5, M22, M82) |
2004-2006 |
01 |
| 020 |
19207629 |
COVER, DIFF CARR |
E26 (MV3, MX5, M22, M82) |
2004-2005 |
01 |
| 021 |
15852707 |
VENT, R/AXL HSG
| E26 (MV3, MX5, JJA) |
2004-2005 |
01 |
|
| 021 |
15852707 |
VENT, R/AXL HSG
| E26 (MV3, MX5, M22, M82) (EXC JJA) |
2004-2005 |
01 |
|
| 022 |
88996591 |
SEAL, R/AXL SHF |
E26 (MV3, MX5, M22, M82) |
2004-2006 |
02 |
| 023 |
89059038 |
PLUG, DIFF CARR FILL (M20X1.5X14) (W/SEAL) |
E (MV3, MX5, M22, M82) |
2004-2006 |
01 |
| 024 |
89048225 |
БОЛТ, RR DIFF R/GR (M12 X 25 MM) |
E26 (M22, G80) |
2004-2006 |
10 |
| 024 |
89048225 |
БОЛТ, RR DIFF R/GR (M12 X 25 MM) |
E26 (M82) |
2004-2006 |
10 |
| 024 |
89048225 |
БОЛТ, RR DIFF R/GR (M12 X 25 MM) |
E26 (MX5) |
2004-2006 |
10 |
| 024 |
89060126 |
БОЛТ, RR DIFF R/GR |
E26 (MV3) |
2004-2006 |
10 |
| 025 |
19178776 |
КРОНШТЕЙН, DIFF (3.23 RATIO) (INCLS 1-24) (COMPLETE/USE T/W 25730853 HSG VENT WHEN ORDERING DIFF КРОНШТЕЙН) |
E26 (MV3) (EXC JNG) |
2004-2004 |
01 |
| 025 |
19178783 |
КРОНШТЕЙН, DIFF (3.73 RATIO) (INCLS 1-24) |
E26 (M82) |
2004-2004 |
01 |
| 025 |
19181709 |
КРОНШТЕЙН, DIFF (3.23 RATIO) (INCLS 1-24) |
E26 (M22) |
2004-2004 |
01 |
| 025 |
19181710 |
КРОНШТЕЙН, DIFF (3.90 RATIO) (INCLS 1-24) (5.510) |
E26 (MX5) |
2004-2004 |
01 |
| K01 |
89048143 |
GEAR SET, DIFF RING DRV PINION (3.91 RATIO) (INCLS 14) |
E26 (MX5) |
2004-2006 |
01 |
| K01 |
89048144 |
GEAR SET, DIFF RING DRV PINION (3.23 RATIO) (INCLS 14) |
E26 (MV3, M22) |
2004-2005 |
01 |
| K01 |
89048145 |
GEAR SET, DIFF RING DRV PINION (3.73 RATIO) (INCLS 14) |
E26 (M82) |
2004-2006 |
01 |
| K02 |
19179933 |
SEAL KIT, DIFF DRV P/GR (INCLS 2) (INCLS FLANGE (105MM), SEAL NUT) (USE W/O CASTING NUMBER 6457038590 ON ШЛАНГИ DIFF DRV PINION GEAR, FOR 2ND DESIGN SEAL SERVICED SEPARATELY SEE 25861283.)
| E26 (M22, M82) (1ST DES) |
2004-2006 |
01 |
|
| K02 |
19179935 |
SEAL KIT, DIFF DRV P/GR (INCLS 2) (INCLS FLANGE (96MM), SEAL NUT) (USE W/O CASTING NUMBER 6457038590 ON ШЛАНГИ DIFF DRV PINION GEAR, FOR 2ND DESIGN SEAL SERVICED SEPARATELY SEE 25861283.)
| E26 (MV3, MX5) (1ST DES) |
2004-2004 |
01 |
|
