| Поз. | Номер | Описание | Применение | Номенклатура | Кол-во |
| 001 |
|
INSERT, FRT GRL (PART OF 7) |
|
2012-2013 |
|
| 002 |
|
INSERT, FRT GRL (PART OF 7) |
|
2012-2013 |
|
| 003 |
|
RIVET, FRT GRL (PART OF 7) |
|
2012-2013 |
|
| 004 |
|
GRILLE, FRT INR (PART OF 7) |
|
2012-2013 |
|
| 005 |
25705182 |
BOLT, FRT BPR FASCIA CTR SUPT (M9.5X6.0 HI-LO, TL 47MM, 22 OD) (12.249) |
CK1 (06-36) |
2007-2013 |
AR |
| 006 |
11610055 |
BOLT, HWASH, M6X1X23 (FRT BPR UPR FASCIA) |
|
2007-2013 |
06 |
| 007 |
20905198 |
GRILLE, FRT (INCLS 1-4, 8) (MAGNA STEEL) |
CK1 (06-36) (GHA, Z75) |
2011-2013 |
00 |
| 007 |
25841844 |
GRILLE, FRT (INCLS 1-4, 8) (CARBON FLASH) |
CK1 (06) (Z75, 58U) |
2011-2013 |
01 |
| 007 |
20957095 |
GRILLE, FRT (INCLS 1-4, 8) (CLARET) |
CK1 (06) (Z75, 89U) |
2012-2013 |
01 |
| 007 |
20957108 |
GRILLE, FRT (INCLS 1-4, 8) (SILVER) |
CK1 (06-36) (GAN, Z75) |
2012-2013 |
01 |
| 007 |
20946007 |
GRILLE, FRT (INCLS 1-4, 8) (PEARL) |
CK1 (06) (GKP, Z75) |
2011-2013 |
01 |
| 007 |
22860578 |
GRILLE, FRT (INCLS 1-4, 8) (PINO NOIR) |
CK1 (06-36) (GWU, Z75) |
2013-2013 |
01 |
| 007 |
22860579 |
GRILLE, FRT (INCLS 1-4, 8) (BLUE) |
CK1 (06) (GXH, Z75) |
2013-2013 |
01 |
| 007 |
22860580 |
GRILLE, FRT (INCLS 1-4, 8) (SILVER) |
CK1 (06) (GWT, Z75) |
2013-2013 |
01 |
| 007 |
22860569 |
GRILLE, FRT (INCLS 1-4, 8) (WHITE) |
CK1 (06-36) (Z75, 98U) |
2011-2013 |
01 |
| 007 |
22860570 |
GRILLE, FRT (INCLS 1-4, 8) (BLACK) |
CK1 (06-36) (Z75, 41U) |
2011-2013 |
01 |
| 008 |
22860587 |
EMBLEM, FRT GRL (PART OF 7) (WREATH/CREAST) |
CK1 (06-36) (Z75) (EXC T84, ULT, WHN) |
2012-2013 |
01 |
| 009 |
15907251 |
MOLDING, HOOD FRT (INCLS 10) (CHROME) |
CK1 (06-36) (Z75) (EXC ULT) |
2008-2013 |
01 |
| 010 |
11561788 |
CLIP, 13X15X12, 1.5 PNL, 1050, 6280M (PART OF 9) |
|
2007-2013 |
07 |
| 011 |
11518121 |
NUT, U, M6X1, MULTI THD, .5-4.0 THK PNL (FRT GRL UPR BRKT) |
|
2007-2013 |
08 |
| 012 |
|
FASCIA, FRT BPR (SEE GROUP 07.000 BUMPER/FRONT FOR DETAILED ILLUSTRATED VIEW) (PAINT TO MATCH) |
|
2007-2013 |
|
