| Поз. | Номер | Описание | Применение | Номенклатура | Кол-во |
| 001 |
15856795 |
STRAP, ENG GND (ACDelco #15856795) |
CK1, 2, 3 (ARL, JAN, MSL, OSG, KG3, KW1, 9L4) |
2007-2009 |
01 |
| 001 |
15921158 |
STRAP, ENG GND (ACDelco #15921158) |
CK1, 2, 3 (CMD, FWI, GMC, KG3, KW1, 9L4) |
2007-2009 |
01 |
| 002 |
11609411 |
ГАЙКА, HEX W/CON WA, M6X1, 5.7 THK, 16 OD, 9, GMW3200 (ENG GND STRP)
|
2007-2009 |
01 |
|
| 003 |
11609619 |
БОЛТ, HEX W/ FL WA-M10X1.5X16, 20 OD, 10.9 STL, GMW3200 FINISH (ENG GND STRP)
|
2007-2009 |
01 |
|
| 004 |
25825642 |
CABLE, AUX BAT POS (INCLS 23, 25, 27) (ACDelco #25825642)
| CK107 (06) (6A6, PPV) |
2007-2009 |
01 |
|
| 004 |
25927555 |
CABLE, AUX BAT POS (INCLS 23, 25, 27) (LABELED 25927555) (LABELED 25927555) |
CK1 (06) (LFA, HP2) (EXC PPV) |
2008-2009 |
01 |
| 004 |
25954910 |
CABLE, AUX BAT POS (INCLS 23, 25, 27) |
CK1 (06) (LFA, HP2) (EXC PPV) |
2008-2009 |
01 |
| 005 |
|
GENERATOR, (СМ. ГРУППУ 02.000 КРЕПЛЕНИЕ ГЕНЕРАТОРА ДЛЯ ДЕТАЛЬНОГО ПРОСМОТРА) |
|
2007-2009 |
|
| 006 |
11609411 |
ГАЙКА, HEX W/CON WA, M6X1, 5.7 THK, 16 OD, 9, GMW3200 (BAT POS CBL)
|
2007-2009 |
01 |
|
| 007 |
20771932 |
CABLE, GEN BAT JPR (LABELED 20771932) (ACDelco #20771932) |
CK1, 2, 3 (EXC VYU) |
2009-2009 |
01 |
| 007 |
25996788 |
CABLE, GEN BAT JPR (ACDelco #25996788) |
CK1, 2, 3 (KG3, VYU) |
2009-2009 |
01 |
| 008 |
21021808 |
ГАЙКА, GEN BAT (M8X1.25X6, BRASS) (2.343)
| CK1, 2, 3 |
2007-2009 |
01 |
|
| 010 |
11516885 |
SCREW, HFH W/FL WA, TAP, M8X1.25X20, 7THD, 17 O.D., TR PT, 6202M, PZOR (BAT POS CBL CLIP) |
|
2007-2009 |
01 |
| 011 |
|
STARTER, (СМ. ГРУППУ 02.000 КРЕПЛЕНИЕ СТАРТЕРА ДЛЯ ДЕТАЛЬНОГО ПРОСМОТРА) |
|
2007-2009 |
|
| 012 |
21021808 |
ГАЙКА, STRTR SOL CBL (M8X1.25X6, BRASS)
| CK1, 2, 3 (EXC HP2) |
2007-2009 |
01 |
|
| 013 |
10306471 |
SENSOR, BAT CUR (PART OF 16)
| CK1 |
2007-2009 |
01 |
|
| 014 |
25925265 |
CLIP, BAT CBL (PART OF 16) |
CK1 (06) (HP2) |
2008-2009 |
01 |
| 014 |
25925268 |
CLIP, BAT CBL (PART OF 16) |
CK1 (06) (HP2) |
2008-2009 |
04 |
| 016 |
25897052 |
CABLE, BAT NEG (INCLS 13, 14, 18-20) (ACDelco #25897052) |
CK1 (9L4) |
2007-2009 |
01 |
| 017 |
11588337 |
БОЛТ, HEX W/FL WA, M6X1X20, 9 THD, 17 OD, 6202M, GMW3200, TAP, DOG PT. (FWD LP WRG HARN GND)
|
2007-2009 |
01 |
|
| 019 |
|
WASHER, BAT CBL TERM (PART OF 9, 16, 18) |
|
2007-2009 |
|
| 020 |
|
ГАЙКА, BAT CBL TERM (PART OF 9, 16, 18) |
|
2007-2009 |
|
| 023 |
21021808 |
ГАЙКА, BAT HDL (PART OF 4) (M8X1.25X6, BRASS) (2.343)
| CK1, 2, 3 |
2007-2009 |
04 |
|
| 024 |
21011332 |
ГАЙКА, HEX STAMPED TY DF FLG 14 (BAT POS CBL RET) (8.921) |
|
2007-2009 |
04 |
| 025 |
15305191 |
FUSE, 175 AMP MEGA (PART OF 4) ( FUSE COLOR, BLACK W/SIZE STAMPED IN WHITE ON CASE)
|
2007-2009 |
02 |
|
| 026 |
21011332 |
ГАЙКА, HEX STAMPED TY DF FLG 14 (BAT POS CBL RET) (8.921) |
|
2007-2009 |
01 |
| 027 |
19116352 |
HOLDER, WRG HARN FUSE (PART OF 4) |
CK1, 2, 3 (9L4) |
2007-2009 |
01 |
| 027 |
19116352 |
HOLDER, WRG HARN FUSE (PART OF 4) |
CK1, 2, 3 (TP2) |
2007-2009 |
01 |
| 027 |
19116352 |
HOLDER, WRG HARN FUSE (PART OF 4) |
CK107 (06) (PPV, 5W4) |
2007-2009 |
01 |
| 028 |
15881616 |
COVER, BAT POS CBL J/BLK (3 WAY MEGAFUSE) |
CK1, 2, 3 (PPV, 5W4, 9L4) |
2007-2009 |
01 |
