| Поз. | Номер | Описание | Применение | Номенклатура | Кол-во |
| 001 |
25955528 |
SUPPORT, RAD (INCLS 2-10) |
CK1 (06-36) (EXC VD1) |
2007-2009 |
01 |
| 001 |
25955529 |
SUPPORT, RAD (INCLS 2-10)
| K1 (06) (VD1) (EXPORT) |
2009-2009 |
01 |
|
| 002 |
11561916 |
NUT-INSERT, M8X1.25, 13.5 HOLE, 0.7-3.8 GRIP, 24 LONG, 17.4 OD, 1008, GMW (PART OF 1, 3) |
|
2007-2009 |
12 |
| 003 |
25870919 |
SUPPORT, F/END UPR TIE BAR (INCLS 2, 4, 6) (PART OF 1)
| CK1 (06-36) (EXC VD1) |
2009-2009 |
01 |
|
| 003 |
25870919 |
SUPPORT, F/END UPR TIE BAR (INCLS 2, 4, 6) (PART OF 1)
| K1 (06) (VD1) |
2009-2009 |
01 |
|
| 004 |
|
ГАЙКА, RAD SUPT (PART OF 1, 3) |
|
2007-2009 |
|
| 005 |
11609989 |
БОЛТ, HEX W/FLAT WASHER, M6X1X25, 15 THD, 17 OD, 6202M STL, GMW3200, TAPTITE (PART OF 1, 9)
|
2007-2009 |
04 |
|
| 006 |
11561407 |
NUT-INSERT , M6X1, 10MM HOLE, 1.7-5.25 PANEL, 19 LONG, 12.9 OD, 1008, GMW3 (PART OF 1, 3, 9) (8.921) |
|
2007-2009 |
47 |
| 007 |
11516932 |
БОЛТ, HEX HD, W/CON WA, M6X1X25, 9.8, 6138M (PART OF 1) |
|
2007-2009 |
06 |
| 008 |
15744933 |
БОЛТ, HEX HD, W/CON WA, M6X1X45 (PART OF 1) (1.267) |
|
2007-2009 |
04 |
| 009 |
25870915 |
BRACE, F/END SH MET RAD OPG (INCLS 5, 6, 10) (PART OF 1) |
CK1 (06-36) (EXC VD1) |
2009-2009 |
01 |
| 009 |
25870916 |
BRACE, F/END SH MET RAD OPG (INCLS 5, 6, 10) (PART OF 1) |
K1 (06) (VD1) (EXC UHT) |
2007-2009 |
01 |
| 009 |
25870916 |
BRACE, F/END SH MET RAD OPG (INCLS 5, 6, 10) (PART OF 1) |
K1 (06) (VD1) |
2009-2009 |
01 |
| 010 |
25870918 |
BRACE, F/END SH MET CR (PART OF 1, 9) |
CK1, 2 (06) |
2007-2009 |
01 |
