| Поз. | Номер | Описание | Применение | Номенклатура | Кол-во |
| 001 |
25815065 |
BRACE, F/END SH MET DIAG |
CK1, 2, 3 |
2007-2008 |
01 |
| 002 |
11609989 |
БОЛТ, HEX W/FLAT WASHER, M6X1X25, 15 THD, 17 OD, 6202M STL, GMW3200, TAPTITE (F/END SH MET DIAG BR)
|
2007-2008 |
02 |
|
| 003 |
11515755 |
БОЛТ, HEX, M8X1.25X16, 15 THD, 18 O.D., 10.9, 7114M (F/FDR RR UPR BR) (T/W 12345493 REPLCS 25534835)
|
2007-2008 |
08 |
|
| 004 |
15185449 |
BRACE, F/FDR RR UPR |
CK1, 2, 3 |
2007-2008 |
01 |
| 004 |
15185450 |
BRACE, F/FDR RR UPR |
CK1, 2, 3 |
2007-2008 |
01 |
| 005 |
11610010 |
БОЛТ, HEX W/ CON WA, M8X1.25X40, 32 THD, 28 OD, 9.8, 7114M, MACH, P-PT (F/FDR INR PNL)
|
2007-2008 |
04 |
|
| 006 |
15870422 |
BRACKET, F/FDR UPR
| CK1, 2, 3 |
2007-2008 |
01 |
|
| 006 |
15951193 |
BRACKET, F/FDR UPR |
CK1 (36) |
2007-2008 |
01 |
| 007 |
11570082 |
БОЛТ, HFH, M8X1.25X22, 19 THD, 18 OD, 10.9, GMW3359 (F/FDR UPR BRKT) (ACDelco #11570082)
|
2007-2008 |
06 |
|
| 008 |
15887400 |
BRACKET, КАПОТ HGE LWR (PART OF 9) |
CK1, 2, 3 |
2007-2008 |
01 |
| 008 |
15887401 |
BRACKET, КАПОТ HGE LWR (PART OF 9) |
CK1, 2, 3 |
2007-2008 |
01 |
| 009 |
25819548 |
КРЫЛО, FRT (INCLS 8)
| CK1 (06-36) (Z75) (EXC VD1) |
2007-2008 |
01 |
|
| 009 |
25819549 |
КРЫЛО, FRT (INCLS 8) |
CK1 (06-36) (Z75) (EXC VD1) |
2007-2008 |
01 |
| 010 |
11516149 |
ГАЙКА, U, 8X1.25, MULTI THD, .08-4.0 THK PNL, PZ (F/FDR RR UPR BRKT)
|
2007-2008 |
02 |
|
| 011 |
15860253 |
INSERT, F/FDR CTR RR UPR MLDG
| CK1 (06-36) (Z75) |
2007-2008 |
01 |
|
| 011 |
15860254 |
INSERT, F/FDR CTR RR UPR MLDG
| CK1 (06-36) (Z75) |
2007-2008 |
01 |
|
| 012 |
11562187 |
NUT-U, M8X1.25, SAE 1050 STL, GMW3179-A (F/FDR RR CTR BRKT) |
|
2007-2008 |
02 |
| 013 |
25948814 |
BRACKET, FRT BPR FASCIA SI (INCLS 14)
| CK1, 2 (06-36) (Z75) |
2007-2008 |
01 |
|
| 013 |
25948815 |
BRACKET, FRT BPR FASCIA SI (INCLS 14)
| CK1, 2 (06-36) (Z75) |
2007-2008 |
01 |
|
| 014 |
11518531 |
ГАЙКА, U-TYPE, M4.2X1.41, 15.9X8.4, .7-2.1 PNL, SAE 1050 STL, 7111M, 8.65 SQ HOL (PART OF 13) (10.512)
|
2007-2008 |
02 |
|
| 015 |
11517164 |
SCREW, HEX M8X1.25X20 W/CON WA (F/FDR LWR) |
|
2007-2008 |
02 |
| 016 |
11589292 |
PUSH PIN, FITS 8.5 DIA HOLE IN 2-4.5 THK PNL, NYLON 6/6 GMP.PA66.015 (FRT W/H LNR (PUSH IN))
|
2007-2008 |
10 |
|
| 017 |
11609952 |
NUT-U, M4.2X1.41, 15.9X8.4, .7-2.1 PNL, SAE 1050 STL, 7111M, 8.65 SQ HOL (FRT W/H LNR) |
|
2007-2008 |
04 |
| 018 |
11562172 |
БОЛТ, FRT W/H LNR
| CK1, 2 (06-36) |
2007-2008 |
04 |
|
| 019 |
10121502 |
RETAINER, FITS .250 HOLE, 1.01LG.700-OD NYLON BLACK (FRT BPR FASCIA OTR BRKT)
|
2007-2008 |
04 |
|
| 020 |
11609489 |
БОЛТ, HEX W/ WASHER, 4.2X1.41X25, 14.5 THD17 OD, GM6010M STL, GMW4205 (FRT BPR FASCIA OTR BRKT)
|
2007-2008 |
04 |
|
| 021 |
11519949 |
RETAINER, FRT W/H LNR (PUSH IN) (20MM DIA X 13.4MM) (PUSH PIN GROMMET) (10.154)
| CK1, 2, 3 |
2007-2008 |
01 |
|
| 022 |
11562024 |
RETAINER, PUSH IN, 7.5X36.5, FITS 6.35 HOLE IN 2.29-18.34 THK PNL (FRT W/H LNR (PUSH IN))
|
2007-2008 |
02 |
|
| 023 |
15926174 |
LINER, FRT W/H
| CK1 (06-36) (Z75) (EXC ULT) |
2008-2008 |
01 |
|
| 024 |
11610010 |
БОЛТ, HEX W/ CON WA, M8X1.25X40, 32 THD, 28 OD, 9.8, 7114M, MACH, P-PT (F/FDR INR PNL)
|
2007-2008 |
06 |
|
| 025 |
11610055 |
БОЛТ, HWASH, M6X1X23 (FRT BPR FASCIA SI BRKT) |
|
2007-2008 |
04 |
| 026 |
25826685 |
INSULATOR, COWL S/PNL |
CK1, 2, 3 |
2007-2008 |
01 |
| 026 |
25877094 |
INSULATOR, COWL S/PNL |
CK1, 2, 3 |
2007-2008 |
01 |
| 027 |
11516150 |
ГАЙКА, U, M8X1.25X32.0, 6H STYLE 11, STL, PZOR (F/FDR LWR)
| 1, 2, 3 (36) |
2007-2008 |
02 |
|
| 028 |
15862261 |
BRACKET, FRT W/H PNL UPR |
CK1, 2, 3 |
2007-2008 |
01 |
| 029 |
15926175 |
LINER, FRT W/H
| CK1 (06-36) (Z75) (EXC ULT) |
2008-2008 |
01 |
|
| 031 |
15893710 |
SHIELD, ENG LWR FRT SPH |
CK1 (06-36) |
2007-2008 |
01 |
| 031 |
15893711 |
SHIELD, ENG LWR FRT SPH |
CK1 (06-36) |
2007-2008 |
01 |
| 032 |
11517560 |
SCREW, FLAT WA (NRW) AND HX WA HD, M8X1.25X25 (ENG LWR FRT SPH SHLD) |
|
2007-2008 |
04 |
