| Поз. | Номер | Описание | Применение | Номенклатура | Кол-во |
| 001 |
88944019 |
WEATHERSTRIP, CARGO BOX STOW M/GATE WDO OPG (PART OF 12) |
K109 (36) (DT3, EN4) |
2007-2008 |
01 |
| 001 |
88944020 |
WEATHERSTRIP, CARGO BOX STOW M/GATE WDO OPG (PART OF 12) |
K109 (36) (DT3, EN4) |
2007-2008 |
01 |
| 002 |
20538173 |
RETAINER, PUBX S/PNL SHLD (PART OF 12) (BLACK) (13.9 X 11.09) (X-MAS TREE) (14.685) |
K1 (36) (DT3, EN4) |
2007-2009 |
01 |
| 003 |
88944021 |
HARNESS, CARGO BOX STOW BOX LP WRG (PART OF 12) (INCLS LAMP SOCKET) |
K1 (36) (DT3, EN4) |
2007-2009 |
01 |
| 004 |
11516669 |
ГАЙКА, PUSH ON, M10, 20.O.D, STL, ZOR (PART OF 12) |
|
2007-2009 |
08 |
| 005 |
|
SPACER, CARGO TIE DN LOOP (PART OF 12) |
|
2007-2009 |
|
| 006 |
11609385 |
ГАЙКА, U-TYPE, M6X1, 29.5 LEN, 12.5 WID, 19.5 CEN-END, 1050, GMW3359 (PART OF 12)
|
2007-2009 |
12 |
|
| 007 |
|
BOX, CARGO BOX STOW (PART OF 12) |
|
2007-2009 |
|
| 008 |
|
БОЛТ, R/CMPT CONVENIENCE HOOK (PART OF 12) |
|
2007-2009 |
|
| 009 |
88937501 |
STRIKER, CARGO BOX CVR LAT (PART OF 12) (FRONT) |
K1 (36) (DT3, EN4) |
2007-2009 |
01 |
| 009 |
88937502 |
STRIKER, CARGO BOX CVR LAT (PART OF 12) (FRONT) |
K1 (36) (DT3, EN4) |
2007-2008 |
01 |
| 009 |
88937503 |
STRIKER, CARGO BOX CVR LAT (PART OF 12) (REAR) |
K1 (36) (DT3, EN4) |
2007-2009 |
03 |
| 009 |
88937504 |
STRIKER, CARGO BOX CVR LAT (PART OF 12) (REAR) |
K1 (36) (DT3, EN4) |
2007-2008 |
03 |
| 010 |
11609374 |
BOLT-WASHER, M6X1X16, 17 OD, 12 THD, 9.8, GMW3359, 1.47 H-REG FL WA. (PART OF 12) |
|
2007-2009 |
16 |
| 011 |
11516630 |
SCREW, RD, M4.2X1.41X20, TYPE AB PT, GM6010M, GMW4205 (PART OF 12) |
|
2007-2009 |
01 |
| 012 |
25853774 |
BOX, CARGO BOX STOW (INCLS 1-11, 13, 15-18) |
K1 (36) (DT3, EN4) |
2007-2009 |
01 |
| 012 |
25853774 |
BOX, CARGO BOX STOW (INCLS 1-11, 13, 15-18) (16.583) |
K1 (36) (DT3, EN4) |
2007-2009 |
01 |
| 012 |
25853775 |
BOX, CARGO BOX STOW (INCLS 1-11, 13, 15-18) |
K1 (36) (DT3, EN4) |
2007-2009 |
01 |
| 012 |
25853775 |
BOX, CARGO BOX STOW (INCLS 1-11, 13, 15-18) (16.583) |
K1 (36) (DT3, EN4) |
2007-2009 |
01 |
| 013 |
11518359 |
PUSH PIN- FITS 8.0-8.25 DIA HOLE, 14.0 NOSE LENGTH, GMP.PA66.078, BLA (PART OF 12) |
|
2007-2009 |
28 |
| 014 |
11561547 |
RIVET, CARGO BOX STOW BOX LOCR (6.45DIA X 14.48, 13 OD, 1038 STL, GMW3044, 1.45-4.0 GRP RNG) (8.808) |
K1 (36) (DT3) |
2007-2009 |
04 |
| 015 |
|
BOX, CARGO BOX STOW (PART OF 12) |
|
2007-2009 |
|
| 016 |
88944018 |
LAMP, CARGO BOX STOW (PART OF 12) |
K1 (36) (DT3, EN4) |
2007-2008 |
01 |
| 017 |
12450313 |
BULB, WEDGE BASE, 12.8VOLTS, 1.4AMPS, 21CP, TRADE NO. 921 (PART OF 12) (ACDelco #W16W921)
|
2007-2009 |
02 |
|
