(TC06-635) - 1999-2007 CK2 РУЛЕВОЙ МЕХАНИЗМ В СБОРЕ CADILLAC - ESCALADE EXT (AWD) 2005

Поз.НомерОписаниеПрименениеНоменклатураКол-во
001 RING, S/GR HSG PLUG RET (*KIT7) 1999-2007
002 07805525 PLUG, S/GR HSG CK2, 3 2001-2007 01
003 SEAL, S/GR HSG PLUG (O RING) (*KIT7) 1999-2007
004 COVER, S/GR HSG (*KIT10) 1999-2007
005 05687973 ГАЙКА, S/GR PIT SHF ADJR (7/16 - 20 UNF-38 THD) (LASH ADJUSTER) (*KIT10) CK1, 2, 3 2001-2007 01
006 07816516 БОЛТ, S/GR HSG CVR (3/8-16X.90 HEX HD) CK2, 3 2001-2007 04
007 GASKET, S/GR HSG CVR (*KIT6, KIT10) 1999-2007
008 GEAR, PIT SHF (*KIT11) 1999-2007
009 07817355 PLUG, S/GR RACK (*KIT8) CK2, 3 2001-2007 01
010 RING, S/GR RACK (TEFLON) (*KIT1, KIT8) 1999-2007
011 SEAL, S/GR RACK (O RING) (*KIT10) 1999-2007
012 RACK, S/GR (*KIT8) 1999-2007
013 BALL, S/GR (*KIT8, KIT9) 1999-2007
014 05695774 GUIDE, S/GR BALL RTN (*KIT8) CK2, 3 2001-2007 02
015 05686539 CLAMP, S/GR BALL RTN GDE (*KIT8) CK2, 3 2001-2007 01
016 05696151 БОЛТ, S/GR BALL RTN GDE CLA (1/4-28 NF-2A THD) (*KIT8) CK2 1999-2007 02
017 07834284 VALVE KIT, S/GR CHK (INCLS VALVE ASM INSTR SHEET) CK2, 3 2001-2007 01
018 RACE, S/GR WMGR THR BRG (*KIT12) 1999-2007
019 BEARING, S/GR WMGR THR (*KIT12) 1999-2007
020 RACE, S/GR WMGR THR BRG (*KIT12) 1999-2007
021 GEAR, S/GR WORM (*KIT8) 1999-2007
022 05697804 BEARING, S/GR PIT SHF CK1, 2, 3 2001-2007 01
023 SEAL, PITMAN SHF (*KIT4) 1999-2007
024 WASHER, S/GR PIT SHF (*KIT4) 1999-2007
025 RING, S/GR PIT SHF SEAL RET (*KIT4) 1999-2007
026 SEAL, DUST (*KIT4) 1999-2007
027 26000985 BOOT, PIT ARM CK1, 2, 3 2001-2007 01
028 19168473 ARM KIT, PIT (USE T/W 19153392) (3 GROOVE APPLICATIONS) CK2, 3 2001-2007 01
028 19168944 ARM KIT, PIT (T/W 19178433) (4 GROOVE SPLINE) CK2, 3 2001-2007 01
029 05697702 WASHER, PIT ARM (7/8) (SPECIAL LOCK TYPE) CK2, 3 2001-2007 01
030 05667628 ГАЙКА, PIT ARM (7/8-14) (SPECIAL HEX) CK2, 3 2001-2007 01
031 SEAL, S/GR STUB SHF (O RING) (PART OF 35) 1999-2007
