| Поз. | Номер | Описание | Применение | Номенклатура | Кол-во |
| 001 |
|
BLOCK, ENG WRG HARN JUNC (СМ. ГРУППУ 02.000 BLOCK-UNDERHOOD BEC ДЛЯ ДЕТАЛЬНОГО ПРОСМОТРА) (WILL ACCEPT 5-TERM FOG LP RELAY 12077866) |
|
2001-2007 |
|
| 002 |
15895625 |
HARNESS, TRFER CASE SEL SHFT CONT SW WRG (TR/CASE TO U/H BEC FRT AXLE HARN) |
K1 (NP2) |
2005-2007 |
01 |
| 002 |
15895626 |
HARNESS, TRFER CASE SEL SHFT CONT SW WRG (TR/CASE TO U/H BEC FRT AXLE HARN) |
K2, 3 (NP2) |
2005-2007 |
01 |
| 003 |
15771689 |
HARNESS, TRFER CASE SEL SHFT CONT SW WRG HARN EXTN |
K1, 2, 3 (NP1, NP2, NP8) |
2003-2007 |
01 |
| 004 |
15745393 |
BRACKET, TRFER CASE SEL SHFT CONT SW WRG HARN RET |
K2, 3 (M74, NP1, NP2) |
2001-2005 |
01 |
| 005 |
11514597 |
ГАЙКА, HFH, 10X1.5 THD, 9.8 THK, 21.8 OD, 510M (10) ZF 7111M (TRFER CASE) (2.383) |
|
2001-2007 |
06 |
| 006 |
11588337 |
БОЛТ, ELEK BRK CONT WRG HARN GND (6 X 1 X 20) (8.900) (1ST DES SEE 11610073)
| K1, 2, 3 (EXC JVA) (2ND DES) |
2005-2005 |
01 |
|
| 006 |
11588337 |
БОЛТ, ELEK BRK CONT WRG HARN GND (6 X 1 X 20) (8.900) (1ST DES SEE 11610073)
| K1, 2, 3 (LM7, LQ4, LQ9, LR4, LU3, L18, L31, L33, L59) (2ND DES) |
2005-2005 |
01 |
|
| 006 |
11610073 |
БОЛТ, ELEK BRK CONT WRG HARN GND (M8X1.25X16, 12.45THD) (13MM SOCKET) (8.900) (2ND DES SEE 11588337) |
K1, 2, 3 (EXC JVA) (1ST DES) |
2005-2005 |
01 |
| 006 |
11610073 |
БОЛТ, ELEK BRK CONT WRG HARN GND (M8X1.25X16, 12.45THD) (13MM SOCKET) (8.900) (2ND DES SEE 11588337) |
K1, 2, 3 (LM7, LQ4, LQ9, LR4, LU3, L18, L31, L33, L59) (1ST DES) |
2005-2005 |
01 |
| 006 |
15709061 |
БОЛТ, ELEK BRK CONT WRG HARN GND (M8X1.25, 12.5) (2.343) |
K1, 2, 3 (EXC JVA) |
2005-2005 |
01 |
