| Поз. | Номер | Описание | Применение | Номенклатура | Кол-во |
| 001 |
24100440 |
HOSE, FUEL FEED EVAP EMIS RTN (INCLS 2-5, 10-12, 14) |
CK2 (06-36) (LQ4, L18) |
2004-2006 |
01 |
| 002 |
15168649 |
CLIP, FUEL FEED EVAP EMIS RTN HOSE (PART OF 1) (ANTI-RATTLE) |
CK2 (06-36) (LQ4, L18) |
2004-2006 |
02 |
| 003 |
|
RETAINER, FUEL FEED PIPE CONN (PART OF 1) |
|
2004-2006 |
|
| 004 |
15168645 |
CLIP, FUEL FEED EVAP EMIS RTN HOSE (PART OF 1) (RETAINER) |
CK2 (06-36) (LQ4, L18) |
2004-2006 |
01 |
| 005 |
15168647 |
CLIP, FUEL FEED EVAP EMIS RTN HOSE (PART OF 1) (2 TUBE) |
CK2 (06-36) (LQ4, L18) |
2004-2006 |
02 |
| 006 |
|
HOSE, FUEL FEED RTN (СМ. ГРУППУ 03.000 СИСТЕМА ТОПЛИВОСНАБЖЕНИЯ-REAR ДЛЯ ДЕТАЛЬНОГО ПРОСМОТРА) |
|
2004-2006 |
|
| 007 |
11514519 |
ГАЙКА, HEX W/23.75 OD CON WA, M8X1.25, 7.32THK, 9, PZOR (FUEL FEED RTN FRT PIPE CLIP)
|
2004-2006 |
03 |
|
| 008 |
11516521 |
БОЛТ, HFH M6X1X20, 9.8, 7114M, DOG PT, 14.2 OD (FUEL FEED RTN FRT HOSE BRKT) |
|
2004-2006 |
01 |
| 009 |
|
BRACKET, FUEL FEED RTN FRT HOSE (СМ. ГРУППУ 03.000 СИСТЕМА ТОПЛИВОСНАБЖЕНИЯ-FRONT ЧАСТЬ 2 ДЛЯ ДЕТАЛЬНОГО ПРОСМОТРА) |
|
2004-2006 |
|
| 010 |
15033234 |
BRACKET, FUEL FEED RTN FRT HOSE (PART OF 1) (W/WELD STUD 2 STAGGERED SLOTTED HOLES) |
CK2 (06-36) (LQ4, L18) |
2004-2006 |
01 |
| 011 |
15085404 |
CLIP, FUEL FEED EVAP EMIS RTN HOSE (PART OF 1) (AT HOSE/PIPE CONNECTION) |
CK2 (06-36) (LQ4, L18) |
2004-2006 |
02 |
| 012 |
15168648 |
CLIP, FUEL FEED EVAP EMIS RTN HOSE (PART OF 1) (W/RETAINER) |
CK2 (06-36) (LQ4, L18) |
2004-2006 |
01 |
| 013 |
11514596 |
ГАЙКА, HFH, M8X1.25, 17.9 OD, 738 THK, 13MM HEX, 10, ZF (FUEL FEED RTN FRT HOSE BRKT) (8.915) (ACDelco #11514596) |
|
2004-2006 |
01 |
| 014 |
15085402 |
BRACKET, FUEL FEED EVAP EMIS RTN HOSE (PART OF 1) |
CK2 (03-36) (LQ4, L18) |
2004-2006 |
01 |
| 014 |
15085402 |
BRACKET, FUEL FEED EVAP EMIS RTN HOSE (PART OF 1) |
CK2 (06-36) (LQ4, L18) |
2005-2005 |
01 |
| 015 |
12573161 |
TUBE, EVAP EMIS CNSTR PURGE |
CK2, 3 (L18) |
2004-2006 |
01 |
| 015 |
12575527 |
TUBE, EVAP EMIS CNSTR PURGE |
CK1, 2, 3 (LM7, LQ4, LQ9, LR4, L33, L59) |
2005-2006 |
01 |
| 016 |
22695614 |
RETAINER, FUEL FEED HOSE CONN (13 X 19 X 36MM) (ONE TUBE)
| CK1, 2, 3 |
2005-2006 |
01 |
|
| 018 |
11514597 |
ГАЙКА, HFH, 10X1.5 THD, 9.8 THK, 21.8 OD, 510M (10) ZF 7111M (TRFER CASE) (2.383) |
|
2004-2006 |
02 |
| 019 |
|
BRACKET, FUEL FEED EVAP EMIS RTN HOSE (*KIT1) |
|
2004-2006 |
|
| 020 |
15164938 |
CLIP, FUEL FEED EVAP EMIS RTN FRT PIPE (*KIT1) |
K2, 3 (L18, ML6) |
2004-2006 |
01 |
| K01 |
15164937 |
BRACKET, FUEL FEED EVAP EMIS RTN PIPE (INCLS 19, 20) |
K2, 3 (L18, ML6) |
2004-2006 |
01 |
