| Поз. | Номер | Описание | Применение | Номенклатура | Кол-во |
| 001 |
10361003 |
HARNESS, CHAS WRG (INCLS 2, 3, 15, 18) |
K159 (36) (JL4, Z55) |
2005-2006 |
01 |
| 002 |
01627989 |
RETAINER, AUTO LVL CONT AIR CMPR TUBE (PART OF 1, 3) (7.346) |
K159 (36) (Z55) |
2003-2006 |
06 |
| 003 |
88987900 |
TUBE, RR S/ABS AIR (INCLS 2) (PART OF 1) |
K159 (36) (Z55) |
2003-2006 |
01 |
| 004 |
11516872 |
BOLT-HEX M6X1X20, 11.5 THD, 17 OD, 6202M, 6280M (TRLR WRG HARN GND) |
|
2003-2006 |
01 |
| 005 |
11516872 |
BOLT-HEX M6X1X20, 11.5 THD, 17 OD, 6202M, 6280M (AUTO LVL CONT WIRE GND) |
|
2003-2006 |
01 |
| 006 |
15317329 |
CAP, TRLR WRG RCPT |
K1, 2, 3 |
2003-2006 |
01 |
| 007 |
|
HARNESS, BODY WRG (СМ. ГРУППУ 02.000 ЖГУТЫ ПРОВОДОВ/КУЗОВ ДЛЯ ДЕТАЛЬНОГО ПРОСМОТРА) |
|
2003-2006 |
|
| 008 |
93440521 |
COVER, BODY WRG HARN |
K159 (36) (JL4, UD7, Y91, Z55, Z75) |
2003-2006 |
01 |
| 009 |
10134407 |
RETAINER, BODY WRG HARN CVR (EBONY) (17.8 X 6.3 X 20.4MM) (NYLON) (ROUND PUSH-IN INCLS PUSH BUTTON LOCK) (1.272)
| K159 (36) (JL4, UD7, Y91, Z55, Z75) |
2003-2006 |
02 |
|
| 010 |
11516872 |
BOLT-HEX M6X1X20, 11.5 THD, 17 OD, 6202M, 6280M (RR LP WRG HARN GND) |
|
2003-2006 |
01 |
| 011 |
11588337 |
БОЛТ, HEX W/FL WA, M6X1X20, 9 THD, 17 OD, 6202M, GMW3200, TAP, DOG PT. (ELEK BRK CONT WRG HARN GND)
|
2003-2006 |
01 |
|
| 012 |
11609679 |
WASHER, FLAT, M8 (ELEK BRK CONT WRG HARN GND) |
|
2003-2006 |
01 |
| 013 |
11588337 |
БОЛТ, HEX W/FL WA, M6X1X20, 9 THD, 17 OD, 6202M, GMW3200, TAP, DOG PT. (CHAS FRT WRG HARN GND)
|
2003-2006 |
01 |
|
| 014 |
11609679 |
WASHER, FLAT, M8 (FUEL SDR WRG HARN GND) |
|
2003-2006 |
01 |
| 015 |
|
COVER, ELEK SUSP CONT MDL FIN (PART OF 1) |
|
2003-2006 |
|
| 016 |
11516885 |
SCREW, HFH W/FL WA, TAP, M8X1.25X20, 7THD, 17 O.D., TR PT, 6202M, PZOR (CHAS FRT WRG HARN CLIP) |
|
2003-2006 |
01 |
| 017 |
11609411 |
ГАЙКА, HEX W/CON WA, M6X1, 5.7 THK, 16 OD, 9, GMW3200 (CHAS RR WRG HARN J/BLK LEAD)
|
2003-2006 |
01 |
|
| 018 |
12177233 |
RELAY, AUTO LVL CONT (5-WAY MALE, BLACK, CODE 7233) (PART OF 1) (SHROUDED) (W/RESISTOR) (SPDT 280 MINI) (FOR 4-TERM APP CUT OFF CENTER TERM LABELED 87A) (9.277) (ACDelco #15-8721) |
K159 (36) (JL4, Z55) |
2003-2006 |
01 |
| 019 |
21011332 |
ГАЙКА, HEX STAMPED TY DF FLG 14 (CHAS FRT WRG HARN BRKT) (8.921) |
|
2003-2006 |
02 |
| 020 |
15045897 |
BRACKET, CHAS FRT WRG HARN |
K1, 2, 3 |
2003-2006 |
01 |
| 021 |
|
HARNESS, I/P WRG (СМ. ГРУППУ 02.000 ЖГУТЫ ПРОВОДОВ/ПРИБОРНАЯ ПАНЕЛЬ ДЛЯ ДЕТАЛЬНОГО ПРОСМОТРА) |
|
2003-2006 |
|
