| Поз. | Номер | Описание | Применение | Номенклатура | Кол-во |
| 001 |
15219565 |
GENERATOR, (ACDelco #15219565) |
CK2 (36) (K68) |
2005-2005 |
01 |
| 001 |
15263858 |
GENERATOR, (PROD 15200268 PHY ID Y9) (ACDelco #15263858) (DELCO SERIES DR44G, TYPE 100) |
CK1 (03-36-53) (KG3) |
2005-2006 |
01 |
| 001 |
15263859 |
GENERATOR, (ACDelco #15263859) (DELCO SERIES AD244, IR)
| K2 (36) (LQ4, L18, KG3) |
2005-2005 |
01 |
|
| 002 |
12555610 |
STUD, GEN P/S PUMP BRKT (M10X1.5X96) (1.060) |
CK2, 3 (L18) |
2001-2007 |
01 |
| 003 |
12570132 |
BRACKET, GEN P/S PUMP (INCLS 7) (INCLS SPACER) |
CK2, 3 (L18) |
2002-2007 |
01 |
| 004 |
11516744 |
BOLT-HFH, M10X1.5X110, 26 THD, 22.3 OD, 9.8, 7114M (GEN P/S PUMP BRKT) |
|
2001-2007 |
04 |
| 005 |
11514597 |
ГАЙКА, HFH, 10X1.5 THD, 9.8 THK, 21.8 OD, 510M (10) ZF 7111M (GEN P/S PUMP BRKT) (2.383) |
|
2001-2007 |
01 |
| 006 |
11516360 |
БОЛТ, HFH M10X1.2X90, 9.8, 7114M, 22.3 OD HDR PT (GEN) |
|
2001-2007 |
02 |
| 007 |
12550090 |
SPACER, GEN P/S PUMP BRKT (PART OF 3)
| CK2, 3 (L18) |
2001-2007 |
02 |
|
| 007 |
12550090 |
SPACER, GEN P/S PUMP BRKT (PART OF 3) (2.277)
| CK2, 3 (L18) |
2001-2007 |
02 |
|
