| Поз. | Номер | Описание | Применение | Номенклатура | Кол-во |
| 100 |
|
BLOCK, ENG |
|
2001-2007 |
|
| 400 |
12574833 |
PAN, OIL (INCLS 401, 402, 404) (INCLSGASKET, PLUG, SEAL) |
CK2, 3 (L18) |
2001-2007 |
01 |
| 401 |
11562588 |
PLUG, МАСЛЯНЫЙ ПОДДОН DRN (PART OF 400) (W/ SEAL) (EXC MAGNET)
| CK2, 3 (L18) |
2001-2007 |
01 |
|
| 402 |
03536966 |
SEAL, МАСЛЯНЫЙ ПОДДОН DRN PLUG (O RING) (PART OF 400) |
CK2, 3 (L18) |
2001-2007 |
01 |
| 403 |
11515758 |
БОЛТ, HFH, M8X1.25X30, 28THD, 18 O.D., MACH PT, 10.9, 7114M
|
2001-2007 |
12 |
|
| 404 |
12567777 |
GASKET, МАСЛЯНЫЙ ПОДДОН (PART OF 400) |
CK2, 3 (L18) |
2001-2007 |
01 |
| 405 |
11517996 |
ГАЙКА, HFH, M10X1.5, 11.2THK, 21.5 O.D., 7111M (CR/SHF OIL DFL) (ACDelco #11517996)
|
2001-2007 |
09 |
|
| 406 |
12590688 |
DEFLECTOR, CR/SHF OIL |
CK2, 3 (L18) |
2001-2007 |
01 |
| 407 |
12570590 |
TUBE, OIL LVL IND (INCLS 411) |
CK2, 3 (L18) |
2001-2007 |
01 |
| 408 |
11517031 |
ГАЙКА, HFH, M8X1.25, 9.4THK, 17.4 O.D., 10, TIN ZN (OIL LVL IND TUBE) |
|
2001-2007 |
01 |
| 409 |
12575123 |
INDICATOR, OIL LVL (INCLS 410) |
CK2, 3 (L18) |
2001-2007 |
01 |
| 410 |
24504091 |
SEAL, OIL LVL IND (O RING) (PART OF 409) (BLACK) (6.07MM ID, 1.78MM DIA) |
CK2, 3 (L18) |
2001-2007 |
01 |
| 411 |
24504091 |
SEAL, OIL LVL IND TUBE (O RING) (PART OF 407) (BLACK) (6.07MM ID, 1.78MM DIA) |
CK2, 3 (L18) |
2001-2007 |
01 |
| 413 |
11515756 |
БОЛТ, HFH, M8X1.25X20, 17THD, 18 O.D., 10.9, 7114M (O/PMP DRV)
|
2001-2007 |
01 |
|
| 414 |
12568356 |
DRIVE, O/PMP |
CK2, 3 (L18) |
2001-2007 |
01 |
| 420 |
03998289 |
SHAFT, O/PMP DRV |
CK2, 3 (L18) |
2001-2007 |
01 |
| 422 |
12562025 |
PUMP, OIL (W/SCRN) (INCLS 902-908) |
CK2, 3 (L18) |
2001-2007 |
01 |
| 423 |
12557507 |
БОЛТ, O/PMP (M10X1.5X60) |
CK2, 3 (L18) |
2001-2007 |
01 |
| 424 |
03764554 |
RETAINER, O/PMP DRV SHF |
CK2, 3 (L18) |
2001-2007 |
01 |
| 435 |
25324052 |
ФИЛЬТР, МАСЛЯНЫЙ (81MM LONG) (ACDelco #PF454)
| CK2, 3 (L18) |
2001-2007 |
01 |
|
| 435 |
89028862 |
ФИЛЬТР, МАСЛЯНЫЙ (81MM LONG) (ACDelco #PF454F) (DURAPACK) (BULK PKG, QTY 12) |
CK2, 3 (L18) |
2001-2007 |
01 |
| 435 |
89060467 |
ФИЛЬТР, МАСЛЯНЫЙ (81MM LONG) (ACDelco #PF454CL) (CLASSIC DESIGN) |
CK2, 3 (L18) |
2001-2007 |
01 |
| 435 |
89060499 |
ФИЛЬТР, МАСЛЯНЫЙ (81MM LONG) (ACDelco #PF454FCL) (CLASSIC DSGN DURAPK) (BULK PKG, QTY 12) |
CK2, 3 (L18) |
2001-2007 |
01 |
| 715 |
12603784 |
SWITCH, ENG OIL LVL IND (135.8X28.7) |
CK2, 3 (L18) |
2002-2007 |
01 |
| 900 |
25013765 |
VALVE, OIL FLTR BYPASS (ACDelco #25013765) |
CK2, 3 (L18) |
2001-2007 |
02 |
| 901 |
03853870 |
FITTING, OIL FLTR |
CK2, 3 (L18) |
2001-2007 |
01 |
| 902 |
|
SCREEN, O/PMP (PART OF 422) |
|
2001-2007 |
|
| 903 |
11508612 |
БОЛТ, HFH, M6X1X12, 10THD, 14.2 O.D., 9.8, PZOR (PART OF 422) |
|
2001-2007 |
05 |
| 904 |
10241110 |
COVER, O/PMP (PART OF 422) |
CK2, 3 (L18) |
2001-2007 |
01 |
| 905 |
03870399 |
ПРУЖИНА, OIL PRESS RLF VLV (PART OF 422) |
CK2, 3 (L18) |
2001-2007 |
01 |
| 906 |
|
VALVE, OIL PRESS RLF (PART OF 422) |
|
2001-2007 |
|
| 907 |
12551790 |
PIN, OIL PRESS RLF VLV SPR ST (PART OF 422) |
CK1 (L18) |
2001-2007 |
01 |
| 908 |
00473396 |
GASKET, O/PMP CVR (PART OF 422) |
CK2, 3 (L18) |
2001-2007 |
01 |
