| Поз. | Номер | Описание | Применение | Номенклатура | Кол-во |
| 001 |
20842414 |
SEAT, RR (EBONY) |
CK109 (06) (AM8, ARS, KA6, Z75, 194) |
2011-2013 |
01 |
| 001 |
20842415 |
SEAT, RR (CASHMERE) |
CK109 (06) (AM8, ARS, KA6, Z75, 394) |
2011-2013 |
01 |
| 002 |
25908031 |
COVER, R/SEAT BK (CASHMERE) |
CK1 (06) (AM8, KA6, Z75, 394) |
2009-2013 |
01 |
| 002 |
25931386 |
COVER, R/SEAT BK (TITANIUM) |
CK1, 2 (06) (AM8, KA6, KB6, 836) (EXC HP2) |
2009-2013 |
01 |
| 002 |
15865521 |
COVER, R/SEAT BK (EBONY) |
CK1, 2 (06) (AM8, 193) (EXC KB6) |
2009-2013 |
01 |
| 002 |
15865522 |
COVER, R/SEAT BK (CASHMERE) |
CK1, 2 (06) (AM8, 333) (EXC KB6) |
2009-2013 |
01 |
| 002 |
15865523 |
COVER, R/SEAT BK (TITANIUM) |
CK1, 2 (06) (AM8, 833) (EXC KB6) |
2009-2013 |
01 |
| 002 |
20895601 |
COVER, R/SEAT BK (EBONY) |
CK1 (06) (AM8, KA6, Z75, 194) |
2007-2013 |
01 |
| 002 |
25931384 |
COVER, R/SEAT BK (EBONY) |
CK1, 2 (06) (AM8, KA6, KB6, 196) |
2011-2013 |
01 |
| 002 |
25908031 |
COVER, R/SEAT BK (CASHMERE) |
CK109 (06) (AM8, ARS, KA6, Z75, 394) |
2009-2013 |
01 |
| 003 |
15291597 |
PAD, R/SEAT BK |
CK107, 109, 2 (06) (AM8, 193, 333, 833) |
2007-2013 |
01 |
| 004 |
11562382 |
BOLT, HFH, M10X1.5X130, 26 THD, 22.3 OD, 10.9, 7114M, MACH, MAT-PT (R/SEAT BK FRM) |
|
2007-2013 |
01 |
| 005 |
15289969 |
BRACKET, RR CTR SEAT BELT RETR |
CK1, 2 (06) (AM8) |
2007-2013 |
01 |
| 006 |
15279450 |
PROTECTOR, R/SEAT SHLDR BELT (BLACK) |
CK1, 2 (06) |
2007-2013 |
01 |
| 007 |
11570116 |
SCREW, PAN HD, M6X1X10, 10 THD, 12 OD, STL SAE J1237, S424, TAPTITE ITE (R/SEAT LAT FIN CVR) (8.913) |
|
2007-2013 |
14 |
| 008 |
|
COVER, R/SEAT H/RST SUPT (PART OF 9) |
|
2007-2013 |
|
| 009 |
20960662 |
RESTRAINT, R/SEAT HD (INCLS 8) (EBONY) |
CK109 (06) (AM8, KA6, Z75, 194) |
2011-2013 |
02 |
| 009 |
20960663 |
RESTRAINT, R/SEAT HD (INCLS 8) (CASHMERE) |
CK109 (06) (AM8, KA6, Z75, 394) |
2011-2013 |
02 |
| 010 |
11562383 |
BOLT, HFH, M12X1.75X30.5, 17 THD, 26.6 OD, 10.9 STL, GMW3359, W/ADH 6175M (R/SEAT LAT) |
|
2007-2013 |
03 |
| 011 |
15279353 |
GUIDE, R/SEAT H/RST (TITANIUM) (W/O BUTTON) |
CK1, 2, 3 (83I) |
2007-2013 |
02 |
| 011 |
25851751 |
GUIDE, R/SEAT H/RST (COCOA) (W/O BUTTON) |
CK1 (06-36) (41I) |
2008-2013 |
02 |
| 011 |
15279347 |
GUIDE, R/SEAT H/RST (EBONY) (W/BUTTON) |
CK1, 2 (06) (19I) |
2007-2013 |
02 |
| 011 |
20912677 |
GUIDE, R/SEAT H/RST (COCOA) (W/BUTTON) |
CK1 (06) (AM8, 41I) |
2009-2013 |
02 |
| 011 |
20912675 |
GUIDE, R/SEAT H/RST (CASHMERE) (W/BUTTON) |
CK1, 2 (06-36) (33I) |
2007-2013 |
02 |
| 011 |
20912675 |
GUIDE, R/SEAT H/RST (CASHMERE) (W/BUTTON) |
CK1, 2 (06-36) (39I) |
2009-2013 |
02 |
| 011 |
20912679 |
GUIDE, R/SEAT H/RST (EBONY) (W/O BUTTON) |
CK1, 2 (06) (AM8, 19I) |
2007-2013 |
02 |
| 011 |
20912680 |
GUIDE, R/SEAT H/RST (CASHMERE) (W/O BUTTON) |
CK1, 2 (06) (33I, 39I) |
2007-2013 |
02 |
| 011 |
20912676 |
GUIDE, R/SEAT H/RST (TITANIUM) (W/BUTTON) |
CK1, 2 (06) (83I) |
2007-2013 |
02 |
| 012 |
15279353 |
GUIDE, R/SEAT H/RST (TITANIUM) (W/O BUTTON) |
CK1, 2, 3 (83I) |
2007-2013 |
02 |
| 012 |
25851751 |
GUIDE, R/SEAT H/RST (COCOA) (W/O BUTTON) |
CK1 (06-36) (41I) |
2008-2013 |
02 |
| 012 |
15279347 |
GUIDE, R/SEAT H/RST (EBONY) (W/BUTTON) |
CK1, 2 (06) (19I) |
2007-2013 |
02 |
| 012 |
20912677 |
GUIDE, R/SEAT H/RST (COCOA) (W/BUTTON) |
CK1 (06) (AM8, 41I) |
2009-2013 |
02 |
| 012 |
20912675 |
GUIDE, R/SEAT H/RST (CASHMERE) (W/BUTTON) |
CK1, 2 (06-36) (33I) |
2007-2013 |
02 |
| 012 |
20912675 |
GUIDE, R/SEAT H/RST (CASHMERE) (W/BUTTON) |
CK1, 2 (06-36) (39I) |
2009-2013 |
02 |
| 012 |
20912679 |
GUIDE, R/SEAT H/RST (EBONY) (W/O BUTTON) |
CK1, 2 (06) (AM8, 19I) |
2007-2013 |
02 |
| 012 |
20912680 |
GUIDE, R/SEAT H/RST (CASHMERE) (W/O BUTTON) |
CK1, 2 (06) (33I, 39I) |
2007-2013 |
02 |
| 012 |
20912676 |
GUIDE, R/SEAT H/RST (TITANIUM) (W/BUTTON) |
CK1, 2 (06) (83I) |
2007-2013 |
02 |
| 013 |
15269762 |
FRAME, R/SEAT BK |
CK1, 2 (06) (AM8) |
2007-2013 |
01 |
| 014 |
15279408 |
PIN, R/SEAT H/RST ADJ ROD LAT (TITANIUM) |
CK1, 2 (06) (AM8, 83I) |
2007-2013 |
02 |
| 014 |
15279406 |
PIN, R/SEAT H/RST ADJ ROD LAT (EBONY) |
CK1, 2 (06) (AM8, 19I) |
2007-2013 |
02 |
| 014 |
15279407 |
PIN, R/SEAT H/RST ADJ ROD LAT (CASHMERE) |
CK1, 2 (06) (33I, 39I) |
2007-2013 |
02 |
| 015 |
15279471 |
COVER, R/SEAT A/RST SUPT FIN (TITANIUM) |
CK1, 2 (06) (AM8, 83I) |
2007-2013 |
01 |
| 015 |
15279469 |
COVER, R/SEAT A/RST SUPT FIN (EBONY) |
CK1, 2 (06) (AM8, 19I) |
2007-2013 |
01 |
| 015 |
15279470 |
COVER, R/SEAT A/RST SUPT FIN (CASHMERE) |
CK1, 2 (06) (AM8, 33I, 39I) |
2007-2013 |
01 |
| 016 |
11562378 |
BOLT, HFH, M10X1.5X30, 18 THD, 22.3 OD, 10.9, GMW3359, W/ADH GM6175M (R/SEAT LAT) |
|
2007-2013 |
06 |
| 017 |
15279616 |
COVER, R/SEAT BK HGE FIN (TITANIUM) (OUTBOARD, OUTER) (16.674) |
CK109, 2 (06) (AM8, 83I) |
2007-2013 |
01 |
| 017 |
15279626 |
COVER, R/SEAT BK HGE FIN (TITANIUM) (OUTBOARD, INNER) (16.674) |
CK109, 2 (06) (AM8, 83I) |
2007-2013 |
01 |
| 017 |
15279636 |
COVER, R/SEAT BK HGE FIN (TITANIUM) (INBOARD, OUTER) (16.674) |
CK109, 2 (06) (AM8, 83I) |
2007-2013 |
01 |
| 017 |
15279646 |
COVER, R/SEAT BK HGE FIN (TITANIUM) (INBOARD, INNER) (16.674) |
CK109, 2 (06) (AM8, 83I) |
2007-2013 |
01 |
| 017 |
15279614 |
COVER, R/SEAT BK HGE FIN (EBONY) (OUTBOARD, OUTER) (16.674) |
CK109, 2 (06) (AM8, 19I) |
2007-2013 |
01 |
| 017 |
15279634 |
COVER, R/SEAT BK HGE FIN (EBONY) (INBOARD, OUTER) (16.674) |
CK109, 2 (06) (AM8, 19I) |
2007-2013 |
01 |
| 017 |
15279615 |
COVER, R/SEAT BK HGE FIN (CASHMERE) (OUTBOARD, OUTER) (16.674) |
CK109, 2 (06) (AM8, 33I, 39I) |
2007-2013 |
01 |
| 017 |
15279625 |
COVER, R/SEAT BK HGE FIN (CASHMERE) (OUTBOARD, INNER) (16.674) |
CK109, 2 (06) (AM8, 33I, 39I) |
2007-2013 |
01 |
| 017 |
15279635 |
COVER, R/SEAT BK HGE FIN (CASHMERE) (INBOARD, OUTER) (16.674) |
CK109, 2 (06) (AM8, 33I, 39I) |
2007-2013 |
01 |
| 017 |
15279644 |
COVER, R/SEAT BK HGE FIN (EBONY) (INBOARD, INNER) (16.674) |
CK109, 2 (06) (AM8, 19I) |
2007-2013 |
01 |
| 017 |
15279645 |
COVER, R/SEAT BK HGE FIN (CASHMERE) (INBOARD, INNER) (16.674) |
CK109, 2 (06) (AM8, 33I, 39I) |
2007-2013 |
01 |
| 017 |
15279624 |
COVER, R/SEAT BK HGE FIN (EBONY) (OUTBOARD, INNER) (16.674) |
CK109, 2 (06) (AM8, 19I) |
2007-2013 |
01 |
| 018 |
19121592 |
BELT KIT, R/SEAT (BKL SI) (TITANIUM) (BKL/BKL) |
CK1, 2 (06) (AM8, 83I) |
2007-2013 |
01 |
| 018 |
19121591 |
BELT KIT, R/SEAT (BKL SI) (CASHMERE) (BKL/BKL) |
CK1, 2 (06) (AM8, 33I, 39I) |
2007-2013 |
01 |
| 018 |
19121589 |
BELT KIT, R/SEAT (BKL SI) (EBONY) (BKL/BKL) |
CK1, 2 (06) (AM8, 19I) |
2007-2013 |
01 |
| 019 |
15269764 |
FRAME, R/SEAT CUSH |
CK1, 2 (06) (AM8) (EXC HP2) |
2007-2013 |
01 |
| 020 |
15275890 |
LATCH, R/SEAT RSR (O/B) |
CK109, 2 (06) (AM8) |
2007-2013 |
01 |
| 020 |
15275891 |
LATCH, R/SEAT RSR (INBOARD) |
CK109, 2 (06) (AM8) |
2007-2013 |
01 |
| 021 |
25896455 |
LATCH, R/SEAT BK (OUTBOARD) |
CK1, 2 (06) (AM8) (EXC HP2) |
2007-2013 |
01 |
| 021 |
25896456 |
LATCH, R/SEAT BK (INBOARD) |
CK1, 2 (06) (AM8, KA6) (EXC HP2) |
2008-2013 |
01 |
| 022 |
15279616 |
COVER, R/SEAT BK HGE FIN (INCLS 49) (TITANIUM) (OUTBOARD, OUTER) (16.674) |
CK109, 2 (06) (AM8, 83I) |
2007-2013 |
01 |
| 022 |
15279626 |
COVER, R/SEAT BK HGE FIN (INCLS 49) (TITANIUM) (OUTBOARD, INNER) (16.674) |
CK109, 2 (06) (AM8, 83I) |
2007-2013 |
01 |
| 022 |
15279636 |
COVER, R/SEAT BK HGE FIN (INCLS 49) (TITANIUM) (INBOARD, OUTER) (16.674) |
CK109, 2 (06) (AM8, 83I) |
2007-2013 |
01 |
| 022 |
15279646 |
COVER, R/SEAT BK HGE FIN (INCLS 49) (TITANIUM) (INBOARD, INNER) (16.674) |
CK109, 2 (06) (AM8, 83I) |
2007-2013 |
01 |
| 022 |
15279614 |
COVER, R/SEAT BK HGE FIN (INCLS 49) (EBONY) (OUTBOARD, OUTER) (16.674) |
CK109, 2 (06) (AM8, 19I) |
2007-2013 |
01 |
| 022 |
15279634 |
COVER, R/SEAT BK HGE FIN (INCLS 49) (EBONY) (INBOARD, OUTER) (16.674) |
CK109, 2 (06) (AM8, 19I) |
2007-2013 |
01 |
| 022 |
15279615 |
COVER, R/SEAT BK HGE FIN (INCLS 49) (CASHMERE) (OUTBOARD, OUTER) (16.674) |
CK109, 2 (06) (AM8, 33I, 39I) |
2007-2013 |
01 |
| 022 |
15279625 |
COVER, R/SEAT BK HGE FIN (INCLS 49) (CASHMERE) (OUTBOARD, INNER) (16.674) |
CK109, 2 (06) (AM8, 33I, 39I) |
2007-2013 |
01 |
| 022 |
15279635 |
COVER, R/SEAT BK HGE FIN (INCLS 49) (CASHMERE) (INBOARD, OUTER) (16.674) |
CK109, 2 (06) (AM8, 33I, 39I) |
2007-2013 |
01 |
| 022 |
15279644 |
COVER, R/SEAT BK HGE FIN (INCLS 49) (EBONY) (INBOARD, INNER) (16.674) |
CK109, 2 (06) (AM8, 19I) |
2007-2013 |
01 |
| 022 |
15279645 |
COVER, R/SEAT BK HGE FIN (INCLS 49) (CASHMERE) (INBOARD, INNER) (16.674) |
CK109, 2 (06) (AM8, 33I, 39I) |
2007-2013 |
01 |
| 022 |
15279624 |
COVER, R/SEAT BK HGE FIN (INCLS 49) (EBONY) (OUTBOARD, INNER) (16.674) |
CK109, 2 (06) (AM8, 19I) |
2007-2013 |
01 |
| 023 |
|
RETAINER, R/SEAT ADJR RLR (PART OF 24) |
|
2007-2013 |
|
| 024 |
15279416 |
HANDLE, R/SEAT RECL (INCLS 23) (TITANIUM) |
CK1, 2 (06) (83I) |
2007-2013 |
01 |
| 024 |
15279414 |
HANDLE, R/SEAT RECL (INCLS 23) (EBONY) |
CK1, 2 (06) (19I) |
2007-2013 |
01 |
| 024 |
15279415 |
HANDLE, R/SEAT RECL (INCLS 23) (CASHMERE) |
CK1, 2 (06) (33I) |
2007-2013 |
01 |
| 024 |
25858332 |
HANDLE, R/SEAT RECL (INCLS 23) (COCOA) |
CK1 (06) (AM8, 41I) |
2009-2013 |
01 |
| 024 |
15279415 |
HANDLE, R/SEAT RECL (INCLS 23) (CASHMERE) |
CK1 (06) (39I) |
2007-2013 |
01 |
| 025 |
|
CABLE, R/SEAT LAT |
|
2007-2013 |
|
| 026 |
|
CABLE, R/SEAT LAT |
|
2007-2013 |
|
| 027 |
|
CABLE, R/SEAT LAT |
|
2007-2013 |
|
| 028 |
15942228 |
CABLE, R/SEAT BK LAT |
CK1, 2 (06) (AM8, ARS) |
2007-2013 |
01 |
| 028 |
15942229 |
CABLE, R/SEAT BK LAT |
CK1, 2 (06) (AM8, ARS) |
2007-2013 |
02 |
| 029 |
15279681 |
COVER, R/SEAT RSR FIN (TITANIUM) (REAR) |
CK109, 2 (06) (AM8, 83I) |
2007-2013 |
01 |
| 029 |
15824844 |
COVER, R/SEAT RSR FIN (TITANIUM) (FRONT) |
CK109, 2 (06) (AM8, 83I) |
2007-2013 |
01 |
| 029 |
15279679 |
COVER, R/SEAT RSR FIN (EBONY) (REAR) |
CK109, 2 (06) (AM8, 19I) |
2009-2013 |
01 |
| 029 |
15824842 |
COVER, R/SEAT RSR FIN (EBONY) (FRONT) |
CK109, 2 (06) (AM8, 19I) |
2007-2013 |
01 |
| 029 |
15279680 |
COVER, R/SEAT RSR FIN (CASHMERE) (REAR) |
CK109, 2 (06) (AM8, 33I, 39I) |
2009-2013 |
01 |
| 029 |
15824843 |
COVER, R/SEAT RSR FIN (CASHMERE) (FRONT) |
CK109, 2 (06) (AM8, 33I, 39I) |
2007-2013 |
01 |
| 030 |
22741878 |
RISER, R/SEAT |
CK109, 2 (06) (AM8) |
2007-2013 |
01 |
| 031 |
|
RETAINER, R/SEAT FLR FIL T/PNL (PART OF 32) |
|
2007-2013 |
|
| 032 |
15279681 |
COVER, R/SEAT RSR FIN (INCLS 31) (TITANIUM) (REAR) |
CK109, 2 (06) (AM8, 83I) |
2007-2013 |
01 |
| 032 |
15824844 |
COVER, R/SEAT RSR FIN (INCLS 31) (TITANIUM) (FRONT) |
CK109, 2 (06) (AM8, 83I) |
2007-2013 |
01 |
| 032 |
15279679 |
COVER, R/SEAT RSR FIN (INCLS 31) (EBONY) (REAR) |
CK109, 2 (06) (AM8, 19I) |
2009-2013 |
01 |
| 032 |
15824842 |
COVER, R/SEAT RSR FIN (INCLS 31) (EBONY) (FRONT) |
CK109, 2 (06) (AM8, 19I) |
2007-2013 |
01 |
| 032 |
15279680 |
COVER, R/SEAT RSR FIN (INCLS 31) (CASHMERE) (REAR) |
CK109, 2 (06) (AM8, 33I, 39I) |
2009-2013 |
01 |
| 032 |
15824843 |
COVER, R/SEAT RSR FIN (INCLS 31) (CASHMERE) (FRONT) |
CK109, 2 (06) (AM8, 33I, 39I) |
2007-2013 |
01 |
| 033 |
15291599 |
PAD, R/SEAT CUSH |
CK1, 2 (06) (AM8) (EXC HP2) |
2007-2013 |
01 |
| 034 |
11570032 |
PIN, R/SEAT HGE (6 X 1 X 98) |
CK1, 2 (06) |
2007-2013 |
01 |
| 035 |
15843763 |
HARNESS, ST RECL WRG (ELEMENT) |
CK107, 109 (06) (AM8, ARS, KA6, Z75) |
2009-2013 |
01 |
| 036 |
22772255 |
PANEL, R/SEAT CUSH TR (EBONY) |
CK109, 2 (06) (AM8, 19I) |
2007-2013 |
01 |
| 036 |
22772256 |
PANEL, R/SEAT CUSH TR (CASHMERE) |
CK109, 2 (06) (AM8, 33I, 39I) |
2010-2013 |
01 |
| 036 |
22772257 |
PANEL, R/SEAT CUSH TR (TITANIUM) |
CK109, 2 (06) (AM8, 83I) |
2012-2013 |
01 |
| 037 |
20933029 |
MODULE, R/SEAT HTR CONT |
CK1 (06) (AM8) |
2009-2013 |
01 |
| 038 |
20792750 |
HEATER, R/SEAT CUSH |
CK1, 2 (06) (KA6) |
2007-2013 |
01 |
| 039 |
15275905 |
STRUT, R/SEAT (USED ON 40% SIDE) |
CK1, 2 (06) (AM8) |
2007-2013 |
02 |
| 039 |
15930099 |
STRUT, R/SEAT (USED ON 60% SIDE) |
CK1, 2 (06) (AM8) |
2007-2013 |
01 |
| 040 |
15275900 |
SPRING, R/SEAT RECL (TUMBLE) |
CK1, 2 (06) (AM8) (EXC HP2) |
2007-2013 |
02 |
| 040 |
15275902 |
SPRING, R/SEAT RECL (MANDREL) |
CK1, 2 (06) (AM8) |
2007-2013 |
02 |
| 041 |
15275900 |
SPRING, R/SEAT RECL (TUMBLE) |
CK1, 2 (06) (AM8) (EXC HP2) |
2007-2013 |
02 |
| 041 |
15275902 |
SPRING, R/SEAT RECL (MANDREL) |
CK1, 2 (06) (AM8) |
2007-2013 |
02 |
| 042 |
11562380 |
BUSHING, R/SEAT HGE |
CK1, 2 (06) (AM8) |
2007-2013 |
08 |
| 043 |
15279666 |
COVER, R/SEAT HGE LWR FIN (TITANIUM) (PIVOT INBOARD) (16.674) |
CK109, 2 (06) (AM8, 83I) |
2007-2013 |
01 |
| 043 |
15279664 |
COVER, R/SEAT HGE LWR FIN (EBONY) (PIVOT INBOARD) (16.674) |
CK109, 2 (06) (AM8, 19I) |
2007-2013 |
01 |
| 043 |
15279665 |
COVER, R/SEAT HGE LWR FIN (CASHMERE) (PIVOT INBOARD) (16.674) |
CK109, 2 (06) (AM8, 33I, 39I) |
2007-2013 |
01 |
| 044 |
15269778 |
BRACKET, R/SEAT |
CK109, 2 (06) (AM8) |
2007-2013 |
01 |
| 045 |
11562381 |
BOLT, R/SEAT BK LAT PIV (M12X1.75X40) |
CK1, 2 (06) (AM8) |
2007-2013 |
02 |
| 046 |
15279671 |
COVER, R/SEAT HGE LWR FIN (TITANIUM) (PIVOT INBOARD) (16.674) |
CK109, 2 (06) (AM8, 83I) |
2007-2013 |
01 |
| 046 |
15279669 |
COVER, R/SEAT HGE LWR FIN (EBONY) (PIVOT INBOARD) (16.674) |
CK109, 2 (06) (AM8, 19I) |
2007-2013 |
01 |
| 046 |
15279670 |
COVER, R/SEAT HGE LWR FIN (CASHMERE) (PIVOT INBOARD) (16.674) |
CK109, 2 (06) (AM8, 33I, 39I) |
2007-2013 |
01 |
| 047 |
25931390 |
COVER, R/SEAT CUSH (EBONY) |
CK1, 2 (06) (AM8, KB6, 196) (EXC HP2) |
2009-2013 |
01 |
| 047 |
25931391 |
COVER, R/SEAT CUSH (CASHMERE) |
CK1, 2 (06) (AM8, KB6, 336) (EXC HP2) |
2009-2013 |
01 |
| 047 |
25931392 |
COVER, R/SEAT CUSH (TITANIUM) |
CK1, 2 (06) (AM8, KA6, KB6, 836) (EXC HP2) |
2009-2013 |
01 |
| 047 |
15865529 |
COVER, R/SEAT CUSH (EBONY) |
CK1, 2 (06) (AM8, 193) (EXC HP2, KB6) |
2009-2013 |
01 |
| 047 |
15865530 |
COVER, R/SEAT CUSH (CASHMERE) |
CK1, 2 (06) (AM8, 333) (EXC HP2, KB6) |
2009-2013 |
01 |
| 047 |
15865531 |
COVER, R/SEAT CUSH (TITANIUM) |
CK1, 2 (06) (AM8, 833) (EXC HP2, KB6) |
2009-2013 |
01 |
| 047 |
25899567 |
COVER, R/SEAT CUSH (EBONY) |
CK1 (06) (AM8, KA6, Z75, 194) (EXC HP2) |
2008-2013 |
01 |
| 047 |
20905440 |
COVER, R/SEAT CUSH (CASHMERE) |
CK1 (06) (AM8, KA6, Z75, 394) (EXC HP2) |
2009-2013 |
01 |
| 048 |
15279616 |
COVER, R/SEAT BK HGE FIN (TITANIUM) (OUTBOARD, OUTER) (16.674) |
CK109, 2 (06) (AM8, 83I) |
2007-2013 |
01 |
| 048 |
15279626 |
COVER, R/SEAT BK HGE FIN (TITANIUM) (OUTBOARD, INNER) (16.674) |
CK109, 2 (06) (AM8, 83I) |
2007-2013 |
01 |
| 048 |
15279636 |
COVER, R/SEAT BK HGE FIN (TITANIUM) (INBOARD, OUTER) (16.674) |
CK109, 2 (06) (AM8, 83I) |
2007-2013 |
01 |
| 048 |
15279646 |
COVER, R/SEAT BK HGE FIN (TITANIUM) (INBOARD, INNER) (16.674) |
CK109, 2 (06) (AM8, 83I) |
2007-2013 |
01 |
| 048 |
15279614 |
COVER, R/SEAT BK HGE FIN (EBONY) (OUTBOARD, OUTER) (16.674) |
CK109, 2 (06) (AM8, 19I) |
2007-2013 |
01 |
| 048 |
15279634 |
COVER, R/SEAT BK HGE FIN (EBONY) (INBOARD, OUTER) (16.674) |
CK109, 2 (06) (AM8, 19I) |
2007-2013 |
01 |
| 048 |
15279615 |
COVER, R/SEAT BK HGE FIN (CASHMERE) (OUTBOARD, OUTER) (16.674) |
CK109, 2 (06) (AM8, 33I, 39I) |
2007-2013 |
01 |
| 048 |
15279625 |
COVER, R/SEAT BK HGE FIN (CASHMERE) (OUTBOARD, INNER) (16.674) |
CK109, 2 (06) (AM8, 33I, 39I) |
2007-2013 |
01 |
| 048 |
15279635 |
COVER, R/SEAT BK HGE FIN (CASHMERE) (INBOARD, OUTER) (16.674) |
CK109, 2 (06) (AM8, 33I, 39I) |
2007-2013 |
01 |
| 048 |
15279644 |
COVER, R/SEAT BK HGE FIN (EBONY) (INBOARD, INNER) (16.674) |
CK109, 2 (06) (AM8, 19I) |
2007-2013 |
01 |
| 048 |
15279645 |
COVER, R/SEAT BK HGE FIN (CASHMERE) (INBOARD, INNER) (16.674) |
CK109, 2 (06) (AM8, 33I, 39I) |
2007-2013 |
01 |
| 048 |
15279624 |
COVER, R/SEAT BK HGE FIN (EBONY) (OUTBOARD, INNER) (16.674) |
CK109, 2 (06) (AM8, 19I) |
2007-2013 |
01 |
| 049 |
|
RETAINER, R/SEAT FLR FIL T/PNL (PART OF 22) |
|
2007-2013 |
|
| 050 |
11562376 |
SCREW, PAN HD, M12X1.75X55, 42 THD, 27 OD, 10.9, S424, W/ADH GM6175M (R/SEAT LAT) |
|
2007-2013 |
02 |
| 051 |
25896455 |
LATCH, R/SEAT BK (OUTBOARD) |
CK1, 2 (06) (AM8) (EXC HP2) |
2007-2013 |
01 |
| 051 |
25896456 |
LATCH, R/SEAT BK (INBOARD) |
CK1, 2 (06) (AM8, KA6) (EXC HP2) |
2008-2013 |
01 |
| 052 |
11562377 |
BOLT, HFH, M10X1.5X55, 43.45 THD, 22.3 OD, 10.9, GMW3359, W/ADH GM6175M (R/SEAT LAT) |
|
2007-2013 |
02 |
| 053 |
20963265 |
KNOB, R/SEAT LAT (EBONY) (INNER) |
CK1, 2 (06) |
2011-2013 |
02 |
| 054 |
11562384 |
NUT, HFH, M4X.7 THD, 4.75 THK, 10.5 OD, GM510M (9)STL, GM4435M-CODE A (R/SEAT FLR FIL T/PNL) |
|
2007-2013 |
02 |
| 055 |
15279616 |
COVER, R/SEAT BK HGE FIN (TITANIUM) (OUTBOARD, OUTER) (16.674) |
CK109, 2 (06) (AM8, 83I) |
2007-2013 |
01 |
| 055 |
15279626 |
COVER, R/SEAT BK HGE FIN (TITANIUM) (OUTBOARD, INNER) (16.674) |
CK109, 2 (06) (AM8, 83I) |
2007-2013 |
01 |
| 055 |
15279636 |
COVER, R/SEAT BK HGE FIN (TITANIUM) (INBOARD, OUTER) (16.674) |
CK109, 2 (06) (AM8, 83I) |
2007-2013 |
01 |
| 055 |
15279646 |
COVER, R/SEAT BK HGE FIN (TITANIUM) (INBOARD, INNER) (16.674) |
CK109, 2 (06) (AM8, 83I) |
2007-2013 |
01 |
| 055 |
15279614 |
COVER, R/SEAT BK HGE FIN (EBONY) (OUTBOARD, OUTER) (16.674) |
CK109, 2 (06) (AM8, 19I) |
2007-2013 |
01 |
| 055 |
15279634 |
COVER, R/SEAT BK HGE FIN (EBONY) (INBOARD, OUTER) (16.674) |
CK109, 2 (06) (AM8, 19I) |
2007-2013 |
01 |
| 055 |
15279615 |
COVER, R/SEAT BK HGE FIN (CASHMERE) (OUTBOARD, OUTER) (16.674) |
CK109, 2 (06) (AM8, 33I, 39I) |
2007-2013 |
01 |
| 055 |
15279625 |
COVER, R/SEAT BK HGE FIN (CASHMERE) (OUTBOARD, INNER) (16.674) |
CK109, 2 (06) (AM8, 33I, 39I) |
2007-2013 |
01 |
| 055 |
15279635 |
COVER, R/SEAT BK HGE FIN (CASHMERE) (INBOARD, OUTER) (16.674) |
CK109, 2 (06) (AM8, 33I, 39I) |
2007-2013 |
01 |
| 055 |
15279644 |
COVER, R/SEAT BK HGE FIN (EBONY) (INBOARD, INNER) (16.674) |
CK109, 2 (06) (AM8, 19I) |
2007-2013 |
01 |
| 055 |
15279645 |
COVER, R/SEAT BK HGE FIN (CASHMERE) (INBOARD, INNER) (16.674) |
CK109, 2 (06) (AM8, 33I, 39I) |
2007-2013 |
01 |
| 055 |
15279624 |
COVER, R/SEAT BK HGE FIN (EBONY) (OUTBOARD, INNER) (16.674) |
CK109, 2 (06) (AM8, 19I) |
2007-2013 |
01 |
| 056 |
15275854 |
ARMREST, R/SEAT (EBONY) |
CK1, 2 (06) (AM8, Z75, Z88, 194, 197) |
2008-2013 |
01 |
| 056 |
15865495 |
ARMREST, R/SEAT (TITANIUM) |
CK1, 2 (06) (AM8, 833, 836) |
2007-2013 |
01 |
| 056 |
15865493 |
ARMREST, R/SEAT (EBONY) |
CK1, 2 (06) (AM8, 196, 846) |
2009-2013 |
01 |
| 056 |
15865493 |
ARMREST, R/SEAT (EBONY) |
CK1, 2 (06) (AM8, 193) |
2009-2013 |
01 |
| 056 |
15865494 |
ARMREST, R/SEAT (CASHMERE) |
CK1, 2 (06) (AM8, 333, 336) |
2009-2013 |
01 |
| 056 |
15275855 |
ARMREST, R/SEAT (CASHMERE) |
CK1, 2 (06) (AM8, KA6, Z75, 394) (EXC HP2) |
2009-2013 |
01 |
| 057 |
15275890 |
LATCH, R/SEAT RSR (O/B) |
CK109, 2 (06) (AM8) |
2007-2013 |
01 |
| 057 |
15275891 |
LATCH, R/SEAT RSR (INBOARD) |
CK109, 2 (06) (AM8) |
2007-2013 |
01 |
| 057 |
15275892 |
LATCH, R/SEAT RSR (RH SEAT I/B O/B) |
CK109, 2 (06) (AM8) |
2007-2013 |
02 |
| 058 |
11562386 |
BOLT, HFH, M8X1.25X24, 22.5 THD, 18 OD, GM6202M, STL, GM4435M.CODE G, TAPTITE (R/SEAT A/RST) |
|
2007-2013 |
AR |
| 059 |
19151106 |
BELT KIT, R/SEAT CTR (RETR SI) (TITANIUM) |
CK1, 2 (06) (AM8, 83I) |
2007-2013 |
01 |
| 059 |
19151105 |
BELT KIT, R/SEAT CTR (RETR SI) (CASHMERE) |
CK1, 2 (06) (AM8, 33I, 39I) |
2007-2013 |
01 |
| 059 |
19151104 |
BELT KIT, R/SEAT CTR (RETR SI) (EBONY) |
CK109, 2 (06) (AM8, 19I) |
2009-2013 |
01 |
| 060 |
15824751 |
ACTUATOR, R/SEAT RECL (INCLS CABLE) |
CK1, 2 (06) (AM8, ARS) |
2007-2013 |
01 |
| 061 |
25784330 |
RETAINER, R/SEAT RSR FIN CVR |
CK1, 2 (06) |
2007-2013 |
04 |
| 063 |
25784330 |
RETAINER, R/SEAT RSR FIN CVR |
CK1, 2 (06) |
2007-2013 |
04 |
| 064 |
11570031 |
PIN, R/SEAT HGE (6 X 1 X 78) |
CK1, 2 (06) |
2007-2013 |
01 |
| 064 |
11570032 |
PIN, R/SEAT HGE (6 X 1 X 98) |
CK1, 2 (06) |
2007-2013 |
01 |
