| Поз. | Номер | Описание | Применение | Номенклатура | Кол-во |
| 002 |
|
WASHER, S/GR RACK THR (PART OF 1) |
|
2009-2013 |
|
| 004 |
11516074 |
NUT, STRG LNKG OTR TIE ROD (PART OF 5) (HEX M14X2X13) (8.917) |
CK1, 2, 3 |
2008-2013 |
02 |
| 007 |
11570615 |
CLAMP, HOSE SPRINGBAND, 26 NOMINAL DIA, 15 THK, STL, ROBO (PART OF 1, 3, 8) |
|
2008-2013 |
02 |
| 010 |
11569910 |
BOLT, P/S ASST MOT (PART OF 1, 11) (M8X1.25X25, 20THD) |
CK1 (HP2) |
2008-2013 |
02 |
| 015 |
|
HARNESS KIT, P/S WRG (PART OF 1, 11) |
|
2009-2013 |
|
| 016 |
12355066 |
STRAP, PLASTIC ADJ TIE (215MM LG) (PART OF 1, 11) (8.965) (ACDelco #16TS825) |
|
2008-2013 |
03 |
