| Поз. | Номер | Описание | Применение | Номенклатура | Кол-во |
| 001 |
22896184 |
HARNESS, CHAS WRG (INCLS 2, 3) |
CK109 (06) (G69, Z55, Z95, Z75) (EXC UFT) |
2012-2013 |
01 |
| 001 |
22970334 |
HARNESS, CHAS WRG (INCLS 2, 3) |
CK109 (06) (G69, UFT, Z55, Z95, Z75) (EXC BRS) |
2012-2013 |
01 |
| 001 |
22970336 |
HARNESS, CHAS WRG (INCLS 2, 3) |
CK109 (06) (BRS, G69, UFT, Z55, Z95, Z75) |
2012-2012 |
01 |
| 004 |
11588337 |
BOLT, HEX W/FL WA, M6X1X20, 9 THD, 17 OD, 6202M, GMW3200, TAP, DOG PT. (CHAS WRG) |
|
2007-2013 |
01 |
| 005 |
11588337 |
BOLT, HEX W/FL WA, M6X1X20, 9 THD, 17 OD, 6202M, GMW3200, TAP, DOG PT. (F/TNK FIL PIPE GND) |
|
2007-2013 |
01 |
| 006 |
11588337 |
BOLT, HEX W/FL WA, M6X1X20, 9 THD, 17 OD, 6202M, GMW3200, TAP, DOG PT. (TRLR WRG HARN GND) |
|
2007-2013 |
02 |
| 007 |
|
HARNESS, I/P WRG (SEE GROUP 02.000 WIRING HARNESS/INSTRUMENT PANEL FOR DETAILED ILLUSTRATED VIEW) |
|
2007-2013 |
|
| 008 |
21011332 |
NUT, HEX STAMPED TY DF FLG 14 (CHAS FRT WRG HARN BRKT) (8.921) |
|
2007-2013 |
02 |
| 009 |
15045897 |
BRACKET, CHAS FRT WRG HARN |
CK1, 2, 3 |
2007-2013 |
01 |
