(TC16-387) - 2008-2009 CK1,2(06-36) СИДЕНЬЕ ВОДИТЕЛЯ/BUCKET (AN3, EXC VENTED/HEATED HNE,KB6) CADILLAC - ESCALADE ESV (AWD) 2009

Поз.НомерОписаниеПрименениеНоменклатураКол-во
001 25865177 SEAT, DRVR (EBONY) CK1 (06-36) (AN3, Z75, 194) (EXC KB6) 2009-2009 01
001 25865474 SEAT, DRVR (EBONY) CK1 (06-36) (AN3, Y91, Z88, 194) (EXC KB6) 2009-2009 01
001 25865475 SEAT, DRVR (CASHMERE) CK1 (06-36) (AN3, Y91, Z88, 394) (EXC KB6) 2009-2009 01
001 25907678 SEAT, DRVR (CASHMERE) CK1 (06-36) (AL0, AN3, Z75, 394) (EXC KB6) 2009-2009 01
002 COVER, D/SEAT H/RST (PART OF 3) 2008-2009
003 15865481 RESTRAINT, D/SEAT HD (INCLS 2) (EBONY) CK1, 2 (06-36) (AN3, 193, 223, 843) 2007-2009 01
003 15865481 RESTRAINT, D/SEAT HD (INCLS 2) (EBONY) CK1, 2 (06-36) (AN3, 196, 843, 846) 2009-2009 01
003 15865482 RESTRAINT, D/SEAT HD (INCLS 2) (CASHMERE) CK1, 2 (06-36) (AN3, 313, 333) 2007-2009 01
003 15865482 RESTRAINT, D/SEAT HD (INCLS 2) (CASHMERE) CK1, 2 (06-36) (AN3, 336) 2009-2009 01
003 15865483 RESTRAINT, D/SEAT HD (INCLS 2) (TITANIUM) CK1, 2 (06-36) (AN3, 833, 836) 2007-2009 01
004 15827115 COVER, D/SEAT BK CUSH (EBONY) CK1 (06) (AL0, AN3, Y91, Z88, 194) (EXC KB6) 2009-2009 01
004 15827116 COVER, D/SEAT BK CUSH (CASHMERE) CK1 (06) (AN3, Y91, Z88, 394) (EXC KB6) 2009-2009 01
004 15865828 COVER, D/SEAT BK CUSH (EBONY) CK1, 2 (06-36) (AN3, 193) 2007-2009 01
004 15865829 COVER, D/SEAT BK CUSH (CASHMERE) CK1, 2 (06-36) (AN3, 313, 333) 2007-2009 01
004 15865830 COVER, D/SEAT BK CUSH (TITANIUM) CK1, 2 (06-36) (AN3, 833) 2007-2009 01
004 15923998 COVER, D/SEAT BK CUSH (EBONY) CK1, 2 (06-36) (AN3, 843) 2007-2009 01
004 25899517 COVER, D/SEAT BK CUSH (EBONY) CK1 (06-36) (AN3, Z75, 194) (EXC KB6) 2007-2009 01
004 25907742 COVER, D/SEAT BK CUSH (CASHMERE) CK1 (06-36) (AL0, AN3, Z75, 394) (EXC KB6) 2009-2009 01
005 15243902 PAD, D/SEAT BK CUSH CK1, 2, 3 (EXC KB6, HNE, HP2) 2007-2009 01
006 15279347 GUIDE, F/SEAT BK H/RST ADJ ROD (EBONY) (W/BUTTON) CK1, 2 (06-36) (19I, 22I, 84I) 2007-2009 02
006 15279348 GUIDE, F/SEAT BK H/RST ADJ ROD (CASHMERE) (W/BUTTON) CK1, 2, 3 (31I, 33I, 39I) 2007-2009 02
006 15279349 GUIDE, F/SEAT BK H/RST ADJ ROD (TITANIUM) (W/BUTTON) CK1, 2, 3 (83I, 84I) 2007-2009 02
007 15279351 GUIDE, F/SEAT BK H/RST ADJ ROD (EBONY) (W/O BUTTON) CK1, 2, 3 (19I, 22I, 84I) 2007-2009 02
007 15279352 GUIDE, F/SEAT BK H/RST ADJ ROD (CASHMERE) (W/O BUTTON) CK1, 2, 3 (31I, 33I, 39I) 2007-2009 02
007 15279353 GUIDE, F/SEAT BK H/RST ADJ ROD (TITANIUM) (W/O BUTTON) CK1, 2, 3 (83I, 84I) 2007-2009 02
008 25808717 FRAME, D/SEAT BK CUSH (INCLS 9, 15, 16, 43-45) (INCLS LUMBAR SUPPORT, RECLINER, SENSOR MOTOR) CK1, 2, 3 (AN3) (EXC KB6, HNE) 2007-2009 01
010 15827133 RING, F/SEAT BK CUSH CVR HOG CK1, 2, 3 2007-2009 02
011 15232706 PANEL, D/SEAT BK CUSH FIN (EBONY) CK1 (06-36) (AN3, Z75, 194) (EXC KB6) 2007-2009 01
011 15232706 PANEL, D/SEAT BK CUSH FIN (EBONY) CK1, 2 (06-36) (AN3, Y91, Z88, 194) (EXC KB6) 2007-2009 01
011 15933726 PANEL, D/SEAT BK CUSH FIN (INCLS MAP POCKET) (EBONY) (WHEN REPL TRIM WRAP PANELS, REPLACE BOTH DRVR PASS PANELS) CK1, 2 (06-36) (AN3, 193, 843) 2007-2009 01
011 15933727 PANEL, D/SEAT BK CUSH FIN (CASHMERE) (WHEN REPL.TRIM WRAP PANELS REPLACE BOTH DR PASS PANELS) CK1, 2, 3 (AN3, 313, 333) 2007-2009 01
