| Поз. | Номер | Описание | Применение | Номенклатура | Кол-во |
| 001 |
15257724 |
COVER, D/SEAT SHLDR BELT GDE TR (GRAY)
| CK1, 2 (06) (19I, 83I, 84I) |
2007-2008 |
01 |
|
| 001 |
15257724 |
COVER, P/SEAT SHLDR BELT GDE TR (GRAY)
| CK1, 2 (06) (19I, 83I, 84I) |
2007-2009 |
01 |
|
| 001 |
15257725 |
COVER, D/SEAT SHLDR BELT GDE TR (CASHMERE) |
CK1 (06-36) (30I) |
2007-2008 |
01 |
| 001 |
15257725 |
COVER, P/SEAT SHLDR BELT GDE TR (CASHMERE) |
CK1 (06-36) (30I) |
2007-2008 |
01 |
| 001 |
15257726 |
COVER, D/SEAT SHLDR BELT GDE TR (CASHMERE) |
CK1, 2 (06) (22I, 31I, 33I, 39I) |
2007-2008 |
01 |
| 001 |
15257726 |
COVER, P/SEAT SHLDR BELT GDE TR (CASHMERE) |
CK1, 2 (06) (22I, 31I, 33I, 39I) |
2007-2008 |
01 |
| 002 |
|
БОЛТ, D/SEAT SHLDR BELT RETR ANC PLT (PART OF 8) |
|
2007-2009 |
|
| 002 |
|
БОЛТ, P/SEAT SHLDR BELT RETR ANC PLT (PART OF 8) |
|
2007-2009 |
|
| 003 |
|
MOLDING, C/PLR UPR GARN (СМ. ГРУППУ 16.000 ОТДЕЛКА/INTERIOR-BODY SIDE FRONT ДЛЯ ДЕТАЛЬНОГО ПРОСМОТРА) |
|
2007-2009 |
|
| 004 |
|
БОЛТ, D/SEAT BELT GUIDE (RETR SI) (PART OF 5) |
|
2007-2009 |
|
| 004 |
|
БОЛТ, P/SEAT BELT GUIDE (RETR SI) (PART OF 5) |
|
2007-2009 |
|
| 005 |
15829533 |
GUIDE, D/SEAT SHLDR BELT (INCLS 4) (CASHMERE) |
CK1 (06-36) (30I) |
2007-2008 |
01 |
| 005 |
15829533 |
GUIDE, P/SEAT SHLDR BELT (INCLS 4) (CASHMERE) |
CK1 (06-36) (30I) |
2007-2008 |
01 |
| 005 |
25901985 |
GUIDE, D/SEAT SHLDR BELT (INCLS 4) (GRAY)
| CK1, 2 (06) (19I, 83I, 84I) |
2007-2008 |
01 |
|
| 005 |
25901985 |
GUIDE, P/SEAT SHLDR BELT (INCLS 4) (GRAY)
| CK1, 2 (06) |
2007-2009 |
01 |
|
| 006 |
|
RETAINER, D/SEAT BELT (PUSH ON) (PART OF 8) |
|
2007-2009 |
|
| 006 |
|
RETAINER, P/SEAT BELT (PUSH ON) (PART OF 8) |
|
2007-2009 |
|
| 007 |
|
БОЛТ, D/SEAT BELT RETR (PART OF 8) |
|
2007-2009 |
|
| 007 |
|
БОЛТ, P/SEAT BELT RETR (PART OF 8) |
|
2007-2009 |
|
| 008 |
15893204 |
BELT, P/SEAT (RETR SI) (INCLS 2, 6, 7, 14) (CASHMERE)
| K1 (06) (AX4, 30I) (EXPORT) |
2007-2008 |
01 |
|
| 008 |
19181016 |
BELT KIT, D/SEAT (RETR SI) (W/ PRE-TENSR) (INCLS 2, 6, 7, 14) (EBONY) (HAS TOP RETR BRACKET WITH TAB) (FOR 2ND DES SEE 19207562) |
CK1 (06) (HP2, 19I) (1ST DES) |
2008-2008 |
01 |
| 008 |
19181017 |
BELT KIT, D/SEAT (RETR SI) (W/ PRE-TENSR) (INCLS 2, 6, 7, 14) (CASHMERE) (HAS TOP RETR BRACKET WITH TAB) (FOR 2ND DES SEE 19207563) |
CK1 (06) (HP2, 31I, 33I) (1ST DES) |
2008-2008 |
01 |
| 008 |
19181018 |
BELT KIT, D/SEAT (RETR SI) (W/ PRE-TENSR) (INCLS 2, 6, 7, 14) (TITANIUM) (HAS TOP RETR BRACKET WITH TAB) (FOR 2ND DES SEE 19207564) |
CK1 (06) (HP2, 83I) (1ST DES) |
2008-2008 |
01 |
| 008 |
19181022 |
BELT KIT, D/SEAT (RETR SI) (W/ PRE-TENSR) (INCLS 2, 6, 7, 14) (EBONY) (HAS TOP RETR BRACKET WITH TAB) (FOR 2ND DES SEE 19207568) |
CK1 (06-36) (19I, 84I) (EXC AX4, HP2) (1ST DES) |
2008-2008 |
01 |
| 008 |
19181023 |
BELT KIT, D/SEAT (RETR SI) (W/ PRE-TENSR) (INCLS 2, 6, 7, 14) (CASHMERE) (HAS TOP RETR BRACKET WITH TAB) (FOR 2ND DES SEE 19207569) |
CK1 (06-36) (31I, 33I, 39I) (EXC AX4, HP2) (1ST DES) |
2008-2008 |
01 |
| 008 |
19181024 |
BELT KIT, D/SEAT (RETR SI) (W/ PRE-TENSR) (INCLS 2, 6, 7, 14) (TITANIUM) (HAS TOP RETR BRACKET WITH TAB) (FOR 2ND DES SEE 19207570) |
CK1 (06-36) (83I) (EXC AX4, HP2) (1ST DES) |
2008-2008 |
01 |
| 008 |
19181025 |
BELT KIT, D/SEAT (RETR SI) (W/ PRE-TENSR) (INCLS 2, 6, 7, 14) (CASHMERE) (HAS TO RETR BRACKET WITH TAB) (FOR 2ND DES SEE 19207571) |
CK1 (06-36) (30I) (EXC AX4) (1ST DES) |
2008-2008 |
01 |
| 008 |
19181027 |
BELT KIT, D/SEAT (RETR SI) (W/ PRE-TENSR) (INCLS 2, 6, 7, 14) (EBONY) (HAS TOP RETR BRACKET WITH TAB) (FOR 2ND DES SEE 19207573) |
CK1 (06-36) (22I) (1ST DES) |
2008-2008 |
01 |
| 008 |
19181028 |
BELT KIT, D/SEAT (RETR SI) (W/ PRE-TENSR) (INCLS 2, 6, 7, 14) (COCOA) (HAS TOP RETR BRACKET WITH TAB) (FOR 2ND DES SEE 19207574) |
CK1 (06) (41I) (1ST DES) |
2008-2008 |
01 |
| 008 |
19181029 |
BELT KIT, P/SEAT (RETR SI) (W/ PRE-TENSR) (INCLS 2, 6, 7, 14) (EBONY) (HAS TOP RETR BRACKET WITH TAB) (FOR 2ND DES SEE 19207575) |
CK1 (06) (HP2, 19I) (1ST DES) |
2008-2008 |
01 |
| 008 |
19181030 |
BELT KIT, P/SEAT (RETR SI) (W/ PRE-TENSR) (INCLS 2, 6, 7, 14) (CASHMERE) (HAS TOP RETR BRACKET WITH TAB) (FOR 2ND DES SEE 19207576) |
CK1 (06) (HP2, 31I, 33I) (1ST DES) |
2008-2008 |
01 |
| 008 |
19181031 |
BELT KIT, P/SEAT (RETR SI) (W/ PRE-TENSR) (INCLS 2, 6, 7, 14) (TITANIUM) (HAS TOP RETR BRACKET WITH TAB) (FOR 2ND DES SEE 19207577) |
CK1 (06) (HP2, 83I) (1ST DES) |
2008-2008 |
01 |
| 008 |
19181036 |
BELT KIT, P/SEAT (RETR SI) (W/ PRE-TENSR) (INCLS 2, 6, 7, 14) (EBONY) (HAS TOP RETR BRACKET WITH TAB) (FOR 2ND DES SEE 19207582)
| CK1 (06-36) (19I, 84I) (EXC AX4, HP2) (1ST DES) |
2008-2008 |
01 |
|
| 008 |
19181037 |
BELT KIT, P/SEAT (RETR SI) (W/ PRE-TENSR) (INCLS 2, 6, 7, 14) (CASHMERE) (HAS TOP RETR BRACKET WITH TAB) (FOR 2ND DES SEE 19207583) |
CK1 (06-36) (31I, 33I, 39I) (EXC AX4, HP2) (1ST DES) |
2008-2008 |
01 |
| 008 |
19181038 |
BELT KIT, P/SEAT (RETR SI) (W/ PRE-TENSR) (INCLS 2, 6, 7, 14) (TITANIUM) (HAS TOP RETR BRACKET WITH TAB) (FOR 2ND DES SEE 19207584) |
CK1 (06-36) (83I) (EXC AX4, HP2) (1ST DES) |
2008-2008 |
01 |
| 008 |
19181039 |
BELT KIT, P/SEAT (RETR SI) (W/ PRE-TENSR) (INCLS 2, 6, 7, 14) (CASHMERE) (HAS TOP RETR BRACKET WITH TAB) (FOR 2ND DES SEE 19207585) |
CK1 (06-36) (30I) (EXC AX4) (1ST DES) |
2008-2008 |
01 |
| 008 |
19181041 |
BELT KIT, P/SEAT (RETR SI) (W/ PRE-TENSR) (INCLS 2, 6, 7, 14) (EBONY) (HAS TOP RETR BRACKET WITH TAB) (FOR 2ND DES SEE 19207587) |
CK1 (06-36) (22I) (1ST DES) |
2008-2008 |
01 |
| 008 |
19181042 |
BELT KIT, P/SEAT (RETR SI) (W/ PRE-TENSR) (INCLS 2, 6, 7, 14) (COCOA) (HAS TOP RETR BRACKET WITH TAB) (FOR 2ND DES SEE 19207588) |
CK1 (06) (41I) (1ST DES) |
2008-2008 |
01 |
| 008 |
19207562 |
BELT KIT, D/SEAT (RETR SI) (W/ PRE-TENSR) (INCLS 2, 6, 7, 14) (EBONY) (HAS EXTENDED TOP RETR BRACKET WITH TAB AND FASTENER HOLE) (FOR 1ST DES SEE 19181016) |
CK1 (06) (HP2, 19I) (2ND DES) |
2008-2008 |
01 |
| 008 |
19207563 |
BELT KIT, D/SEAT (RETR SI) (W/ PRE-TENSR) (INCLS 2, 6, 7, 14) (CASHMERE) (HAS EXTENDED TOP RETR BRACKET WITH TAB AND FASTENER HOLE) (FOR 1ST DES SEE 19181017) |
CK1 (06) (HP2, 31I, 33I) (2ND DES) |
2008-2008 |
01 |
| 008 |
19207564 |
BELT KIT, D/SEAT (RETR SI) (W/ PRE-TENSR) (INCLS 2, 6, 7, 14) (TITANIUM) (HAS EXTENDED TOP RETR BRACKET WITH TAB AND FASTENER HOLE) (FOR 1ST DES SEE 19181018) |
CK1 (06) (HP2, 83I) (2ND DES) |
2008-2008 |
01 |
| 008 |
19207568 |
BELT KIT, D/SEAT (RETR SI) (W/ PRE-TENSR) (INCLS 2, 6, 7, 14) (EBONY) (HAS EXTENDED TOP RETR BRACKET WITH TAB AND FASTENER HOLE) (FOR 1ST DES SEE 19181022)
| CK1 (06-36) (19I, 84I) (EXC AX4, HP2) (2ND DES) |
2008-2008 |
01 |
|
| 008 |
19207569 |
BELT KIT, D/SEAT (RETR SI) (W/ PRE-TENSR) (INCLS 2, 6, 7, 14) (CASHMERE) (HAS EXTENDED TOP RETR BRACKET WITH TAB AND FASTENER HOLE) (FOR 1ST DES SEE 19181023) |
CK1 (06-36) (31I, 33I, 39I) (EXC AX4, HP2) (2ND DES) |
2008-2008 |
01 |
| 008 |
19207570 |
BELT KIT, D/SEAT (RETR SI) (W/ PRE-TENSR) (INCLS 2, 6, 7, 14) (TITANIUM) (HAS EXTENDED TOP RETR BRACKET WITH TAB AND FASTENER HOLE) (FOR 1ST DES SEE 19181024) |
CK1 (06-36) (83I) (EXC AX4, HP2) (2ND DES) |
2008-2008 |
01 |
| 008 |
19207571 |
BELT KIT, D/SEAT (RETR SI) (W/ PRE-TENSR) (INCLS 2, 6, 7, 14) (CASHMERE) (HAS EXTENDED TOP RETR BRACKET WITH TAB AND FASTENER HOLE) (FOR 1ST DES SEE 19181025) |
CK1 (06-36) (30I) (EXC AX4) (2ND DES) |
2008-2008 |
01 |
| 008 |
19207573 |
BELT KIT, D/SEAT (RETR SI) (W/ PRE-TENSR) (INCLS 2, 6, 7, 14) (EBONY) (HAS EXTENDED TOP RETR BRACKET WITH TAB AND FASTENER HOLE) (FOR 1ST DES SEE 19181027) |
CK1 (06-36) (22I) (2ND DES) |
2008-2008 |
01 |
| 008 |
19207574 |
BELT KIT, D/SEAT (RETR SI) (W/ PRE-TENSR) (INCLS 2, 6, 7, 14) (COCOA) (HAS EXTENDED TOP RETR BRACKET WITH TAB AND FASTENER HOLE) (FOR 1ST DES SEE 19181028) |
CK1 (06) (41I) (2ND DES) |
2008-2008 |
01 |
| 008 |
19207575 |
BELT KIT, P/SEAT (RETR SI) (W/ PRE-TENSR) (INCLS 2, 6, 7, 14) (EBONY) (HAS EXTENDED TOP RETR BRACKET WITH TAB AND FASTENER HOLE) (FOR 1ST DES SEE 19181029) |
CK1 (06) (HP2, 19I) (2ND DES) |
2008-2008 |
01 |
| 008 |
19207576 |
BELT KIT, P/SEAT (RETR SI) (W/ PRE-TENSR) (INCLS 2, 6, 7, 14) (CASHMERE) (HAS EXTENDED TOP RETR BRACKET WITH TAB AND FASTENER HOLE) (FOR 1ST DES SEE 19181030) |
CK1 (06) (HP2, 31I, 33I) (2ND DES) |
2008-2008 |
01 |
| 008 |
19207577 |
BELT KIT, P/SEAT (RETR SI) (W/ PRE-TENSR) (INCLS 2, 6, 7, 14) (TITANIUM) (HAS EXTENDED TOP RETR BRACKET WITH TAB AND FASTENER HOLE) (FOR 1ST DES SEE 19181031) |
CK1 (06) (HP2, 83I) (2ND DES) |
2008-2008 |
01 |
| 008 |
19207582 |
BELT KIT, P/SEAT (RETR SI) (W/ PRE-TENSR) (INCLS 2, 6, 7, 14) (EBONY) (HAS EXTENDED TOP RETR BRACKET WITH TAB AND FASTENER HOLE) (FOR 1ST DES SEE 19181036)
| CK1 (06-36) (19I, 84I) (EXC AX4, HP2) (2ND DES) |
2008-2008 |
01 |
|
| 008 |
19207583 |
BELT KIT, P/SEAT (RETR SI) (W/ PRE-TENSR) (INCLS 2, 6, 7, 14) (CASHMERE) (HAS EXTENDED TOP RETR BRACKET WITH TAB AND FASTENER HOLE) (FOR 1ST DES SEE 19181037) |
CK1 (06-36) (31I, 33I, 39I) (EXC AX4, HP2) (2ND DES) |
2008-2008 |
01 |
| 008 |
19207584 |
BELT KIT, P/SEAT (RETR SI) (W/ PRE-TENSR) (INCLS 2, 6, 7, 14) (TITANIUM) (HAS EXTENDED TOP RETR BRACKET WITH TAB AND FASTENER HOLE) (FOR 1ST DES SEE 19181038) |
CK1 (06-36) (83I) (EXC AX4, HP2) (2ND DES) |
2008-2008 |
01 |
| 008 |
19207585 |
BELT KIT, P/SEAT (RETR SI) (W/ PRE-TENSR) (INCLS 2, 6, 7, 14) (CASHMERE) (HAS EXTENDED TOP RETR BRACKET WITH TAB AND FASTENER HOLE) (FOR 1ST DES SEE 19181039) |
CK1 (06-36) (30I) (EXC AX4) (2ND DES) |
2008-2008 |
01 |
| 008 |
19207587 |
BELT KIT, P/SEAT (RETR SI) (W/ PRE-TENSR) (INCLS 2, 6, 7, 14) (EBONY) (HAS EXTENDED TOP RETR BRACKET WITH TAB AND FASTENER HOLE) (FOR 1ST DES SEE 19178395) |
CK1 (06-36) (22I) (2ND DES) |
2008-2008 |
01 |
| 008 |
19207588 |
BELT KIT, P/SEAT (RETR SI) (W/ PRE-TENSR) (INCLS 2, 6, 7, 14) (COCOA) (HAS EXTENDED TOP RETR BRACKET WITH TAB AND FASTENER HOLE) (FOR 1ST DES SEE 19181042) |
CK1 (06) (41I) (2ND DES) |
2008-2008 |
01 |
| 008 |
25778304 |
BELT, D/SEAT (RETR SI) (INCLS 2, 6, 7, 14) (EBONY) |
K1 (06) (AX4, 19I) (EXPORT) |
2007-2008 |
01 |
| 008 |
25941491 |
BELT, D/SEAT (RETR SI) (INCLS 2, 6, 7, 14) (CASHMERE) |
K1 (06) (AX4, 30I) (EXPORT) |
2007-2009 |
01 |
| 008 |
25941494 |
BELT, P/SEAT (RETR SI) (INCLS 2, 6, 7, 14) (EBONY)
| K1 (06) (AX4, 19I) (EXPORT) |
2007-2009 |
01 |
|
| 009 |
11518121 |
ГАЙКА, D/SEAT BELT (RETR SI) (M6 X 1 X 12.5) (U-SHAPE) (8.921) |
CK1, 2 (06) |
2008-2009 |
01 |
| 009 |
11518121 |
ГАЙКА, P/SEAT BELT (RETR SI) (M6 X 1 X 12.5) (U-SHAPE) (8.921) |
CK1, 2 (06) |
2008-2009 |
01 |
| 009 |
15035434 |
ГАЙКА, D/SEAT BELT (RETR SI) (M10X1.5X10.8) (FLANGE NUT) (16.679)
| CK1, 2 |
2007-2009 |
01 |
|
| 009 |
15035434 |
ГАЙКА, P/SEAT BELT (RETR SI) (M10X1.5X10.8) (FLANGE NUT) (16.679)
| CK1, 2 |
2007-2009 |
01 |
|
| 010 |
19121537 |
BELT KIT, D/SEAT (BKL SI) (EBONY)
| CK1, 2 (06) (AN3, 19I, 22I, 84I) |
2007-2009 |
01 |
|
| 010 |
19121538 |
BELT KIT, D/SEAT (BKL SI) (CASHMERE) |
CK1, 2 (06) (AN3, 31I, 33I, 39I) |
2007-2009 |
01 |
| 010 |
19121539 |
BELT KIT, D/SEAT (BKL SI) (TITANIUM) |
CK1, 2 (06) (AN3, 83I) |
2007-2009 |
01 |
| 010 |
19121540 |
BELT KIT, D/SEAT (BKL SI) (CASHMERE) |
CK1 (06-36) (AN3, AL0, Z75, 304) |
2007-2008 |
01 |
| 010 |
19121542 |
BELT KIT, P/SEAT (BKL SI) (CASHMERE) (W/РОЛИК НАТЯЖИТЕЛЬ) |
CK1, 2 (AL0, 31I, 33I, 39I) |
2007-2009 |
01 |
| 010 |
19121543 |
BELT KIT, P/SEAT (BKL SI) (TITANIUM) (W/РОЛИК НАТЯЖИТЕЛЬ) |
CK1, 2 (06) (AN3, 83I) |
2007-2009 |
01 |
| 010 |
19121544 |
BELT KIT, P/SEAT (BKL SI) (CASHMERE) (W/РОЛИК НАТЯЖИТЕЛЬ) |
CK1 (06-36) (AN3, AL0, 30I) |
2007-2008 |
01 |
| 010 |
19180587 |
BELT KIT, D/SEAT (BKL SI) (COCOA) |
CK1 (06) (AN3, HNE, ULT, Z75, 415) |
2008-2009 |
01 |
| 010 |
19180588 |
BELT KIT, P/SEAT (BKL SI) (COCOA) |
CK1 (06) (AN3, Z75, 415) |
2008-2009 |
01 |
| 011 |
|
ГАЙКА, D/SEAT BELT (BKL SI) |
|
2007-2009 |
|
| 011 |
|
ГАЙКА, P/SEAT BELT (BKL SI) |
|
2007-2009 |
|
| 012 |
|
BELT KIT, F/SEAT CTR |
|
2007-2009 |
|
| 013 |
12473319 |
БОЛТ, F/SEAT CTR BELT (M12X1.75X37) (HEX) (OUTER) (16.682) |
CK1, 2, 3 |
2007-2009 |
01 |
| 014 |
19121443 |
STOP KIT, BELT LAT (RETR SI) (PART OF 8) (TITANIUM) (14.875) |
CK1, 2, 3 (83I) |
2007-2009 |
01 |
| 014 |
19121443 |
STOP KIT, BELT LAT (RETR SI) (PART OF 8) (TITANIUM) (14.875) |
CK1, 2, 3 (84I) |
2008-2009 |
01 |
| 014 |
19121445 |
STOP KIT, BELT LAT (RETR SI) (PART OF 8) (CASHMERE) (14.875) |
CK1, 2, 3 (31I) |
2008-2009 |
01 |
| 014 |
19121446 |
STOP KIT, BELT LAT (RETR SI) (PART OF 8) (EBONY) (14.875) |
CK1, 2, 3 (19I, 88I) |
2007-2009 |
01 |
| 014 |
19207765 |
STOP KIT, BELT LAT (RETR SI) (PART OF 8) (COCOA) (14.875) |
CK1, 2, 3 (41I) |
2008-2009 |
01 |
