| Поз. | Номер | Описание | Применение | Номенклатура | Кол-во |
| 001 |
15763887 |
RETAINER, HDLNG FRT T/PNL (DUAL LOCK) (BLACK) (SQ 26.0 X DIA 7.89) (W/VELCRO) |
CK159, 2 (06) |
2000-2006 |
AR |
| 002 |
11518121 |
ГАЙКА, U, M6X1, MULTI THD, .5-4.0 THK PNL (I/P DRVR KNEE BOLS REINF) |
|
2000-2006 |
AR |
| 003 |
15124270 |
DEFLECTOR, AUX A/C AIR OTLT (PART OF 4) (PEWTER) |
CK1, 2 (06) (92I) |
2002-2006 |
AR |
| 003 |
15124271 |
DEFLECTOR, AUX A/C AIR OTLT (PART OF 4) (SHALE) |
CK1, 2 (06) (15I, 52I) |
2002-2006 |
AR |
| 004 |
15214763 |
PANEL, HDLNG FRT TR (INCLS 3, 5, 8, 11-15, 26) (PEWTER) |
K159 (06) (CF5, CJ2, C36, DK8, U42, Z75, 92I) |
2005-2006 |
01 |
| 004 |
15239977 |
PANEL, HDLNG FRT TR (INCLS 3, 5, 8, 11-15, 26) (SHALE) |
K159 (06) (CF5, CJ2, C36, DK8, ULT, U42, 15I) |
2004-2006 |
01 |
| 004 |
15787465 |
PANEL, HDLNG FRT TR (INCLS 3, 5, 8, 11-15, 26) (SHALE) |
CK159, 2 (06) (CF5, CJ2, C36, DK8, Z75, 15I) (EXC ULT, U42) |
2004-2006 |
01 |
| 004 |
15787466 |
PANEL, HDLNG FRT TR (INCLS 3, 5, 8, 11-15, 26) (PEWTER) |
K159 (06) (CF5, CJ2, C36, DK8, Z75, 92I) (EXC U42) |
2005-2006 |
01 |
| 004 |
15787468 |
PANEL, HDLNG FRT TR (INCLS 3, 5, 8, 11-15, 26) (SHALE) |
CK159, 2 (06) (CF5, CJ2, C36, DK8, U42, Z75, 15I) (EXC ULT) |
2005-2006 |
01 |
| 005 |
15044366 |
HANDLE, ASST (PART OF 4) (SHALE) (INCLUDES RETAINER) |
CK159, 2 (06) (52I, 92I) (EXC U42) |
2006-2006 |
01 |
| 005 |
15048750 |
HANDLE, ASST (PART OF 4) (PEWTER) (FRT PASS SIDE) (INCLUDES RETAINERS) |
K159 (06-36) (92I) |
2001-2006 |
01 |
| 006 |
11588650 |
CLIP, 12X14X16.6, GM4345M (PART OF 7)
|
2000-2006 |
02 |
|
| 007 |
10382915 |
RETAINER, RF CNSL (PUSH IN) (INCLS 6) |
CK1, 2 (06) (CF5, DK8) |
2000-2006 |
01 |
| 008 |
15186286 |
RETAINER, S/S (PART OF 4) (SHALE) (OPENING FACES AWAY FROM FASTENER) |
CK1, 2 (06) (69I) |
2004-2006 |
02 |
| 008 |
15186286 |
RETAINER, S/S (PART OF 4) (SHALE) (OPENING FACES AWAY FROM FASTENER) |
CK1, 2 (06) (Z75, 15I) |
2004-2006 |
02 |
| 008 |
15186287 |
RETAINER, S/S (PART OF 4) (PEWTER) |
CK1 (06) (Z75, 92I) |
2004-2006 |
02 |
| 009 |
11516440 |
SCREW (PART OF 10) |
|
2000-2006 |
04 |
| 010 |
15256848 |
СОЛНЦЕЗАЩИТНЫЙ КОЗЫРЕК, (INCLS 9) (SHALE) |
K159 (06) (DH6, ULT, 15I) |
2006-2006 |
01 |
| 010 |
15282714 |
СОЛНЦЕЗАЩИТНЫЙ КОЗЫРЕК, (INCLS 9) (SHALE) |
CK1, 2 (06) (DH6, 15I) (EXC ULT) |
2006-2006 |
01 |
| 010 |
15282714 |
СОЛНЦЕЗАЩИТНЫЙ КОЗЫРЕК, (INCLS 9) (SHALE) |
CK1, 2 (06) (DH6, 52I) |
2006-2006 |
01 |
| 010 |
15282715 |
СОЛНЦЕЗАЩИТНЫЙ КОЗЫРЕК, (INCLS 9) (PEWTER) |
CK1 (06-36) (DH6, Z75, 92I) |
2006-2006 |
01 |
| 010 |
15282717 |
СОЛНЦЕЗАЩИТНЫЙ КОЗЫРЕК, (INCLS 9) (SHALE) |
CK1, 2 (06) (DH6, 15I) (EXC ULT) |
2006-2006 |
01 |
| 010 |
15282717 |
СОЛНЦЕЗАЩИТНЫЙ КОЗЫРЕК, (INCLS 9) (SHALE) |
CK1, 2 (06) (DH6, 52I) |
2006-2006 |
01 |
| 010 |
15282718 |
СОЛНЦЕЗАЩИТНЫЙ КОЗЫРЕК, (INCLS 9) (PEWTER) |
CK1 (06) (DH6, Z75, 92I) |
2006-2006 |
01 |
| 010 |
15282720 |
СОЛНЦЕЗАЩИТНЫЙ КОЗЫРЕК, (INCLS 9) (SHALE) (USED ON VEHICLES THAT HAVE A SLIDE ON ARM FEATURE) (FOR 1ST DES SEE 15256846) |
K159 (06) (DH6, ULT, 15I) |
2006-2006 |
01 |
| 011 |
15166054 |
LAMP, DM RDG (INCLS 12-15) (PART OF 4) (SHALE) (W/ PUSHBUTTONS 3 BULB LAMP)
| K159 (06) (ULT, Y91, Z75, 15I) |
2004-2006 |
02 |
|
| 011 |
15166055 |
LAMP, DM RDG (INCLS 12-15) (PART OF 4) (PEWTER) (W/ PUSHBUTTONS 3 BULB LAMP) |
CK1 (06) (92I, Z75) |
2002-2006 |
AR |
| 012 |
12450074 |
BULB, TRADE #578 (PART OF 4, 11) (ACDelco #578)
|
2000-2006 |
03 |
|
| 013 |
15032588 |
LENS, DM RDG LP (PART OF 4, 11) (3 BULB STYLE) |
CK1, 2, 3 |
2001-2006 |
01 |
| 014 |
15166059 |
PUSHBUTTON, RDG LP SW (PART OF 4, 11) (EBONY) |
CK1, 2, 3 |
2001-2006 |
02 |
| 015 |
15032587 |
ШЛАНГИ, DM RDG LP (PART OF 4, 11) |
CK1, 2, 3 |
2001-2006 |
01 |
| 016 |
15763887 |
RETAINER, HDLNG FRT T/PNL (DUAL LOCK) (BLACK) (SQ 26.0 X DIA 7.89) (W/VELCRO) |
CK159, 2 (06) |
2000-2006 |
AR |
| 017 |
15206648 |
RETAINER, HDLNG FRT T/PNL (PUSH IN) (SHALE) (LONG PUSH PIN) (LENGTH 47.5MM)
| CK159, 2 (06) (Z75, 15I) |
2003-2006 |
AR |
|
| 017 |
15206649 |
RETAINER, HDLNG FRT T/PNL (PUSH IN) (PEWTER) (LONG PUSH PIN) |
K159 (06) (Z75, 92I) |
2003-2006 |
04 |
| 018 |
15111579 |
RETAINER, HDLNG FRT T/PNL (PUSH IN) (PEWTER) (SHORT PUSH PIN)
| K159 (06) (Z75, 92I) |
2003-2006 |
AR |
|
| 018 |
15111580 |
RETAINER, HDLNG FRT T/PNL (PUSH IN) (SHALE) (SHORT PUSH PIN) (28.8MM LENGTH) |
CK159, 2 (06) (Z75, 15I) |
2003-2006 |
AR |
| 019 |
15166042 |
LAMP, DM (INCLS 20, 21) (PART OF 22) (PEWTER) (ONE BULB LAMP) |
K159 (06) (Z75, 92I) |
2003-2006 |
AR |
| 019 |
15166043 |
LAMP, DM (INCLS 20, 21) (PART OF 22) (SHALE) (1 BULB STYLE) |
CK1, 2, 3 (15I, 52I, 69I, 92I) |
2003-2006 |
01 |
| 020 |
88892575 |
LENS, DM LP (PART OF 19, 22) (ONE BULB STYLE) |
CK1, 2, 3 |
2001-2006 |
01 |
| 021 |
09431808 |
BULB, TRADE # 211-2 (PART OF 19, 22) (ACDelco #L211-2) |
|
2000-2006 |
01 |
| 022 |
10372339 |
PANEL, HDLNG RR TR (INCLS 19-21, 24) (SHALE) (INCLS HARNESS) |
K159 (06) (ULT, Y91, Z75, 15I) |
2004-2006 |
01 |
| 022 |
93440684 |
PANEL, HDLNG RR TR (INCLS 19-21, 24) (SHALE) (INCLS HARNESS) |
K159 (06) (Z75, 15I) (EXC ULT) |
2004-2006 |
01 |
| 022 |
93440685 |
PANEL, HDLNG RR TR (INCLS 19-21, 24) (PEWTER) (INCLS HARNESS) |
K159 (06) (Z75, 92I) |
2003-2006 |
01 |
| 023 |
15111579 |
RETAINER, HDLNG FRT T/PNL (PUSH IN) (PEWTER) (SHORT PUSH PIN)
| K159 (06) (Z75, 92I) |
2003-2006 |
AR |
|
| 023 |
15111580 |
RETAINER, HDLNG FRT T/PNL (PUSH IN) (SHALE) (SHORT PUSH PIN) (28.8MM LENGTH) |
CK159, 2 (06) (Z75, 15I) |
2003-2006 |
AR |
| 024 |
15045844 |
HOOK, COAT (RR CARGO AREA) (PART OF 22) (PEWTER) |
K159 (06) (Z75, 92I) |
2003-2006 |
02 |
| 024 |
15760164 |
HOOK, COAT (PART OF 22) (SHALE) |
CK159, 2 (06) (52I, 92I) |
2003-2006 |
02 |
| 025 |
|
КОНСОЛЬ, RF (СМ. ГРУППУ 16.000 КОНСОЛЬ/КРЫША ДЛЯ ДЕТАЛЬНОГО ПРОСМОТРА) |
|
2000-2006 |
|
| 026 |
25903301 |
ASPIRATOR, I/S AIR TEMP SEN (PART OF 4) (ACDelco #15-51256)
| CK1, 2 (06) |
2003-2006 |
02 |
|
