| Поз. | Номер | Описание | Применение | Номенклатура | Кол-во |
| 001 |
15145241 |
MOLDING, BK BODY OPG GARN (INCLS 2) (SHALE) |
K1 (06) (E52, ULT, 15I) |
2004-2006 |
01 |
| 001 |
15747517 |
MOLDING, BK BODY OPG GARN (INCLS 2) (PEWTER) (16.575) |
K1, 2 (06) (E52, 92I) |
2003-2006 |
01 |
| 001 |
15760296 |
MOLDING, BK BODY OPG GARN (INCLS 2) (SHALE) |
K1 (06) (E52, 15I) (EXC ULT) |
2004-2006 |
01 |
| 002 |
15748479 |
RETAINER, GARNISH MOLDING TYPE, FITS SLOT 6.0MM, SPR STL, ZC (PART OF 1) |
|
2003-2006 |
07 |
| 003 |
|
MOLDING, BODY RR COR UPR GARN (СМ. ГРУППУ 16.000 ОТДЕЛКА/INTERIOR-BODY SIDE-QUARTER DETAIL ДЛЯ ДЕТАЛЬНОГО ПРОСМОТРА) |
|
2003-2006 |
|
| 004 |
11588650 |
CLIP, 12X14X16.6, GM4345M (PART OF 9)
|
2003-2006 |
10 |
|
| 005 |
10390375 |
PLATE, RR S/D SILL TR (INCLS 7) (SHALE) |
K159 (06-36) (Y91, Z75, 15I) (EXC ULT) |
2004-2006 |
02 |
| 005 |
10390376 |
PLATE, RR S/D SILL TR (INCLS 7) (PEWTER) |
K159 (06-36) (Y91, Z75, 92I) |
2003-2006 |
02 |
| 005 |
15254116 |
PLATE, RR S/D SILL TR (INCLS 7) (SHALE) |
K159 (06) (ULT, Y91, Z75, 15I) |
2006-2006 |
02 |
| 006 |
21011332 |
ГАЙКА, HEX STAMPED TY DF FLG 14 (RR S/D SILL TR PLT BRKT) (8.921) |
|
2003-2006 |
06 |
| 007 |
15254056 |
RETAINER, RR S/D SILL TR PLT (PART OF 5) (8.950) |
K1 (06) (ULT, Y91, Z75) |
2004-2006 |
06 |
| 007 |
16651848 |
RETAINER, RR S/D SILL TR PLT (PART OF 5) (BLACK) (STEEL) (12.045) |
K159 (06-36) (Y91, Z75) (EXC ULT) |
2004-2006 |
03 |
| 008 |
15177754 |
BRACKET, RR S/D SILL TR PLT (MAY NEED TO ORDER NEWEST BRKT STUD P/N 20513798) |
K159, 2 (06) |
2005-2006 |
02 |
| 009 |
15145233 |
MOLDING, BODY L/PLR GARN (INCLS 4, 10-12) (SHALE) |
K1 (06) (ULT, 15I) |
2004-2006 |
01 |
| 009 |
15145235 |
MOLDING, BODY L/PLR GARN (INCLS 4, 10-12) (SHALE) |
K1 (06) (ULT, 15I) |
2004-2006 |
01 |
| 009 |
15214599 |
MOLDING, BODY L/PLR GARN (INCLS 4, 10-12) (PEWTER) |
K159, 2 (06) (92I) |
2003-2006 |
01 |
| 009 |
15214600 |
MOLDING, BODY L/PLR GARN (INCLS 4, 10-12) (SHALE) |
K159 (06) (15I) (EXC ULT) |
2004-2006 |
01 |
| 009 |
15214603 |
MOLDING, BODY L/PLR GARN (INCLS 4, 10-12) (PEWTER) |
K159, 2 (06) (92I) |
2003-2006 |
01 |
| 009 |
15214604 |
MOLDING, BODY L/PLR GARN (INCLS 4, 10-12) (SHALE) |
K159 (06) (15I) (EXC ULT) |
2004-2006 |
01 |
| 010 |
15069120 |
GUIDE, R/SEAT SHLDR BELT (LOWER COMFORT GUIDE) (PART OF 9) (SHALE) |
K159 (06) (15I) |
2003-2006 |
02 |
| 010 |
15755985 |
GUIDE, R/SEAT SHLDR BELT (PART OF 9) (PEWTER) (LOWER COMFORT GUIDE) |
K1, 2 (06) (92I) |
2003-2006 |
02 |
| 011 |
10404690 |
CLIP, BODY L/PLR G/MLDG (PART OF 9) (15.2MM WIDE) |
CK159, 2 (06) (EXC ULT) |
2005-2006 |
04 |
| 012 |
11561392 |
RETAINER, BODY L/PLR G/MLDG (LEFT AND RIGHT) (PART OF 9) |
K1, 2 (06) |
2006-2006 |
01 |
| 012 |
11561392 |
RETAINER, BODY L/PLR G/MLDG (LEFT AND RIGHT) (PART OF 9) |
K1, 2 (06) |
2006-2006 |
01 |
| 012 |
11561392 |
RETAINER, BODY L/PLR G/MLDG (LEFT AND RIGHT) (PART OF 9) |
K1, 2 |
2006-2006 |
06 |
| 013 |
|
PANEL, BODY SI TR (СМ. ГРУППУ 16.000 ОТДЕЛКА/INTERIOR-BODY SIDE-QUARTER DETAIL ДЛЯ ДЕТАЛЬНОГО ПРОСМОТРА) |
|
2003-2006 |
|
| 014 |
15043000 |
PLUG, R/CMPT SILL TR PLT HOLE (38.0 X 17.0 X 18.0MM) (OBLONG) (16.600) |
K1, 2 (06) |
2003-2006 |
11 |
| 015 |
15748479 |
RETAINER, GARNISH MOLDING TYPE, FITS SLOT 6.0MM, SPR STL, ZC (PART OF 16) |
|
2003-2006 |
11 |
| 016 |
10390986 |
PLATE, R/FLR RR TR (INCLS 15) (PEWTER) |
K1, 2 (06) (E52, 92I) |
2006-2006 |
01 |
| 016 |
10390988 |
PLATE, R/FLR RR TR (INCLS 15) (SHALE) |
K1 (06) (E52, 15I) |
2006-2006 |
01 |
